▶ EngineEngine Manufacturer FPT FPT Engine Model Not Published Not Published Engine Type Turbocharged 6-cylinder diesel, 12 valves 4-cylinder, turbocharged and aftercooled No. of Cylinders 6 4 Displacement 411 in³ 219.7 in³ Rated Engine Speed 2200 rpm 2300 rpm Engine Power (Gross) 125 hp 117 hp PTO Power 105 hp 99 hp Engine Emissions Constraints Tier 3 Tier 4 Cooling System Type Liquid-cooled Not Published Air Cleaner Not Published Not Published Fuel System Mechanical injection Not Published Alternator 120 A Not Published ▶ HydraulicsPump Type Fixed displacement pump Not Published Implement Flow 22 gpm 21.7 gpm Steering Flow 9 gpm Not Published Total Hydraulic Flow 31 gpm Not Published Overall Hydraulic Pump Flow 31 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves 4 3 (or 3 with diverter) ▶ Fluid CapacityFuel Tank Capacity 62 gal 34.3 gal Coolant Capacity Not Published Not Published Crankcase Capacity 14.8 qt Not Published Transmission / Hydraulic System Capacity 65.5 qt Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Not Published PTO Rear 540/1000 (two individual shafts) Not Published Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II with flex link ends Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 7,200 lb 4,123 lb (6,938 lb optional) Lift Control Type Not Published 12x12: mechanical draft control, top link sensing; Hi-Lo: electronic draft control, lower link sensing ▶ Transmission & DrivetrainTransmission Type Not Published 12x12 electronic power shuttle (standard); 20x20 electronic power shuttle with creeper (optional) No. of Speeds 8F/8R (16F/8R optional) 12F/12R (20F/20R with creeper optional) Max Travel Speed (Forward) 18.4 mph Not Published Max Travel Speed (Reverse) 19.0 mph Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Electro-hydraulic differential lock; Class 1.0 MFD front axle with limited slip ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Not Published Brakes Wet disc Not Published Seat Suspension & Adjustability Mechanical seat (standard); air suspension seat (optional) Not Published Front Axle Type Not Published Class 1.0 MFD with limited slip Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width Not Published Not Published Wheelbase 105 in (2WD); 104 in (MFD) 92.5 in (MFD) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 106.2 in Overall Length Not Published 158.2 in (MFD cab) ▶ WeightTractor Weight (Base) 9,061 lb (2WD ROPS); 9,700 lb (MFD ROPS); 9,766 lb (2WD cab); 10,406 lb (MFD cab) 10,240 lb (MFD, cab, without ballast) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear 18.4-34 Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Automatic quick-coupling loader mount with combined hydraulic connection Not Published Loader Model L755 L635 Loader Lift Height Not Published L635: up to 149 in Loader Lift Capacity (Full Height) Not Published Not Published Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
