▶ EnginePTO Power 19.2 hp 17.2 hp Alternator Not Published Not Published Air Cleaner Not Published Not Published Engine Type Diesel, naturally aspirated Diesel, naturally aspirated Fuel System Not Published Indirect injection Displacement 79.3 in³ 76.9 in³ No. of Cylinders 3 3 Rated Engine Speed 2500 rpm 3000 rpm Cooling System Type Not Published Water-cooled Engine Manufacturer Not Published Not Published Engine Power (Gross) 24.6 hp 24.7 hp Engine Emissions Constraints Tier 4 Tier 4 ▶ WeightWeight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published ▶ HydraulicsPump Type Not Published Not Published Steering Flow Not Published Not Published Implement Flow 7.9 gpm 4.6 gpm Total Hydraulic Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 0 (standard) / 1 (optional) (DIA) Not Published Overall Hydraulic Pump Flow Not Published Not Published No. of Optional Remote Valves 1 1 No. of Standard Remote Valves 0 0 ▶ PTO & HitchPTO Rear 540 rpm 540 rpm PTO Type Not Published Independent electro-hydraulic engagement; Mid-PTO: standard (2,500 rpm) Lift Control Type Not Published Not Published Hitch Lift Capacity 1,433 lb @ 24 in behind pin 992 lb Mid-PTO Availability Optional mid-PTO (2,000 rpm) Standard Category, 3-Point Hitch Category 1 Category 1 Hitch Lift Capacity (at 24”) 1,433 lb @ 24 in behind pin 728 lb @ 24 in behind ball ends ▶ Tire OptionsR3 Turf - Rear Not Published Not Published R3 Turf - Front Not Published Not Published Tire Size & Options Not Published Not Published R4 Industrial - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R1 Agricultural - Front Not Published Not Published ▶ Fluid CapacityCoolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Fuel Tank Capacity 7.4 gal 6.6 gal Front Axle Fluid Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published ▶ Loader & AttachmentsLoader Lift Height 94.3 in Up to 72 in Loader Breakout Force 1,926 lb Up to 1,426 lb Quick Attach Loader System L330 L320S Loader Lift Capacity (Full Height) 1,214 lb Up to 693 lb ▶ Transmission & DrivetrainClutch Dry clutch Wet clutch No. of Speeds 12F/12R (mechanical shuttle); Hydrostatic (optional) Not Published Transmission Type 12x12 Mechanical shuttle with synchro shift (dry clutch) (standard); Hydrostatic (optional) 2-Range Hydrostatic Synchro Shuttle (wet clutch) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Differential Lock & Limited Slip Options Mechanical differential lock Mechanical differential lock ▶ Chassis, Steering & ControlsBrakes Not Published Not Published Steering Not Published Not Published Frame Type Not Published Not Published Front Axle Type Mechanical Front Drive (MFD) Mechanical Front Drive (MFD) Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 65.9 in 56 in Overall Width Not Published Not Published Ground Clearance Not Published Not Published Height to Top of ROPS 88.2 in 87.4 in Height to Top of Cab Model Not Applicable Not Applicable Height to Top of ROPS (folded) 68.2 in 62.4 in Min. Turn Radius without Brakes Not Published Not Published Overall Length with 3-Point Hitch 117.2 in 97 in
