▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNM74F-NCJT 3TNM74F Engine Type Diesel 3 cylinder, water-cooled diesel, natural aspiration No. of Cylinders 3 3 Displacement 60 in³ 60.6 in³ Rated Engine Speed 3200 rpm 3200 rpm Engine Power (Gross) 21.5 hp 21.5 hp PTO Power 16.2 hp 15.4 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Not Published Single dry element Fuel System Not Published Indirect injection Alternator Not Published 40 A, 12 V ▶ HydraulicsPump Type Gear Single gear pump with flow divider Implement Flow 3.5 gpm 4.17 gpm Steering Flow 3.5 gpm 2.11 gpm Total Hydraulic Flow 7 gpm 6.3 gpm Overall Hydraulic Pump Flow 7 gpm 6.97 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 5.57 gal 6.6 gal Coolant Capacity Not Published 3.7 qt Crankcase Capacity Not Published 2.1 qt Transmission / Hydraulic System Capacity Not Published 3.6 gal Front Axle Fluid Capacity Not Published 2.6 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Standard, 2100 rpm Optional, 2,500 rpm Category, 3-Point Hitch Limited Category I Category I (limited) Hitch Lift Capacity Not Published 1,100 lb Hitch Lift Capacity (at 24”) 758 lb 679 lb Lift Control Type Select control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic - 2 range Hydrostatic (HST) No. of Speeds Infinite (hydrostatic), 2 ranges forward and reverse 2 range Max Travel Speed (Forward) 9.1 mph 7.8 mph Max Travel Speed (Reverse) 9.1 mph Not Published Clutch Not Published Dry single plate Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Foldable ROPS, standard equipment Sub-compact tractor Steering Power steering Hydrostatic power steering Brakes Wet disc, left-hand pedal Wet disc Seat Suspension & Adjustability Suspension seat, high back, adjustable settings; no tilt steering Not Published Front Axle Type Four-wheel drive (mechanical front-wheel drive) Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 47.22 in (R3 tires); 47.32 in (R4 tires) 44.5 in Wheelbase 57.1 in 53.1 in Ground Clearance Not Published 8.3 in Min. Turn Radius without Brakes Not Published 86.6 in Height to Top of ROPS Not Published 86.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length Not Published 94.2 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,475 lb (shipping weight, open station) 1,433 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf, R3 Hybrid, or R4 R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front Not Published 16x7.50-9 R1 Agricultural - Rear Not Published 24x12.00-12 R3 Turf - Front 18x8.50-10 16x7.50-8 R3 Turf - Rear 26x12-12 26x12.00-12 R4 Industrial - Front 18x8.5-10 18x8.5-10 R4 Industrial - Rear 26x12-12 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System Tool-free attach and park Quick attach front loader Loader Model 120R BBL100 Loader Lift Height 120R: 72 in 78.5 in (at pivot pin) Loader Lift Capacity (Full Height) 120R (NSL): 704 lb (at pivot, full height) 617 lb (at pivot pin) Loader Breakout Force Not Published 1,253 lbf ▶ WarrantyWarranty Length & Coverage Powertrain 6 years or 2,000 hours, standard at no cost, covers residential and commercial use Basic 24 months or 1,000 hours; powertrain 84 months or 2,000 hours; loader and backhoe 24 months from shipment, 12 months from sale, or 500 hours
