▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNM74F-NCJT 3TNV80F-CJT Engine Type Diesel 3-cylinder, liquid-cooled diesel No. of Cylinders 3 3 Displacement 60.6 in³ 77.3 in³ Rated Engine Speed 3200 rpm 3200 rpm Engine Power (Gross) 21.5 hp 23.9 hp PTO Power 16.2 hp 18 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Dry with safety element Fuel System Not Published Indirect injection Alternator Not Published 40 A, 12 V ▶ HydraulicsPump Type Gear Gear Implement Flow 3.5 gpm 3.5 gpm Steering Flow 3.5 gpm 3.5 gpm Total Hydraulic Flow 7 gpm 7 gpm Overall Hydraulic Pump Flow 7 gpm 7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 3.5 gpm per pump (implement circuit); total system output 6.3 gpm No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Three ▶ Fluid CapacityFuel Tank Capacity 5.57 gal 5.6 gal Coolant Capacity Not Published 3.9 qt Crankcase Capacity Not Published 2.9 qt Transmission / Hydraulic System Capacity Not Published 3.25 gal Front Axle Fluid Capacity Not Published 3.0 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Standard, 2100 rpm Standard, 2100 rpm Category, 3-Point Hitch Limited Category 1 Limited Category 1 Hitch Lift Capacity Not Published 1177 lb Hitch Lift Capacity (at 24”) 758 lb 758 lb Lift Control Type Select control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic - 2 range Hydrostatic - 2 range No. of Speeds Infinite (hydrostatic), 2 ranges forward and reverse Infinite (hydrostatic), 2 ranges forward and reverse Max Travel Speed (Forward) 9.1 mph 9.1 mph Max Travel Speed (Reverse) 9.1 mph 9.1 mph Clutch Not Published wet disc Differential Lock & Limited Slip Options Not Published Standard rear differential lock ▶ Chassis, Steering & ControlsFrame Type Foldable ROPS, standard equipment Semi-flat platform; two-post folding ROPS; 4WD with mechanical front-wheel drive Steering Power steering Power steering Brakes Wet disc, left-hand pedal Wet disk, left-hand pedal Seat Suspension & Adjustability Deluxe suspension seat with high back and adjustable settings; no tilt steering Premium seat; adjusts fore/aft; seat flips forward; high seat back and armrests; retractable seat belt Front Axle Type Four-wheel drive (mechanical front-wheel drive) Four-wheel drive (mechanical front-wheel drive, on-the-go engagement) Front Axle Rating Not Published 1349 lb Drawbar Capacity Not Published 2165 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch Not Published 108 in Overall Width 47.22 in (R3 tires); 47.32 in (R4 tires) 47.22 in (R3 tires); 47.32 in (R4 tires) Wheelbase 57.1 in 57.1 in Ground Clearance Not Published 9.0 in under the front axle (operator's manual); 7.7 in (Deere website) Min. Turn Radius without Brakes Not Published 88.8 in Height to Top of ROPS Not Published 90 in Height to Top of ROPS (folded) Not Published 73 in Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) Approx. 1,475 lb (shipping weight, open station) 1444 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf, R3 Hybrid, or R4 Industrial Standard R4, optional R3 R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front 18x8.50-10 18x8.5-10 R3 Turf - Rear 26x12-12 26x12-12 R4 Industrial - Front 18x8.5-10 18x8.5-10 R4 Industrial - Rear 26x12-12 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System Quik-Park Quik-Park (MSL option on 120R) Loader Model 120R 120R (NSL or MSL) or 120E (D120 and H120 on earlier units) Loader Lift Height 120R: 72 in 120R (NSL and MSL): 72 in; 120E: 71.2 in; D120 and H120: 71.2 in Loader Lift Capacity (Full Height) 120R (NSL): 704 lb 120R NSL: 752 lb (49 in bucket) or 704 lb (53 in bucket); 120R MSL: 548 lb (53 in bucket); D120: 825 lb; H120: 836 lb (all at pivot pin, max height) Loader Breakout Force 1823 lbf (at pivot pin) 120R NSL: 2008 lbf (49 in bucket) or 1816 lbf (53 in bucket); 120R MSL: 1591 lbf; D120: 1808 lbf; H120: 1819 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-Year / 2,000 Hour Limited Powertrain Warranty; standard at no cost, covers residential and commercial use 6-Year / 2,000 Hour Limited Powertrain Warranty; standard at no cost, covers residential and commercial use
