▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNE74 3TNV80F-CJT Engine Type 3-cylinder liquid-cooled diesel, indirect injection 3-cylinder, liquid-cooled diesel No. of Cylinders 3 3 Displacement 61.4 in³ 77.3 in³ Rated Engine Speed 3000 rpm 3200 rpm Engine Power (Gross) 23 hp 23.9 hp PTO Power 17.7 hp 18 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry type with safety element Dry with safety element Fuel System Indirect injection, in-line fuel pump with solenoid shutoff Indirect injection Alternator 20 A 40 A, 12 V ▶ HydraulicsPump Type Not Published Gear Implement Flow 3 gpm 3.3 gpm Steering Flow 2.5 gpm 3.3 gpm Total Hydraulic Flow 5.5 gpm 6.5 gpm Overall Hydraulic Pump Flow 5.5 gpm 6.5 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published 3.5 gpm per pump (implement circuit); total system output 6.3 gpm No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Three ▶ Fluid CapacityFuel Tank Capacity 5.0 gal 5.6 gal Coolant Capacity 3.2 qt 3.9 qt Crankcase Capacity 2.2 qt 2.9 qt Transmission / Hydraulic System Capacity 3.4 gal 3.25 gal Front Axle Fluid Capacity 2.6 qt 3.0 qt ▶ PTO & HitchPTO Type Independent, wet disk clutch Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Standard, 2100 rpm Standard, 2100 rpm Category, 3-Point Hitch Category 1 Limited Category I Hitch Lift Capacity Not Published 1177 lb Hitch Lift Capacity (at 24”) 701 lb 758 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic Hydrostatic - 2 range No. of Speeds Infinite forward and reverse, 2 ranges Infinite (hydrostatic), 2 ranges forward and reverse Max Travel Speed (Forward) 8.4 mph 9.1 mph Max Travel Speed (Reverse) 6.3 mph 9.1 mph Clutch Not Published wet disc Differential Lock & Limited Slip Options Not Published Standard rear differential lock ▶ Chassis, Steering & ControlsFrame Type Two-post fixed ROPS; four-wheel drive Semi-flat platform; two-post folding ROPS; 4WD with mechanical front-wheel drive Steering Power steering Power steering Brakes Wet disk Wet disk, left-hand pedal Seat Suspension & Adjustability Not Published Premium seat; adjusts fore/aft; seat flips forward; high seat back and armrests; retractable seat belt Front Axle Type Mechanical front wheel drive (MFWD), standard, all ranges, engages on the go Four-wheel drive (mechanical front-wheel drive, on-the-go engagement) Front Axle Rating 3120 lb 1349 lb Drawbar Capacity 562 lb 2165 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 104.3 in 108 in Overall Width 47.2 in 47.22 in (R3 tires); 47.32 in (R4 tires) Wheelbase 57.1 in 57.1 in Ground Clearance 7.7 in (front axle) 9.0 in under the front axle (operator's manual); 7.7 in (Deere website) Min. Turn Radius without Brakes 88.6 in (MFWD off) 88.8 in Height to Top of ROPS 77.6 in 90 in Height to Top of ROPS (folded) Not Published 73 in Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1400 lb 1444 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 18x8.5-10 front and 26x12.00-12 rear; R1 standard, R3 optional Standard R4, optional R3 R1 Agricultural - Front 18x8.5-10 Not Published R1 Agricultural - Rear 26x12.00-12 Not Published R3 Turf - Front 18x8.5-10 18x8.5-10 R3 Turf - Rear 26x12.00-12 26x12-12 R4 Industrial - Front 18x8.50-10 18x8.5-10 R4 Industrial - Rear 26x12.00-12 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quik-Park (MSL option on 120R) Loader Model 210 120R (NSL or MSL) or 120E (D120 and H120 on earlier units) Loader Lift Height 210: 68.5 in 120R (NSL and MSL): 72 in; 120E: 71.2 in; D120 and H120: 71.2 in Loader Lift Capacity (Full Height) 210: 622 lb (to max height at pivot point) 120R NSL: 752 lb (49 in bucket) or 704 lb (53 in bucket); 120R MSL: 548 lb (53 in bucket); D120: 825 lb; H120: 836 lb (all at pivot pin, max height) Loader Breakout Force 210: 1577 lbf (at pivot point) 120R NSL: 2008 lbf (49 in bucket) or 1816 lbf (53 in bucket); 120R MSL: 1591 lbf; D120: 1808 lbf; H120: 1819 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published 6-Year / 2,000 Hour Limited Powertrain Warranty; standard at no cost, covers residential and commercial use
