▶ EngineEngine Manufacturer Yanmar Kubota Engine Model 3TNE74 D1005 Engine Type 3-cylinder liquid-cooled diesel, indirect injection Liquid-cooled, 4-cycle diesel No. of Cylinders 3 3 Displacement 61.4 in³ 61.1 in³ Rated Engine Speed 3000 rpm 3200 rpm Engine Power (Gross) 23 hp 23.3 hp PTO Power 17.7 hp 19.2 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Water with pressurized radiator, reverse air-flow design Air Cleaner Dry type with safety element Dry element Fuel System Indirect injection, in-line fuel pump with solenoid shutoff Direct injection Alternator 20 A 40 A, 12 V ▶ HydraulicsPump Type Not Published Open center tandem pump gear type Implement Flow 3 gpm 5.2 gpm Steering Flow 2.5 gpm 1.0 gpm Total Hydraulic Flow 5.5 gpm 6.2 gpm Overall Hydraulic Pump Flow 5.5 gpm 6.2 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None (2-valve rear remote coupler optional) No. of Optional Remote Valves Not Published 2 (optional; ISO 7241-1 series A or B) ▶ Fluid CapacityFuel Tank Capacity 5.0 gal 6.6 gal Coolant Capacity 3.2 qt 3.5 qt Crankcase Capacity 2.2 qt 4.2 qt Transmission / Hydraulic System Capacity 3.4 gal 3.0 gal Front Axle Fluid Capacity 2.6 qt 3.8 qt ▶ PTO & HitchPTO Type Independent, wet disk clutch Live independent PTO (with hydraulic clutch) PTO Rear 540 rpm STD (540 rpm) Mid-PTO Availability Standard, 2100 rpm STD (2500 rpm) Category, 3-Point Hitch Category 1 SAE Category I Hitch Lift Capacity Not Published 1,213 lb Hitch Lift Capacity (at 24”) 701 lb 680 lb Lift Control Type Not Published Quarter-inching valve ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic Hydrostatic transmission No. of Speeds Infinite forward and reverse, 2 ranges 2 Range (Low-High) Max Travel Speed (Forward) 8.4 mph 8.4 mph Max Travel Speed (Reverse) 6.3 mph 6.5 mph Clutch Not Published None (HST) Differential Lock & Limited Slip Options Not Published Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Two-post fixed ROPS; four-wheel drive Two-post foldable ROPS Steering Power steering Hydrostatic type power steering Brakes Wet disk Mechanical, wet disc type Seat Suspension & Adjustability Not Published High-back seat with armrests; fore/aft slide and backrest-tilt adjustment Front Axle Type MFWD, standard, all ranges, on-the-go engagement 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating 3,120 lb Not Published Drawbar Capacity Not Published Max. drawbar load @ hitch: 550 lb ▶ Dimensions & ManeuverabilityOverall Width 47.2 in 45.1 in Wheelbase 57.1 in 55.1 in Ground Clearance 7.7 in (front axle) 6.5 in Min. Turn Radius without Brakes 88.6 in (MFWD off) 7.5 ft Height to Top of ROPS 77.6 in 83.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 104.3 in (with 3-point hitch) 95.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,400 lb (with all fluids) 1,521 lb (with ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 18x8.5-10 front and 26x12.00-12 rear; R1 standard, R3 optional R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 18x8.5-10 18X8.5-10 R1 Agricultural - Rear 26x12.00-12 26X12-12 R3 Turf - Front 18x8.5-10 18X8.5-10 R3 Turf - Rear 26x12.00-12 26X12-12 R4 Industrial - Front 18x8.50-10 18X8.5-10 R4 Industrial - Rear 26x12.00-12 26X12-12 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Swift-Tach Loader (LA344S - Two Lever Quick Attach Bucket) Loader Model 210 LA344S (standard, quick attach); LA344 (pin-on option) Loader Lift Height 210: 68.5 in (at pivot pin) 71.0 in (at pivot pin) Loader Lift Capacity (Full Height) 210: 622 lb (to max height at pivot point) 739 lb (LA344 pin-on); 613 lb (LA344S quick attach) Loader Breakout Force 210: 1,577 lbf (at pivot point) 1,407 lbf (LA344 pin-on); 1,286 lbf (LA344S quick attach) ▶ WarrantyWarranty Length & Coverage Not Published Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
