▶ EnginePTO Power 20.7 hp 16.2 hp Alternator 55 A, 12 V 40 A Air Cleaner Dual element Dual element Engine Type Diesel, water-cooled Diesel Fuel System Direct injection Indirect injection Displacement 100.1 in³ 60.6 in³ No. of Cylinders 3 3 Rated Engine Speed 2400 rpm 3200 rpm Cooling System Type Liquid Water pump Engine Manufacturer Yanmar Yanmar Engine Power (Gross) 24.4 hp @ 400 rpm 21.5 hp @ 200 rpm Engine Emissions Constraints Tier 4 Tier 4 ▶ WeightWeight with ROPS and Loader Not Published 1446 lb Weight with Cab and Loader Not Applicable n/a Tractor Weight (Base) n/a Open station: 1446 lb ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) 6-year powertrain warranty (as stated in 2016 review; current terms may vary) ▶ HydraulicsPump Type Single gear Single gear Steering Flow 3.6 gpm 3.5 gpm Implement Flow 4.8 gpm 3.5 gpm Total Hydraulic Flow 8.9 gpm 6.3 gpm 23.8 lpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 3.5 gpm (13.3 lpm) implement circuit Overall Hydraulic Pump Flow 8.9 gpm 6.3 gpm total (2.8 gpm steering + 3.5 gpm implement) No. of Optional Remote Valves Up to two (optional) 1 additional (optional 3rd SCV kit; standard is 2 mid-SCVs) No. of Standard Remote Valves Not Published n/a System Operating Pressure n/a 2000 PSI ▶ PTO & HitchPTO Rear 540 rpm (6-spline) 540 rpm PTO Type Not Published independent Lift Control Type Position control Position control (rockshaft lever) Hitch Lift Capacity Not Published 1,433 lbs 1,433 lb Mid-PTO Availability Not Applicable 2100 rpm Category, 3-Point Hitch Category 1 Limited Category 1 Hitch Lift Capacity (at 24”) 2,081.2 lb @ 24 in behind link arms 758 lb ▶ Tire OptionsR3 Turf - Rear 41X14-20 26x12-12 R3 Turf - Front 27X8.50-15 18x8.50-10 Tire Size & Options R1 Bar, R3 Turf, R4 Industrial n/a R4 Industrial - Rear 15.00-19.5 26x12-12 R4 Industrial - Front 25X8.50-14 18x8.5-10 R1 Agricultural - Rear 11.2-24 26x12-12 R1 Agricultural - Front 7-14 18x8.5-10 ▶ Fluid CapacityCoolant Capacity Not Published 0.98 gal Crankcase Capacity 1.1 gal 0.71 gal Fuel Tank Capacity 10.0 gal 5.6 gal Front Axle Fluid Capacity 1.0 gal 0.74 gal Transmission / Hydraulic System Capacity 9.2 gal 3.3 gal ▶ Loader & AttachmentsLoader Lift Height 84.0 in 71.2 in (D120 and H120 loaders) Loader Breakout Force 1,704 lb n/a Quick Attach Loader System Quick-change attachment carrier Quik-Park Loader System Loader Lift Capacity (Full Height) 1,186 lb D120: 570 lb; H120: 512 lb (at full height, 71.2 in) ▶ Transmission & DrivetrainClutch Not Published Wet disk No. of Speeds 8F/8R Infinite (hydrostatic, 2-range) Transmission Type 8F/8R synchromesh shuttle shift gear transmission Hydrostatic - two range Max Travel Speed (Forward) 11.1 mph 9.1 mph Max Travel Speed (Reverse) 11.6 mph 9.1 mph Differential Lock & Limited Slip Options Not Published Differential lock Yes; Limited slip differential No ▶ Chassis, Steering & ControlsBrakes Not Published Wet disc (left-hand pedal) Steering Not Published Power Frame Type Not Published Open center frame with two-post foldable ROPS Front Axle Type MFWD (4WD) MFWD (Mechanical Front-Wheel Drive) 4WD Drawbar Capacity Not Published n/a Front Axle Rating Not Published 1349 lb Seat Suspension & Adjustability Not Published Spring suspension seat, adjusts fore/aft ▶ Dimensions & ManeuverabilityWheelbase 62.6 in 57.1 in. Overall Width 57.3 in 47.2 in with R3 tires; 47.3 in with R4 tires Ground Clearance 13.0 in 7.7 in. Height to Top of ROPS Not Published 78.6 in Height to Top of Cab Model Not Applicable n/a Height to Top of ROPS (folded) Not Published n/a Min. Turn Radius without Brakes Not Published 2.51 m 8.2 ft Overall Length with 3-Point Hitch 111.2 in 87.6 in
