▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV88F-EPJPT 3TNV80F-CJT Engine Type 4-cycle, inline, water-cooled diesel, naturally aspirated 3-cylinder, liquid-cooled diesel No. of Cylinders 3 3 Displacement 100.2 in³ 77.3 in³ Rated Engine Speed 2400 rpm 3200 rpm Engine Power (Gross) 24.4 hp 23.9 hp PTO Power 20.7 hp 18 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid Liquid-cooled Air Cleaner Dry Dry with safety element Fuel System Direct injection Indirect injection Alternator 55 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type 2 single-section external gear pumps, 1 on each side of the engine timing-gear cover Gear Implement Flow 5.1 gpm 3.5 gpm Steering Flow 3.8 gpm 3.5 gpm Total Hydraulic Flow 8.5 gpm 7 gpm Overall Hydraulic Pump Flow 8.9 gpm 6.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 3.5 gpm implement circuit; total 7 gpm No. of Standard Remote Valves None Not Published No. of Optional Remote Valves Up to two (optional) Not Published ▶ Fluid CapacityFuel Tank Capacity 9.7 gal 6.3 gal Coolant Capacity 1.18 gal 3.9 qt Crankcase Capacity 1.1 gal 2.9 qt Transmission / Hydraulic System Capacity 9.24 gal 3.25 gal Front Axle Fluid Capacity 1.0 gal 3.0 qt ▶ PTO & HitchPTO Type Not Published Independent PTO Rear 540 rpm at 2400 rpm engine (rated) 540 rpm Mid-PTO Availability Not Published Standard, 2100 rpm Category, 3-Point Hitch Category I Limited Category I Hitch Lift Capacity Not Published 1,177 lb Hitch Lift Capacity (at 24”) 1,670 lb 758 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type 8F/8R gear drive transmission Hydrostatic - 2 range No. of Speeds 8F/8R Infinite (hydrostatic), 2 ranges forward and reverse Max Travel Speed (Forward) 11.1 mph 9.1 mph Max Travel Speed (Reverse) Not Published 9.1 mph Clutch Not Published wet disc Differential Lock & Limited Slip Options Not Published Standard rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Semi-flat platform; two-post folding ROPS; four-wheel drive Steering Power steering Power steering Brakes Not Published Wet disk, left-hand pedal Seat Suspension & Adjustability Not Published Deluxe suspension seat with armrests and tilt steering wheel Front Axle Type MFWD (4WD) 4WD (MFWD), on-the-go engagement Front Axle Rating Not Published 1,349 lb Drawbar Capacity 1,102 lb 2,165 lb ▶ Dimensions & ManeuverabilityOverall Width 57.3 in 47.22 in (R3 tires); 47.32 in (R4 tires) Wheelbase 62 in 57.1 in Ground Clearance 14 in 7.7 in (front axle) Min. Turn Radius without Brakes 6.9 ft (with brake applied) 7.4 ft (no brakes, no MFWD) Height to Top of ROPS Not Published 90 in (ROPS extended, R4 tires) Height to Top of ROPS (folded) Not Published 73 in Height to Top of Cab Model Not Published Not Published Overall Length 111.2 in 108 in ▶ WeightTractor Weight (Base) 2,778 lb 1,556 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial Standard R4, optional R3 R1 Agricultural - Front 7-14 Not Published R1 Agricultural - Rear 11.2-24 Not Published R3 Turf - Front 27X8.50-15 18x8.5-10 R3 Turf - Rear 41X14-20 26x12-12 R4 Industrial - Front 25X8.50-14 18x8.5-10 R4 Industrial - Rear 15-19.5 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System Quick-change attachment carrier Tool-free attach and park (MSL optional on 120R) Loader Model 300E 120R (MSL or NSL); 120E (NSL only) Loader Lift Height 84.0 in (at pivot pin) 120R: 72 in; 120E: 71.2 in Loader Lift Capacity (Full Height) 1,186 lb (at pivot pin) 120R (MSL): 680 lb; 120E (NSL): 519 lb (at 19.7 in ahead of pivot) Loader Breakout Force 1,704 lb (at pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours; powertrain 72 months or 2,000 hours Powertrain 6 years, standard at no cost, covers residential and commercial use
