▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV88F-EPJT 3TNV80F-NCJT Engine Type 4-cycle, inline, water-cooled diesel, naturally aspirated Diesel No. of Cylinders 3 3 Displacement 100.1 in³ 77.3 in³ Rated Engine Speed 2400 rpm 3200 rpm Engine Power (Gross) 24.4 hp 23.2 hp PTO Power 20.7 hp 17.8 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid Liquid-cooled Air Cleaner Dual element Not Published Fuel System Direct injection Not Published Alternator 55 A, 12 V Not Published ▶ HydraulicsPump Type Two single-section external gear pumps, one each side of engine timing-gear cover Gear Implement Flow 4.8 gpm 3.5 gpm Steering Flow 3.6 gpm 3.5 gpm Total Hydraulic Flow Not Published 7 gpm Overall Hydraulic Pump Flow 8.9 gpm 7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to two (optional) Not Published ▶ Fluid CapacityFuel Tank Capacity 10.0 gal 5.31 gal Coolant Capacity 1.2 gal Not Published Crankcase Capacity 1.1 gal Not Published Transmission / Hydraulic System Capacity 9.2 gal Not Published Front Axle Fluid Capacity 1.0 gal Not Published ▶ PTO & HitchPTO Type Not Published Independent PTO Rear 540 rpm at 2400 rpm engine (rated) 540 rpm Mid-PTO Availability Not Published Standard, 2100 rpm Category, 3-Point Hitch Category I Limited Category I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 2,081.2 lb @ 24 in behind link arms 915 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type 8F/8R synchromesh shuttle shift gear transmission Hydrostatic - 2 range No. of Speeds 8F/8R Infinite (hydrostatic), 2 ranges forward and reverse Max Travel Speed (Forward) 11.1 mph 12.3 mph Max Travel Speed (Reverse) 11.6 mph 12.3 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Foldable ROPS, standard equipment Steering Power steering Power steering Brakes Not Published Wet disc, left-hand pedal Seat Suspension & Adjustability Not Published Deluxe suspension seat with high back and adjustable settings; tilt steering Front Axle Type MFWD (4WD) Four-wheel drive Front Axle Rating Not Published Not Published Drawbar Capacity 1102 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 111.2 in Not Published Overall Width 57.3 in 47.22 in (R3 tires); 48.03 in (R4 tires) Wheelbase 62.6 in 63 in Ground Clearance 13.0 in Not Published Min. Turn Radius without Brakes 6.9 ft (with brakes) (with brake applied) Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2987 lb Approx. 1,797 lb open station; 2,242 lb cab (shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial R3 Turf, R3 Hybrid, or R4 Industrial R1 Agricultural - Front 7-14 Not Published R1 Agricultural - Rear 11.2-24 Not Published R3 Turf - Front 27X8.50-15 23x8.50-12 R3 Turf - Rear 41X14-20 12-16.5 R4 Industrial - Front 25X8.50-14 23x8.50-12 R4 Industrial - Rear 15.00-19.5 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System Quick-change attachment carrier Quik-Park Loader Model D160 120R Loader Lift Height 84.0 in 120R: 72 in Loader Lift Capacity (Full Height) 1,186 lb 120R (NSL): 803 lb Loader Breakout Force 1,704 lb 1823 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) 6-Year / 2,000 Hour Limited Powertrain Warranty; standard at no cost, covers residential and commercial use
