▶ EnginePTO Power 20.7 hp 21.7 hp Alternator 55 A, 12 V Not Published Air Cleaner Dual element Not Published Engine Type Diesel, water-cooled Liquid-cooled, diesel Fuel System Direct injection Not Published Displacement 100.1 in³ 100.5 in³ No. of Cylinders 3 3 Rated Engine Speed 2400 rpm 2600 rpm Cooling System Type Liquid Liquid-cooled Engine Manufacturer Yanmar KIOTI (Daedong) Engine Power (Gross) 24.4 hp @ 400 rpm 24.5 hp Engine Emissions Constraints Tier 4 Tier 4 ▶ WeightWeight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Applicable Not Published ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor ▶ HydraulicsPump Type Single gear Not Published Steering Flow 3.6 gpm Not Published Implement Flow 4.8 gpm Not Published Total Hydraulic Flow 8.9 gpm 11.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 8.9 gpm 11.7 gpm No. of Optional Remote Valves Up to two (optional) Not Published No. of Standard Remote Valves Not Published Not Published ▶ PTO & HitchPTO Rear 540 rpm (6-spline) 540 rpm PTO Type Not Published Live Lift Control Type Position control Position control Hitch Lift Capacity Not Published 1,631 lb (at 24 in) Mid-PTO Availability Not Applicable Optional Category, 3-Point Hitch Category 1 Category 1 Hitch Lift Capacity (at 24”) 2,081.2 lb @ 24 in behind link arms 1,631 lb ▶ Tire OptionsR3 Turf - Rear 41X14-20 41X14-20 R3 Turf - Front 27X8.50-15 28X8.5-15 Tire Size & Options R1 Bar, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R4 Industrial - Rear 15.00-19.5 15-19.5 R4 Industrial - Front 25X8.50-14 27X8.5-15 R1 Agricultural - Rear 11.2-24 11.2-24 R1 Agricultural - Front 7-14 7-16 ▶ Fluid CapacityCoolant Capacity Not Published Not Published Crankcase Capacity 1.1 gal Not Published Fuel Tank Capacity 10.0 gal 9.0 gal Front Axle Fluid Capacity 1.0 gal Not Published Transmission / Hydraulic System Capacity 9.2 gal Not Published ▶ Loader & AttachmentsLoader Lift Height 84.0 in 98.4 in Loader Breakout Force 1,704 lb 2,110 lb Quick Attach Loader System Quick-change attachment carrier Quick-attach (QA) bucket Loader Lift Capacity (Full Height) 1,186 lb 1,252 lb ▶ Transmission & DrivetrainClutch Not Published Dry dual stage No. of Speeds 8F/8R 9F/3R Transmission Type 8F/8R synchromesh shuttle shift gear transmission 9-speed gear Max Travel Speed (Forward) 11.1 mph 10.08 mph Max Travel Speed (Reverse) 11.6 mph 9.6 mph Differential Lock & Limited Slip Options Not Published Mechanical rear ▶ Chassis, Steering & ControlsBrakes Not Published Wet multi-disc Steering Not Published Hydrostatic Power Steering Frame Type Not Published Not Published Front Axle Type MFWD (4WD) 4WD Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Fully Adjustable Suspension Seat ▶ Dimensions & ManeuverabilityWheelbase 62.6 in 65.7 in Overall Width 57.3 in 55.1 in (R1); 63.1 in (R4) Ground Clearance 13.0 in 13.4 in Height to Top of ROPS Not Published 99.2 in Height to Top of Cab Model Not Applicable Not Published Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Overall Length with 3-Point Hitch 111.2 in 120.9 in ▶ ITC Company AccessoriesAccessories that fit None tagged yet
