▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV88F-EPJT2 3TNE74 Engine Type Diesel, naturally aspirated, direct injection 3-cylinder liquid-cooled diesel, indirect injection No. of Cylinders 3 3 Displacement 100.2 in³ 61.4 in³ Rated Engine Speed 2400 rpm 3000 rpm Engine Power (Gross) 24.4 hp 23 hp PTO Power 19.4 hp 17.7 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water pump Liquid-cooled Air Cleaner Dry type with safety element Dry type with safety element Fuel System Direct injection Indirect injection, in-line fuel pump with solenoid shutoff Alternator 55 A, 12 V 20 A ▶ HydraulicsPump Type Implement/steering pump: tandem gear pump; hydrostatic pump: PV axial-piston pump Not Published Implement Flow 5.3 gpm 3 gpm Steering Flow 4.0 gpm 2.5 gpm Total Hydraulic Flow 9.3 gpm 5.5 gpm Overall Hydraulic Pump Flow 9.3 gpm 5.5 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 2 (optional) Not Published ▶ Fluid CapacityFuel Tank Capacity 7.5 gal 5.0 gal Coolant Capacity 5.2 qt 3.2 qt Crankcase Capacity 4.5 qt 2.2 qt Transmission / Hydraulic System Capacity 5.5 gal 3.4 gal Front Axle Fluid Capacity 4 qt 2.6 qt ▶ PTO & HitchPTO Type Not Published Independent, wet disk clutch PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Standard, 2100 rpm Category, 3-Point Hitch Category I Category 1 Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 1,356 lb 701 lb Lift Control Type Not Published Not Published ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (HST) 2-range hydrostatic No. of Speeds Not Published Infinite forward and reverse, 2 ranges Max Travel Speed (Forward) Not Published 8.4 mph Max Travel Speed (Reverse) Not Published 6.3 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Open operator station (OOS) Two-post fixed ROPS; four-wheel drive Steering Power steering Power steering Brakes Wet disc Wet disk Seat Suspension & Adjustability Not Published Not Published Front Axle Type 4WD (MFWD) MFWD, standard, all ranges, on-the-go engagement Front Axle Rating 1,760 lb 3,120 lb Drawbar Capacity 880 lb (maximum vertical load) Not Published ▶ Dimensions & ManeuverabilityOverall Width 56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires) 47.2 in Wheelbase 62.8 in 57.1 in Ground Clearance 12.7 in (R4 tires) 7.7 in (front axle) Min. Turn Radius without Brakes Not Published 88.6 in (MFWD off) Height to Top of ROPS 95.3 in 77.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 115.9 in (with 3-point hitch) 104.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,222 lb 1,400 lb (with all fluids) Weight with ROPS and Loader 2,972 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial 18x8.5-10 front and 26x12.00-12 rear; R1 standard, R3 optional R1 Agricultural - Front 7-14 18x8.5-10 R1 Agricultural - Rear 11.2-24 26x12.00-12 R3 Turf - Front 27X8.50-15 18x8.5-10 R3 Turf - Rear 41X14-20 26x12.00-12 R4 Industrial - Front 25X8.50-14 or 27X8.50-15 18x8.50-10 R4 Industrial - Rear 15-19.5 or 43x16-20 26x12.00-12 ▶ Loader & AttachmentsQuick Attach Loader System Quick-change attachment carrier Not Published Loader Model 300E 210 Loader Lift Height 84 in (at pivot pin) 210: 68.5 in (at pivot pin) Loader Lift Capacity (Full Height) 1,186 lb (at pivot pin) 210: 622 lb (to max height at pivot point) Loader Breakout Force 1,704 lb (at pivot pin) 210: 1,577 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours; powertrain 72 months or 2,000 hours Not Published
