▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV88F-EPJT2 3TNV88F-EPJPT Engine Type Diesel, naturally aspirated, direct injection 4-cycle, inline, water-cooled diesel, naturally aspirated No. of Cylinders 3 3 Displacement 100.2 in³ 100.2 in³ Rated Engine Speed 2400 rpm 2400 rpm Engine Power (Gross) 24.4 hp 24.4 hp PTO Power 19.4 hp 20.7 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water pump Liquid Air Cleaner Dry type with safety element Dry Fuel System Direct injection Direct injection Alternator 55 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Implement/steering pump: tandem gear pump; hydrostatic pump: PV axial-piston pump 2 single-section external gear pumps, 1 on each side of the engine timing-gear cover Implement Flow 5.3 gpm 5.1 gpm Steering Flow 4.0 gpm 3.8 gpm Total Hydraulic Flow 9.3 gpm 8.5 gpm Overall Hydraulic Pump Flow 9.3 gpm 8.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None No. of Optional Remote Valves Up to 2 (optional) Up to two (optional) ▶ Fluid CapacityFuel Tank Capacity 7.5 gal 9.7 gal Coolant Capacity 5.2 qt 1.18 gal Crankcase Capacity 4.5 qt 1.1 gal Transmission / Hydraulic System Capacity 5.5 gal 9.24 gal Front Axle Fluid Capacity 4 qt 1.0 gal ▶ PTO & HitchPTO Type Not Published Not Published PTO Rear 540 rpm 540 rpm at 2400 rpm engine (rated) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 1,356 lb 1,670 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (HST) 8F/8R gear drive transmission No. of Speeds Not Published 8F/8R Max Travel Speed (Forward) Not Published 11.1 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Open operator station (OOS) Not Published Steering Power steering Power steering Brakes Wet disc Not Published Seat Suspension & Adjustability Not Published Not Published Front Axle Type 4WD (MFWD) MFWD (4WD) Front Axle Rating 1,760 lb Not Published Drawbar Capacity 880 lb (maximum vertical load) 1,102 lb ▶ Dimensions & ManeuverabilityOverall Width 56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires) 57.3 in Wheelbase 62.8 in 62 in Ground Clearance 12.7 in (R4 tires) 14 in Min. Turn Radius without Brakes Not Published 6.9 ft (with brake applied) Height to Top of ROPS 95.3 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 115.9 in (with 3-point hitch) 111.2 in ▶ WeightTractor Weight (Base) 2,222 lb 2,778 lb Weight with ROPS and Loader 2,972 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 7-14 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 27X8.50-15 27X8.50-15 R3 Turf - Rear 41X14-20 41X14-20 R4 Industrial - Front 25X8.50-14 or 27X8.50-15 25X8.50-14 R4 Industrial - Rear 15-19.5 or 43x16-20 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Quick-change attachment carrier Quick-change attachment carrier Loader Model 300E 300E Loader Lift Height 84 in (at pivot pin) 84.0 in (at pivot pin) Loader Lift Capacity (Full Height) 1,186 lb (at pivot pin) 1,186 lb (at pivot pin) Loader Breakout Force 1,704 lb (at pivot pin) 1,704 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours; powertrain 72 months or 2,000 hours Basic 24 months or 2,000 hours; powertrain 72 months or 2,000 hours
