▶ EnginePTO Power 30.4 hp 30 hp Alternator 55 A, 12 V 50 A, 12 V Air Cleaner Dual element Not Published Engine Type Liquid-cooled diesel, naturally aspirated, 3 Cylinder, Water-Cooled, Diesel Fuel System High pressure common rail direct injection Diesel fuel Displacement 100.1 in³ 104.7 in³ No. of Cylinders 3 3 Rated Engine Speed 2800 rpm 2600 rpm Cooling System Type Liquid Water cooled Engine Manufacturer Yanmar A1700N4-BUTC_4 Engine Power (Gross) 34.2 hp 34.9 hp Engine Emissions Constraints Tier 4 EPA Final Tier4 ▶ WeightWeight with ROPS and Loader Not Published 3163 lbs Weight with Cab and Loader Not Applicable 3,728 lbs Tractor Weight (Base) — 3,496.5 lb (3,497 lbs) for ROPS MODEL; 3,728 lb (3,728 lbs) for CABIN MODEL ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) 6-year powertrain warranty ▶ HydraulicsPump Type Single gear Not Published Steering Flow 4.4 gpm 4.4 gpm Implement Flow 5.9 gpm 8.2 gpm Total Hydraulic Flow 10.3 gpm 12.6 gpm (4.4+8.2) Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 10.3 gpm 12.6 gpm No. of Optional Remote Valves Up to two (optional) Optional (up to 2) No. of Standard Remote Valves Not Published Not Published System Operating Pressure — 180 - 407.9 lbf/cm² for control valve ▶ PTO & HitchPTO Rear 540 rpm at 2400 rpm engine 540 RPM PTO Type Mechanical control; transmission clutch; wet disk brake (mid/rear PTO) Independent Lift Control Type Position control Position Control Hitch Lift Capacity Not Published 3,306.9 lb Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category 1 Cat 1 Hitch Lift Capacity (at 24”) 2081.2 lb 2,425 lb ▶ Tire OptionsR3 Turf - Rear 41X14-20 Not Published R3 Turf - Front 27X8.5-15 Not Published Tire Size & Options R1 Bar, R3 Turf, R4 Industrial Std (manual): 8.0-16 / 12.4-24; IND (website): 28X8.50-15 / 43X16.00-20 R4 Industrial - Rear 15-19.5 43X16.00-20 R4 Industrial - Front 25X8.5-14 28X8.50-15 R1 Agricultural - Rear 11.2-24 12.4-24 6PR R1 Agricultural - Front 7-14 8.0-16 4PR ▶ Fluid CapacityCoolant Capacity 1.2 gal 1.32 gal Crankcase Capacity 1.1 gal 1.14 gal Fuel Tank Capacity 10.0 gal 7.13 gal Front Axle Fluid Capacity 1.0 gal Not Published Transmission / Hydraulic System Capacity 9.2 gal 9.77 u.s. gal (37 ℓ) HST ▶ Loader & AttachmentsLoader Lift Height 84.0 in 104 in Loader Breakout Force 1,704 lb 3,660 lb Quick Attach Loader System Quick-change attachment carrier SSQA Loader Lift Capacity (Full Height) 1,186 lb 2,200 lb (at pivot pin) ▶ Transmission & DrivetrainClutch Single dry traction clutch None (HST) No. of Speeds 8F/8R 3 Range Transmission Type 8F/8R synchromesh shuttle shift gear transmission HST (3-range) Max Travel Speed (Forward) Not Published 19.08 mph (range C) Max Travel Speed (Reverse) Not Published 19.08 mph (range C) Differential Lock & Limited Slip Options Differential lock: Yes; limited slip: Not Published Differential lock ▶ Chassis, Steering & ControlsBrakes Wet disk Wet multi-disc Steering Power steering Fully hydraulic power steering Frame Type Not Published Not Published Front Axle Type MFWD (4WD) Cast Iron Drawbar Capacity Not Published Not Published Front Axle Rating 1940 lb Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 62 in 65.7 in Overall Width 57.3 in [at 44.5 in rear tread] 56.7 in Ground Clearance 13.0 in minimum 15 in Height to Top of ROPS Not Published 96.85 in Height to Top of Cab Model Not Applicable Not Applicable Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Overall Length with 3-Point Hitch Not Published 134.88 in Overall Length — 134.88 in. ▶ ITC Company AccessoriesAccessories that fit None tagged yet
