▶ EngineEngine Manufacturer Yanmar FPT Engine Model 4TNV86CHT-MJT S8000 Engine Type Turbocharged 4-cylinder Diesel 3-cylinder, Tier 4 B/Final, FPT turbocharged & aftercooled No. of Cylinders 4 3 Displacement 127.6 in³ 178.8 in³ Rated Engine Speed 2600 rpm 2300 rpm Engine Power (Gross) 65 hp 64 hp PTO Power 57 hp 50 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dual element (dry type with safety element) Not Published Fuel System High-pressure common rail direct injection Electronic high pressure common rail Alternator 75 A, 12 V 120 A ▶ HydraulicsPump Type Dual Independent Fixed displacement Implement Flow 10.2 gpm 12.6 gpm Steering Flow 5.7 gpm Not Published Total Hydraulic Flow 15.9 gpm 12.6 gpm Overall Hydraulic Pump Flow 15.9 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 2 No. of Optional Remote Valves 3rd, 4th, and 5th optional (up to 5 total) 3 ▶ Fluid CapacityFuel Tank Capacity 13 gal 21.7 gal Coolant Capacity 1.5 gal Not Published Crankcase Capacity 1.4 gal (with filter) Not Published Transmission / Hydraulic System Capacity 12.5 gal Not Published Front Axle Fluid Capacity 5.3 qt Not Published ▶ PTO & HitchPTO Type Independent, 540 rpm (wet disc clutch) Independent PTO Rear 540 rpm 540 (standard); 540/540E (optional) Mid-PTO Availability No mid-PTO offered Not Published Category, 3-Point Hitch Category I Category I/II Hitch Lift Capacity 3,130 lb 5,952 lb (optional hitch 6,614 lb) Hitch Lift Capacity (at 24”) 2,500 lb 4,300 lb (optional hitch 4,740 lb) Lift Control Type Position control Mechanical Draft Control (MDC), top link sensing ▶ Transmission & DrivetrainTransmission Type Standard: 12F/12R PowrReverser; Optional: eHydro (3-range hydrostatic) MFD: 12x12 power shuttle (wet clutch); 2WD: 8x8 mechanical shuttle (dry clutch); optional 12x12 mechanical shuttle (dry clutch) or 12x12 with creeper (20x20) No. of Speeds Infinitely-variable, 3 range MFD: 12F/12R; 2WD: 8F/8R; optional 12F/12R mechanical or 20F/20R creeper Max Travel Speed (Forward) 18.6 mph 18.6 mph Max Travel Speed (Reverse) 18.6 mph Not Published Clutch Wet disc (PowrReverser); n/a (eHydro) MFD: wet clutch (12x12 power shuttle); 2WD: dry clutch (8x8 mechanical shuttle) Differential Lock & Limited Slip Options Differential lock Mechanical rear differential lock; MFD engagement electrohydraulic; limited-slip MFD front axle ▶ Chassis, Steering & ControlsFrame Type ROPS - Foldable Not Published Steering Power Hydrostatic Brakes Wet disc Wet disc Seat Suspension & Adjustability Adjustable vinyl seat with retractable seat belt; optional premium seat kit with mechanical suspension base Mechanical contoured seat, adjustable; optional air-suspension seat Front Axle Type Mechanical front wheel drive (MFWD) - Standard 2WD or MFD with limited slip Front Axle Rating (Continuous) 3,307 lb Not Published Drawbar Capacity Max vertical load 1,103 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 78.2 in Not Published Wheelbase 73.0 in 2WD: 82.1 in; MFD: 83.6 in Ground Clearance Front axle: 15.6 in Not Published Min. Turn Radius without Brakes 17.1 ft Not Published Height to Top of ROPS 100.2 in Not Applicable Height to Top of ROPS (folded) 80.5 in Not Published Height to Top of Cab Model Not Published 2WD: 98 in; MFD: 100 in Overall Length 130.6 in (with 3-point hitch) 155.3 in ▶ WeightTractor Weight (Base) 3,770 lb (operating weight) 2WD Cab: 6,173 lb; MFD Cab: 6,834 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial R-1 (ag tread) bias ply standard; optional R-1W (ag tread) radial R1 Agricultural - Front 8-16 (6PR) 2WD: 9.5L-15; MFD: 11.2x24 R1 Agricultural - Rear 13.6-28 2WD: 16.9R28; MFD: 16.9x30 (optional 16.9R28) R3 Turf - Front 27X10.50-15 Not Published R3 Turf - Rear 44X18.00-20 (4PR) Not Published R4 Industrial - Front 10-16.5 (6PR) Not Published R4 Industrial - Rear 16.9-24 (6PR) Not Published ▶ Loader & AttachmentsQuick Attach Loader System Quik-Park easy-to-attach/detach loader Not Published Loader Model 400E L610 Loader Lift Height 400E: 112 in (to pivot pin) 120 in Loader Lift Capacity (Full Height) 400E: 2,396 lb (at pivot, full height) NSL: 1,828 lb; MSL: 3,153 lb Loader Breakout Force 400E: 3,853 lbf at pivot; 2,902 lbf at 500 mm forward of pivot Not Published ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours; powertrain 72 months or 2,000 hours Not Published
