▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNE84 3TNV88C-KJPT Engine Type 3-cylinder liquid-cooled diesel, direct injection 4-cycle, inline, water-cooled diesel, naturally aspirated No. of Cylinders 3 3 Displacement 91.3 in³ 100.2 in³ Rated Engine Speed 2700 rpm 2800 rpm Engine Power (Gross) 32.2 hp 34.2 hp PTO Power 27 hp 30.4 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid Air Cleaner Dry type with safety element Dry Fuel System Direct injection, self-bleeding in-line fuel pump, electric shutoff Direct injection Alternator 40 A 55 A, 12 V ▶ HydraulicsPump Type Dual gear pump 2 single-section external gear pumps, 1 on each side of the engine timing-gear cover Implement Flow 8.3 gpm 5.9 gpm Steering Flow 5.0 gpm 4.4 gpm Total Hydraulic Flow 13.3 gpm 10.3 gpm Overall Hydraulic Pump Flow 13.3 gpm 10.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 None No. of Optional Remote Valves Not Published Up to two (optional) ▶ Fluid CapacityFuel Tank Capacity 10.0 gal 9.7 gal Coolant Capacity 6.1 qt 1.2 gal Crankcase Capacity 4.5 qt 1.1 gal Transmission / Hydraulic System Capacity 6.3 gal (gear); 6.9 gal (hydrostatic) 9.2 gal Front Axle Fluid Capacity 4.7 qt 1.0 gal ▶ PTO & HitchPTO Type Independent, wet disk clutch and brake Mechanical control; transmission clutch; wet disk brake (mid/rear PTO) PTO Rear 540 rpm 540 rpm at 2800 rpm engine (rated) Mid-PTO Availability Available, 2100 rpm Not Published Category, 3-Point Hitch Category 1 Category I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 2,200 lb 1,670 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type SyncShift 9F/3R gear (2WD and 4WD); SyncReverser 12F/12R (4WD only); hydrostatic 3-range (2WD and 4WD) 8F/8R synchromesh shuttle shift gear transmission No. of Speeds 9 forward, 3 reverse (SyncShift); 12 forward, 12 reverse (SyncReverser); infinite forward and reverse, 3 ranges (hydrostatic) 8F/8R Max Travel Speed (Forward) 15.6 mph (SyncShift); 15.6 mph (SyncReverser); 15.5 mph (hydrostatic) Not Published Max Travel Speed (Reverse) 7.7 mph (SyncShift); 15.5 mph (hydrostatic) Not Published Clutch 1 multi-disk wet clutch, 4.88 in (SyncShift); 2 multi-disk wet clutches, 4.88 in (SyncReverser) Single dry traction clutch Differential Lock & Limited Slip Options Mechanical rear differential lock Differential lock: Yes ▶ Chassis, Steering & ControlsFrame Type Standard ROPS or folding ROPS; 2WD or MFWD Not Published Steering Power steering, cylinder-assisted Power steering Brakes Wet disk Wet disk Seat Suspension & Adjustability Not Published Not Published Front Axle Type 2WD standard; MFWD optional, all ranges MFWD (4WD) Front Axle Rating 1,588 to 3,197 lb 1,940 lb Drawbar Capacity 562 lb 1,102 lb (static vertical load) ▶ Dimensions & ManeuverabilityOverall Width 50.0 in (minimum); 66.7 in (maximum) 57.3 in Wheelbase 68.0 in 62 in Ground Clearance 13.4 in (rear axle) 14 in Min. Turn Radius without Brakes Not Published 6.9 ft (with brake applied) Height to Top of ROPS 84.0 in (standard ROPS); 90.0 in (folding ROPS) Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 117 in (with 3-point hitch) 111.2 in ▶ WeightTractor Weight (Base) 2,600 lb (2WD); 2,900 lb (MFWD) 2,800 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: 5.00-15 F2 (2WD), 7.00-14 or 7.00-16 R1, 25x8.50-14 R4, 27x8.50-15 R3, 25-10.50LLx15 golf; rear: 11.2-24 or 12.4-24 R1, 11.2-24 or 41x14.00-20 R3, 15.00-19.5 R4, 41LLx18.00-16 golf R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 5.00-15 (2WD, F2); 7.00-14 or 7.00-16 (MFWD) 7-14 R1 Agricultural - Rear 11.2-24 or 12.4-24 11.2-24 R3 Turf - Front 27x8.50-15 (2WD); 7.00-14 (MFWD) 27X8.5-15 R3 Turf - Rear 41x14.00-20 or 11.2-24 41X14-20 R4 Industrial - Front 25x8.50-14 25X8.5-14 R4 Industrial - Rear 15.00-19.5 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick-change attachment carrier Loader Model 420; 430 300E Loader Lift Height 420: 87.6 in; 430: 101.4 in 84 in (at pivot pin) Loader Lift Capacity (Full Height) 420: 1,195 lb; 430: 1,258 lb (to max height at pivot point) 1,186 lb (at pivot pin) Loader Breakout Force 420: 2,693 lbf; 430: 3,299 lbf (at pivot point) 1,704 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours
