▶ EnginePTO Power 57.7 hp @ 100 rpm 60 hp Alternator 90 A 75 A, 12 V Air Cleaner Dry air cleaner Dry type with safety element Engine Type Diesel, turbocharged and air-to-air aftercooled Diesel, turbocharged and aftercooled Fuel System High Pressure Common Rail (HPCR) electronic fuel injection High pressure common-rail direct injection Displacement 177 in³ 127.6 in³ No. of Cylinders 3 4 Rated Engine Speed 2200 rpm 2600 rpm Cooling System Type Not Published Liquid-cooled Engine Manufacturer John Deere PowerTech 3029 EWR Yanmar Engine Power (Gross) 73.9 hp @ 200 rpm 74.6 hp Engine Emissions Constraints Tier 4 Tier 4 ▶ WeightWeight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) ▶ HydraulicsPump Type Tandem Gear Open center Steering Flow 6.3 gpm 6.2 gpm Implement Flow 18.4 gpm 11.2 gpm Total Hydraulic Flow 24.7 gpm 17.4 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 24.7 gpm 17.4 gpm No. of Optional Remote Valves Up to 1 additional (rear) (max 3 total) Up to 6 rear remotes available No. of Standard Remote Valves 2 (rear) Not Published ▶ PTO & HitchPTO Rear 540 @2100 engine rpm; 540E @1645 engine rpm; 1000 @2100 engine rpm (if equipped) 540 rpm @ 2600 rpm (540E optional) PTO Type Independent rear PTO (wet disc clutch, electrohydraulic activation): 540/540E standard; 1000 optional Independent (wet disc clutch); PTO brake for mid & rear PTO Lift Control Type Mechanical or electrohydraulic (draft control) Position control (draft sensing) Hitch Lift Capacity 5,305 lb @ hitch ball (standard 2.6 in cylinders); 6,114 lb optional (65 & 3 in cylinders) 3,079 lb at hitch balls Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (convertible to Category I) Limited Category 1 Hitch Lift Capacity (at 24”) 5,161 lb @ 24 in behind lift point (standard); 5,958 lb optional 2,709 lb @ 24 in behind ▶ Tire OptionsR3 Turf - Rear Not Published 44X18-20 or 22.5LL-16.1 R3 Turf - Front Not Published 27X10.5-15 or 27X12LL-15 Tire Size & Options R1 Ag / R3 Turf / R4 Industrial R1 Ag / R3 Turf / R4 Industrial / Snow R4 Industrial - Rear Not Published 16.9LX24 R4 Industrial - Front Not Published 10-16.5 R1 Agricultural - Rear Not Published 13.6-28 R1 Agricultural - Front Not Published 8-16 ▶ Fluid CapacityCoolant Capacity OOS: 3.6 gal; Cab: 4.2 gal 8.0 qt Crankcase Capacity 2.2 gal 5.7 qt (with filter) Fuel Tank Capacity Cab: 48.2 gal; OOS: 44.6 gal 14.7 gal Front Axle Fluid Capacity Differential housing (MFWD): 1.3 gal; Wheel hub (each): 0.2 gal 5.8 qt Transmission / Hydraulic System Capacity Open center: 10.4 gal; Closed center: 12.5 gal 12.5 gal ▶ Loader & AttachmentsLoader Lift Height Not Published 110 in Loader Breakout Force Not Published 3,835 lbf @ pivot Quick Attach Loader System Not Published Quick-Park Loader System; Quik-Change Attachment Carrier Loader Lift Capacity (Full Height) Not Published 2,313 lb @ pivot ▶ Transmission & DrivetrainClutch Not Published Not Applicable (hydrostatic transmission) No. of Speeds 16 forward / 16 reverse; 32 forward / 16 reverse (Hi-Lo) Infinitely variable / 3 range Transmission Type PowrReverser 16F/16R or 32F/16R Hi-Lo eHydro / 3-range hydrostatic Max Travel Speed (Forward) Not Published 18.7 mph Max Travel Speed (Reverse) Not Published 18.7 mph Differential Lock & Limited Slip Options Not Published Differential lock: Yes ▶ Chassis, Steering & ControlsBrakes Hydraulically actuated wet disc brakes Multi-plate wet disc Steering Not Published Hydrostatic power steering Frame Type Not Published Not Published Front Axle Type MFWD MFWD (4WD) Drawbar Capacity Not Published Not Published Front Axle Rating 6,613 lb max permissible front axle load 3,307 lb continuous Seat Suspension & Adjustability Not Published Air suspension with swivel seat ▶ Dimensions & ManeuverabilityWheelbase 92.5 in 73.0 in Overall Width 74.0 in (without fender extension); 85.6 in (with fender extension) 78.3 in Ground Clearance Not Published 13.8 in Height to Top of ROPS Not Published 104.3 in Height to Top of Cab Model 105.3 in 97.4 in Height to Top of ROPS (folded) Not Published 80.0 in Min. Turn Radius without Brakes 157.5 in 126.0 in Overall Length with 3-Point Hitch Cab overall length: 157.3 in 133.4 in
