▶ EngineEngine Manufacturer John Deere John Deere Engine Model PowerTech 3-cylinder (2.9 L) EWX John Deere PowerTech 3029 Engine Type Diesel, turbocharged, aftercooled Diesel, turbocharged, liquid-cooled No. of Cylinders 3 3 Displacement 177 in³ 179 in³ Rated Engine Speed 2200 rpm 2100 rpm Engine Power (Gross) 73.8 hp 67 hp PTO Power 57.7 hp @ 100 rpm 49 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled (Cool-Gard II coolant) Liquid-cooled Air Cleaner Not Published Dry type, dual element (primary and secondary) Fuel System Not Published Not Published Alternator OOS: 90 A; Cab: 120 A 40 A ▶ HydraulicsPump Type Tandem gear pump Not Published Implement Flow 18.4 gpm 11.4 gpm Steering Flow 6.3 gpm 6.8 gpm Total Hydraulic Flow 24.7 gpm 18.2 gpm Overall Hydraulic Pump Flow 24.7 gpm 18.2 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (rear); 2 (mid) 1 No. of Optional Remote Valves Up to 3 total (rear); up to 3 total (mid) 2 ▶ Fluid CapacityFuel Tank Capacity OOS: 39.2 gal; OOS (High Capacity): 47.1 gal; Cab: 43.7 gal; Cab (High Capacity): 52 gal 19.6 gal Coolant Capacity OOS: 3.6 gal; Cab: 4.2 gal 10 qt Crankcase Capacity 2.2 gal 9 qt Transmission / Hydraulic System Capacity 10.4 gal 10.3 gal Front Axle Fluid Capacity Differential housing (MFWD): 1.3 gal; Wheel hub (each): 0.2 gal Dana axle: differential housing 1.18 gal, wheel hub (each) 0.21 gal; Carraro axle: differential housing 1.03 gal, reduction gear oil (each side) 0.15 gal ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic wet disc clutch: 540/540E standard, 540/540E/1000 optional Independent; mechanical engagement (SyncShuttle); electrohydraulic engagement (PowrReverser) PTO Rear 540/540E rpm standard; 1000 rpm optional 540 rpm (540E optional with PowrReverser) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (convertible to I) Category II, convertible to I Hitch Lift Capacity 5,305 lb standard; 6,114 lb optional Not Published Hitch Lift Capacity (at 24”) 5,150 lb standard; 5,950 lb optional 3,192 lb Lift Control Type Mechanical or Electrohydraulic Position control with top link draft sensing ▶ Transmission & DrivetrainTransmission Type PowrReverser 16F/16R (base); optional 32F/16R PowrReverser Hi-Lo SyncShuttle (standard); PowrReverser (optional) No. of Speeds 16F/16R (standard PowrReverser); 32F/16R (optional PowrReverser Hi-Lo) 9F/3R (SyncShuttle); 12F/12R (PowrReverser optional) Max Travel Speed (Forward) 24 mph Not Published Max Travel Speed (Reverse) 16F/16R PowrReverser, top gear D-4: 20.5 mph (30K gearing); 23.9 mph (40K gearing), with 480/70R28 rear tires at 2200 rpm Not Published Clutch Wet Dry (SyncShuttle); wet (12F/12R PowrReverser) Differential Lock & Limited Slip Options Electrohydraulic rear differential lock Differential lock, standard; pedal-operated, mechanical ▶ Chassis, Steering & ControlsFrame Type Cast iron mid-frame Not Published Steering Not Published Power steering Brakes Hydraulically actuated wet disc brakes Hydraulic wet disc brakes Seat Suspension & Adjustability OOS: isolated mechanical seat standard (fore/aft, weight, lumbar adjust) or air suspension seat optional; Cab: mechanical seat standard or air suspension seat optional; adjustable weight range 88-330 lb Not Published Front Axle Type MFWD 2WD or MFWD Front Axle Rating 6,613 lb max permissible front axle load Not Published Drawbar Capacity Standard drawbar: 2,756 lb; 2,425 lb; 2,205 lb. Heavy-duty drawbar: 3,197 lb; 2,646 lb 1,675 lb (fully extended); 2,470 lb (short position) ▶ Dimensions & ManeuverabilityOverall Width Cab, with fender extension: 85.6 in; Cab, without fender extension: 74 in; OOS, with fender extension: 69.1 in; OOS, without fender extension: 51.7 in 57.3 in Wheelbase 92.5 in 80.7 in Ground Clearance Not Published 2WD: 18.8 in; MFWD: 13.4 in Min. Turn Radius without Brakes 13.1 ft 11.5 ft (2WD); 15.3 ft (4WD); 12.8 ft (4WD, Carraro axle) Height to Top of ROPS 102.1 in (with standard rear tires) 98.4 in Height to Top of ROPS (folded) Not Published 78.5 in Height to Top of Cab Model 102.9 in (with standard rear tires) 95.6 in Overall Length 149.5 in (including draft links) 137.8 in ▶ WeightTractor Weight (Base) 2WD OOS: 8,140 lb; 2WD Cab: 8,580 lb; MFWD OOS: 8,765 lb; MFWD Cab: 9,185 lb (approximate ship weight, less weights) 2WD: 4,634 lb; MFWD: 5,621 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front 12.4R24 (320/85R24) R1W Radial MFWD: 9.5-24; 280/85R24 (11.2R24) R1W Radial R1 Agricultural - Rear 18.4R30 (460/85R30) R1W Radial 16.9-28 R3 Turf - Front Not Published 9.5-16 (MFWD) R3 Turf - Rear Not Published 21.5L-16.1; 22.5LL-16.1 (Turf Special) R4 Industrial - Front Not Published 12.5/80-18 (MFWD) R4 Industrial - Rear Not Published 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published 520M; H240 (NSL or MSL) Loader Model 520M (4WD only); 540M NSL; 540M MSL; 540R; 600M NSL; 600M MSL H240NSL Loader Lift Height 520M: 130-132 in; 540M NSL: 137-141 in; 540M MSL: 138-141 in; 540R: 141.85 in; 600M NSL: 148.8-152.8 in; 600M MSL: 148-153 in 131 in Loader Lift Capacity (Full Height) 520M NSL: 3,335-3,612 lb; 520M MSL: 2,460-2,661 lb; 540M NSL: 2,394-2,666 lb; 540M MSL: 3,117-3,309 lb; 540R: 3,406 lb; 600M NSL: 3,104-3,236 lb; 600M MSL: 3,891-4,085 lb 3,671 lb (H240NSL, at pivot) Loader Breakout Force 540M NSL: 6,686 lbf; 540M SL: 5,513 lbf; 540R NSL: 4,945 lbf; 540R SL: 5,291 lbf; H310 NSL: 6,767 lbf (measured at pivot; H310 for MFWD tractors) 4,504 lb (H240NSL, at pivot) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
