▶ EngineEngine Manufacturer John Deere Yanmar Engine Model PowerTech 4045 PWL 4TNV86CHT-MJT Engine Type Diesel, turbocharged, air-to-air aftercooled Turbocharged 4-cylinder Diesel No. of Cylinders 4 4 Displacement 276 in³ 127.6 in³ Rated Engine Speed 2200 rpm 2600 rpm Engine Power (Gross) 89.2 hp 74.3 hp PTO Power 75 hp @ 100 rpm 60 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Cool-Gard II coolant Liquid-cooled Air Cleaner Primary and secondary air cleaner elements Dry type with electronic restriction indicator Fuel System High pressure common rail; electronic fuel control High pressure common-rail direct injection Alternator OOS: 90 A; Cab: 120 A; Field-installed option: 200 A, 12 V 75 A ▶ HydraulicsPump Type Tandem gear pump Dual Independent Implement Flow 18.4 gpm Not Published Steering Flow 6.3 gpm Not Published Total Hydraulic Flow 24.7 gpm 15.9 gpm Overall Hydraulic Pump Flow 24.7 gpm 15.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (rear, Dual SCV) Not Published No. of Optional Remote Valves Up to 1 additional rear valve (3 total with Triple SCV); up to 3 mid SCVs (XI, XII, XIII) for loader functions 3/4/5 optional ▶ Fluid CapacityFuel Tank Capacity OOS: 29.6 gal; OOS (High Capacity): 37.2 gal; Cab: 37 gal; Cab (High Capacity): 44.9 gal 14.7 gal Coolant Capacity OOS: 5.2 gal; Cab: 5.8 gal 8.0 qt Crankcase Capacity 3.4 gal 5.7 qt Transmission / Hydraulic System Capacity 10.4 gal Not Published Front Axle Fluid Capacity Differential housing (MFWD): 1.3 gal; Wheel hub (each): 0.2 gal Not Published ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic actuation: 540/540E standard, 540/540E/1000 optional Independent (wet disc clutch) PTO Rear 540/540E rpm standard; 1000 rpm optional 540 rpm Mid-PTO Availability Not Published No mid-PTO offered Category, 3-Point Hitch Category II (convertible to I) Category I Hitch Lift Capacity 5,305 lb; 6,114 lb, at hitch ball throughout lift range 3,130 lb Hitch Lift Capacity (at 24”) 5,159 lb standard; 5,954 lb optional 2,500 lb Lift Control Type Mechanical or electrohydraulic (draft control) Position control ▶ Transmission & DrivetrainTransmission Type PowrReverser 16F/16R (base); optional 32F/16R PowrReverser Hi-Lo or 12F/4R SyncShuttle Plus Standard: eHydro (3F/3R hydrostatic); Optional: 12F/12R PowrReverser No. of Speeds 16F/16R (standard PowrReverser); 12F/4R (optional SyncShuttle Plus); 32F/16R (optional PowrReverser Hi-Lo) eHydro: 3F/3R; PowrReverser: 12F/12R Max Travel Speed (Forward) 16F/16R PowrReverser, top gear (D-4): 30K config: 18.6 mph; 40K config: 21.7 mph 18.7 mph Max Travel Speed (Reverse) 16F/16R PowrReverser, top gear (D-4): 30K config: 20.5 mph; 40K config: 23.9 mph Not Published Clutch Wet Wet disc (PowrReverser); n/a (eHydro) Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock, engage on the go Yes, mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Cast iron mid-frame ComfortGard cab (standard) Steering Not Published Power steering Brakes Not Published Wet disc Seat Suspension & Adjustability OOS: isolated mechanical seat, mechanical seat, or air suspension seat (fore/aft, weight and lumbar adjustment); Cab: mechanical suspension seat or air suspension seat; adjustable weight range 88-330 lb Not Published Front Axle Type MFWD (standard); 2WD (optional) Mechanical front wheel drive (MFWD) - Standard Front Axle Rating 6,613 lb (MFWD, max permissible front axle load) 3,307 lb Drawbar Capacity Standard drawbar: 2,756 lb; 2,425 lb; 2,205 lb. Heavy-duty drawbar: 3,197 lb; 2,646 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width Cab, with fender extension: 85.6 in; Cab, without fender extension: 74 in; OOS, with fender extension: 69.1 in; OOS, without fender extension: 51.7 in 78.3 in Wheelbase 92.5 in 73 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 102.1 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 102.9 in 97.4 in Overall Length 149.5 in (including draft links) 133.4 in ▶ WeightTractor Weight (Base) 2WD, OOS: 8,140 lb; 2WD, Cab: 8,580 lb; MFWD, OOS: 8,765 lb; MFWD, Cab: 9,185 lb (shipping weight, less weights) 4,828 lb (operating weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front 12.4R24 (320/85R24) R1W Radial 8-16 (6PR) R1 Agricultural - Rear 18.4R30 (460/85R30) R1W Radial 13.6-28 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model 540M NSL; 540M SL; 540R NSL; 540R SL; H310 NSL (MFWD required for H310) 440R Loader Lift Height 540M NSL: 138 in; 540M SL: 138 in; 540R NSL: 141 in; 540R SL: 141 in; H310 NSL: 149 in Not Published Loader Lift Capacity (Full Height) 540M NSL: 3,674 lb; 540M SL: 3,058 lb; 540R NSL: 4,246 lb; 540R SL: 3,395 lb; H310 NSL: 4,644 lb (measured at pivot) 440R NSL: 2,539 lb; 440R MSL: 2,213 lb (at pivot pin, 4R Series figures) Loader Breakout Force 540M NSL: 6,686 lbf; 540M SL: 5,513 lbf; 540R NSL: 4,945 lbf; 540R SL: 5,291 lbf; H310 NSL: 6,767 lbf (measured at pivot) Not Published ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours
