▶ EngineEngine Manufacturer John Deere John Deere Engine Model John Deere PowerTech 4.5L diesel PowerTech 4045 (4.5L) PWL Engine Type 4-cylinder, turbocharged and intercooled diesel, 4-valve high pressure common rail 4-cylinder, turbocharged and aftercooled diesel, electronic fuel control No. of Cylinders 4 4 Displacement 276 in³ 276 in³ Rated Engine Speed 2200 rpm 2400 rpm Engine Power (Gross) 90 hp 90 hp PTO Power 75 hp @ 100 rpm 76.7 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry type with safety element Dry type with safety element Fuel System High pressure common rail, 4 valve, electronic fuel control High pressure common rail, electronic fuel control Alternator 200 A OOS: 90 A; Cab: 120 A ▶ HydraulicsPump Type Tandem gear pump (open center); variable axial-piston implement pump (PFC, optional) Tandem gear pump, two engine-mounted pumps Implement Flow 19.3 gpm (open center); 30.9 gpm (PFC) 15.9 gpm Steering Flow 6.3 gpm (open center) 6.6 gpm Total Hydraulic Flow 25.6 gpm (open center) 22.5 gpm Overall Hydraulic Pump Flow 25.6 gpm (open center); 30.9 gpm (PFC) 22.5 gpm Hydraulic System Type Open center (standard); closed center PFC (optional) Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 rear and 2 mid (stackable) 2 rear; 0 mid No. of Optional Remote Valves Rear: 3 (mechanical or proportional EH, optional; 4th rear by conversion kit); Mid: 3 Deluxe (mechanical or EH, optional) 3 rear; up to 3 mid ▶ Fluid CapacityFuel Tank Capacity 38 gal 25 gal (open operator station); 30 gal (cab) Coolant Capacity 4.25 gal 2.5 gal (open operator station); 3 gal (cab) Crankcase Capacity 3.1 gal 3.2 gal Transmission / Hydraulic System Capacity 11.75 gal (open center); 12.5 gal (closed center PFC) 11.5 gal Front Axle Fluid Capacity 1.3 gal (MFWD differential housing); 0.2 gal (each wheel hub) 1.3 gal (MFWD differential housing); 0.74 qt (each wheel hub) ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement, wet PTO clutch, reversible 540/1000 shaft Independent, electro-hydraulic engagement, wet PTO clutch PTO Rear 540/540E/1000 rpm 540/540E standard; 540/1000 optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (telescoping draft links with Category II balls) Category 2, convertible to Category 1 Hitch Lift Capacity 7,158 lb; 8,157 lb throughout lift range at hitch ball; 11,122 lb / 12,515 lb maximum 5,159 lb (maximum lift force at hitch ball); 3,846 lb throughout lift range Hitch Lift Capacity (at 24”) 6,975 lb; 7,868 lb throughout lift range 4,630 lb (electrohydraulic hitch) Lift Control Type Electro-hydraulic hitch with fender controls, lower-link draft sensing Electro-hydraulic hitch with electronic quick raise and lower (premium cab); top-link draft sensing ▶ Transmission & DrivetrainTransmission Type CommandQuad 16F/16R manual with electronic range and gear shifting, AutoClutch and wet traction clutch (standard); CommandQuad 16F/16R Auto, CommandQuad 16F/16R manual with creeper, or Command8 32F/16R (optional) PowrReverser 12F/12R standard; PowrReverser Hi-Lo 24F/12R optional No. of Speeds 16F/16R (CommandQuad, standard); 32F/16R (Command8, optional) 12 forward, 12 reverse (standard); 24 forward, 12 reverse (Hi-Lo) Max Travel Speed (Forward) 22.0 mph (D4, 16/16 transmission, 480/70R28 rear tires) 21.7 mph (electronically limited) Max Travel Speed (Reverse) 18.6 mph 21.7 mph (electronically limited) Clutch Wet traction clutch with AutoClutch Wet Differential Lock & Limited Slip Options Electro-hydraulic differential lock Rear differential lock ▶ Chassis, Steering & ControlsFrame Type Cab standard with air conditioning; mechanical front-wheel drive (MFWD) Foldable ROPS (open operator station); standard or premium cab; MFWD Steering Hydrostatic power steering Hydrostatic power steering Brakes Hydraulic wet disc, self-equalizing and self-adjusting, lockable turning brakes; electronic park brake Hydraulic wet disc, self-equalizing and self-adjusting, dual-stage Seat Suspension & Adjustability Not Published Mechanical seat standard; air-suspension seat optional for cab Front Axle Type MFWD, electro-hydraulic engagement, planetary final drives MFWD Front Axle Rating 7,937 lb (MFWD closed center); 7,055 lb (MFWD open center) 6,615 lb Drawbar Capacity 2,756 lb (standard drawbar, 9.8 in extended); 2,205 lb (standard, 13.8 in extended); 3,197 lb (heavy duty, 9.8 in extended); 2,646 lb (heavy duty, 13.8 in extended) 2,755 lb (standard drawbar, 9.8 in extended); 2,425 lb (standard drawbar, 350 and 15.7 in extended); 3,195 lb (heavy-duty drawbar, 9.8 in extended); 2,645 lb (heavy-duty drawbar, 350 and 15.7 in extended) ▶ Dimensions & ManeuverabilityOverall Width 87 in (with fender extension); 74 in (without fender extension); 66.9 in (narrow cab, without fender extension) 83.6 in (minimum, 16.9-30 R1 tires); 85.1 in (minimum, 18.4-30 R1 tires) Wheelbase 88.6 in 92.5 in Ground Clearance Not Published 17 in (front axle) Min. Turn Radius without Brakes Not Published 11.6 ft (MFWD) Height to Top of ROPS Not Published 101.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 106.1 in 102.4 in Overall Length 147.8 in 159.13 in ▶ WeightTractor Weight (Base) 9,811 lb (base machine weight, with all fluids) 7,275 lb (MFWD open operator station, shipping weight); 8,150 lb (MFWD cab, shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 320/85R24 (12.4R24) R1-W radial front and 460/85R30 (18.4R30) R1-W radial rear standard; optional 11.2R28/13.6R38, 380/70R20/480/70R28, 13.6R24/16.9R34, 380/70R24/480/70R34 R1; R3 44x18-20/23.1-26; R4 12.5/80-18/19.5L-24 18.4-30 R1 bias rear standard; 16.9-30 R1 also listed R1 Agricultural - Front 320/85R24 (12.4R24) R1-W radial 12.4-24 R1 Agricultural - Rear 460/85R30 (18.4R30) R1-W radial 18.4-30 R1 bias R3 Turf - Front 44x18-20 Not Published R3 Turf - Rear 23.1-26 Not Published R4 Industrial - Front 12.5/80-18 Not Published R4 Industrial - Rear 19.5L-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Global carrier in base; John Deere 500-style carrier optional (540R) Quick attach option with integrated parking stand Loader Model 540R (non self-leveling and mechanical self-leveling) 520M (NSL and MSL); 540M (NSL) Loader Lift Height 540R: 141.5 in 520M MSL: 132.0 in Loader Lift Capacity (Full Height) 540R NSL: 4,246 lb (measured at pivot) 520M MSL: 2,606 lb (to maximum height, measured at pivot) Loader Breakout Force 540R NSL: 4,945 lbf (measured at pivot) 520M NSL: 4,511 lbf; 520M MSL: 4,793 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage Not Published Powertrain 5 years or 2,000 hours, as sold new
