▶ EngineEngine Manufacturer John Deere John Deere Engine Model PowerTech 4045 EWL PowerTech 4045 (4.5L) PWL Engine Type Diesel, turbocharged with intercooler, 4-valve HPCR 4-cylinder, turbocharged and aftercooled diesel, electronic fuel control No. of Cylinders 4 4 Displacement 276 in³ 276 in³ Rated Engine Speed 2200 rpm 2400 rpm Engine Power (Gross) 128.5 hp 90 hp PTO Power 113.3 hp 76.7 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Dry type air cleaner with safety element Dry type with safety element Fuel System High-pressure common rail (HPCR), 4-valve High pressure common rail, electronic fuel control Alternator 120 A, 12 V OOS: 90 A; Cab: 120 A ▶ HydraulicsPump Type Tandem gear pump Tandem gear pump, two engine-mounted pumps Implement Flow 18.4 gpm 15.9 gpm Steering Flow 6.3 gpm 6.6 gpm Total Hydraulic Flow 25.6 gpm 22.5 gpm Overall Hydraulic Pump Flow 25.6 gpm 22.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (rear); 2 (mid) 2 rear; 0 mid No. of Optional Remote Valves Up to 3 total (rear); up to 3 total (mid) 3 rear; up to 3 mid ▶ Fluid CapacityFuel Tank Capacity 43.7 gal (Standard Cab) 25 gal (open operator station); 30 gal (cab) Coolant Capacity Not Published 2.5 gal (open operator station); 3 gal (cab) Crankcase Capacity Not Published 3.2 gal Transmission / Hydraulic System Capacity Not Published 11.5 gal Front Axle Fluid Capacity Not Published 1.3 gal (MFWD differential housing); 0.74 qt (each wheel hub) ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic clutch Independent, electro-hydraulic engagement, wet PTO clutch PTO Rear 540/540E standard; 540/540E/1000 optional 540/540E standard; 540/1000 optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (convertible to I) Category 2, convertible to Category 1 Hitch Lift Capacity Not Published 5,159 lb (maximum lift force at hitch ball); 3,846 lb throughout lift range Hitch Lift Capacity (at 24”) 6,975 lb standard; 7,868 lb optional 4,630 lb (electrohydraulic hitch) Lift Control Type Electrohydraulic Electro-hydraulic hitch with electronic quick raise and lower (premium cab); top-link draft sensing ▶ Transmission & DrivetrainTransmission Type PowrQuad PLUS 16F/16R or Powr8 32F/16R (cab only) PowrReverser 12F/12R standard; PowrReverser Hi-Lo 24F/12R optional No. of Speeds 16F/16R (PowrQuad PLUS); 32F/16R (Powr8) 12 forward, 12 reverse (standard); 24 forward, 12 reverse (Hi-Lo) Max Travel Speed (Forward) 24 mph 21.7 mph (electronically limited) Max Travel Speed (Reverse) Not Published 21.7 mph (electronically limited) Clutch Wet Wet Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock Rear differential lock ▶ Chassis, Steering & ControlsFrame Type Cast iron mid-frame design Foldable ROPS (open operator station); standard or premium cab; MFWD Steering Power steering Hydrostatic power steering Brakes Hydraulic wet disc brakes, self-equalizing and self-adjusting Hydraulic wet disc, self-equalizing and self-adjusting, dual-stage Seat Suspension & Adjustability Mechanical-suspension seat, standard; air-suspension seat, optional; heated low-frequency air-suspension seat, optional Mechanical seat standard; air-suspension seat optional for cab Front Axle Type MFWD MFWD Front Axle Rating Not Published 6,615 lb Drawbar Capacity 3,197 lb 2,755 lb (standard drawbar, 9.8 in extended); 2,425 lb (standard drawbar, 350 and 15.7 in extended); 3,195 lb (heavy-duty drawbar, 9.8 in extended); 2,645 lb (heavy-duty drawbar, 350 and 15.7 in extended) ▶ Dimensions & ManeuverabilityOverall Width Not Published 83.6 in (minimum, 16.9-30 R1 tires); 85.1 in (minimum, 18.4-30 R1 tires) Wheelbase 92.5 in 92.5 in Ground Clearance Not Published 17 in (front axle) Min. Turn Radius without Brakes 13.1 ft 11.6 ft (MFWD) Height to Top of ROPS Not Applicable 101.1 in Height to Top of ROPS (folded) Not Applicable Not Published Height to Top of Cab Model Not Published 102.4 in Overall Length Not Published 159.13 in ▶ WeightTractor Weight (Base) 9,185 lb 7,275 lb (MFWD open operator station, shipping weight); 8,150 lb (MFWD cab, shipping weight) Weight with ROPS and Loader Not Applicable Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural 18.4-30 R1 bias rear standard; 16.9-30 R1 also listed R1 Agricultural - Front 12.4R24 12.4-24 R1 Agricultural - Rear 18.4R30 18.4-30 R1 bias R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12.5/80-18 in, 12PR R4 Bias Not Published R4 Industrial - Rear 19.5L-24 in, 10PR R4 Bias Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick attach option with integrated parking stand Loader Model 520M (4WD only); 540M (NSL and MSL); 540R (NSL and MSL); 600M (NSL only) 520M (NSL and MSL); 540M (NSL) Loader Lift Height 520M: NSL/MSL 130-132 in; 540M: NSL 137-141 in, MSL 138-141 in; 540R: 141.85 in; 600M: NSL 148.8-152.8 in 520M MSL: 132.0 in Loader Lift Capacity (Full Height) 520M (4WD): NSL 3,335-3,612 lb, MSL 2,460-2,661 lb; 540M: NSL 2,394-2,666 lb, MSL 3,117-3,309 lb; 540R: 3,406 lb; 600M: NSL 3,104-3,236 lb 520M MSL: 2,606 lb (to maximum height, measured at pivot) Loader Breakout Force Not Published 520M NSL: 4,511 lbf; 520M MSL: 4,793 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, whole-machine standard agricultural equipment term Powertrain 5 years or 2,000 hours, as sold new
