▶ EngineEngine Manufacturer John Deere John Deere Engine Model CD3029DLV50 PowerTech 3029 (2.9L) EWR Engine Type 3-cylinder, naturally aspirated, direct injection, liquid-cooled diesel Diesel, turbocharged No. of Cylinders 3 3 Displacement 179 in³ 179 in³ Rated Engine Speed 2400 rpm 2100 rpm Engine Power (Gross) 53 hp 50 hp PTO Power 45 hp 38 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid cooled with overflow reservoir Air Cleaner Dry type with safety element Dry type with safety element Fuel System Direct injection, rotary injection pump, electric shutoff Electronically controlled, high-pressure common rail Alternator 40 A 70 A ▶ HydraulicsPump Type Tandem gear pump Tandem gear pump (implement + steering) Implement Flow 11.4 gpm 11.4 gpm Steering Flow 6.8 gpm 6.8 gpm Total Hydraulic Flow 18.2 gpm 18.2 gpm Overall Hydraulic Pump Flow 18.2 gpm 18.2 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow 11.4 gpm 11.4 gpm at a single rear SCV No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 18 gal (open station); 22 gal (cab) 19 gal Coolant Capacity 10 qt Not Published Crankcase Capacity 9 qt 9.0 qt (with filter) Transmission / Hydraulic System Capacity 10 gal (CollarShift and SyncShuttle, dry clutch); 11.5 gal (PowrReverser, wet clutch) Not Published Front Axle Fluid Capacity 5.3 qt (MFWD differential housing); 0.63 qt (each wheel hub) MFWD (Dana axle): 1.18 gal differential; 0.21 gal each wheel hub ▶ PTO & HitchPTO Type Fully independent 540 rpm PTO; shiftable 540/540E with SyncShuttle transmission; lever-operated clutch Independent, mechanical engagement PTO Rear 540 rpm (at 2400 engine rpm); 540E (at 1700 engine rpm, SyncShuttle) 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I and II Category II, convertible to I Hitch Lift Capacity Not Published 3,968 lb Hitch Lift Capacity (at 24”) 3,374 lb 3,192 lb Lift Control Type Position and depth control, top link draft sensing Position control, draft control, adjustable rate of drop ▶ Transmission & DrivetrainTransmission Type CollarShift standard; SyncShuttle optional; PowrReverser optional SyncShuttle No. of Speeds 9 forward, 3 reverse (CollarShift and SyncShuttle); 12 forward, 12 reverse (PowrReverser) 9F/3R Max Travel Speed (Forward) 14.98 mph (CollarShift and SyncShuttle, gear C-3); 14.89 mph (PowrReverser, gear C-4) Not Published Max Travel Speed (Reverse) 12.78 mph (CollarShift and SyncShuttle, gear C-R); 17.21 mph (PowrReverser, gear C-4 reverse) Not Published Clutch Dual dry clutch (CollarShift and SyncShuttle); multi-disk wet clutch (PowrReverser) Dry Differential Lock & Limited Slip Options Not Published Mechanical, rear ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS; cab optional; two-wheel drive or MFWD Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disk, self-equalizing, self-adjusting Hydraulically actuated wet disc brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Not Published Deluxe adjustable vinyl seat with retractable seat belt Front Axle Type Two-wheel drive or mechanical front wheel drive (MFWD) 2WD or MFWD Front Axle Rating 2,720 to 4,700 lb (2WD, by front tire, no loader); 2,760 to 4,620 lb (MFWD, by front tire, without loader) Not Published Drawbar Capacity 1,675 lb (maximum permissible static vertical load, drawbar fully extended) 1,675 lb (fully extended); 2,470 lb (short position) ▶ Dimensions & ManeuverabilityOverall Width 94.6 in (maximum) Not Published Wheelbase 80.7 in 80.7 in Ground Clearance 19 in (2WD front axle); 17 in (MFWD front axle); 14.3 in (drawbar) Not Published Min. Turn Radius without Brakes 11.3 ft (2WD); 12.5 ft (MFWD engaged); 11.3 ft (MFWD disengaged) 11.5 ft (2WD); 15.3 ft (MFWD) Height to Top of ROPS 88.7 in (extended) Not Published Height to Top of ROPS (folded) 76.7 in Not Published Height to Top of Cab Model 97 in Not Published Overall Length 122.6 in (2WD); 125.9 in (MFWD) (less drawbar and front weights) (without 3-point hitch) 144.5 in ▶ WeightTractor Weight (Base) 4,370 lb (2WD); 4,730 lb (MFWD); add 1,000 lb with cab 5,335 to 5,809 lb (shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: 6.50-16, 7.50-16, 9.5L-15, 27/9.5L-15, 11L-15 (2WD); 9.5L-16, 8.3-24, 9.5-24, 10.5/80-18, 11.2-24 (MFWD). Rear: 13.6-28, 14.9-24, 14.9-28, 16.9-24, 16.9-28, 18.4-16.1 Not Published R1 Agricultural - Front 8.3-24 (MFWD) MFWD: 9.5-24; 11.2-24; 12.4-24 R1 Agricultural - Rear 13.6-28 14.9-28 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published 520M and H240 loaders (Loader Prep Package includes loader mounting frames and hood guard); not compatible with the 512 loader Loader Model 521; 541; 541 self-leveling; 542; 542 self-leveling 500E, 500M or 520M Loader Lift Height 521: 122 in; 541: 126 in; 541 self-leveling: 130 in 500M: 124 in Loader Lift Capacity (Full Height) 521: 2,500 lb; 541: 2,500 lb; 541 self-leveling: 2,800 lb (full at pin) 500M: 3,225 lb (at pivot, full height) Loader Breakout Force 521: 3,485 lbf; 541: 3,484 lbf; 541 self-leveling: 4,125 lbf (at pin) 500M: 4,354 lb (at pivot) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
