▶ EngineEngine Manufacturer KIOTI KIOTI (Daedong) Engine Model CK3520: 3H-TM4-U; CK3520H: 3H-TH4-U; CK3520SE, CK3520SEH, CK3520SEH CAB: 3H-TM4-U2 / 3H-TH4-U2 CK3510: 3H-TM4A; CK3510 HST: 3H-TH4A Engine Type 3-cylinder, in-line, liquid-cooled diesel 3 cylinder, in-line vertical, water-cooled 4-cycle diesel, CRDI No. of Cylinders 3 3 Displacement 111.4 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 34.9 hp 34.9 hp PTO Power CK3520, CK3520SE: 30.9 hp; CK3520H, CK3520SEH, CK3520SEH CAB: 28.9 hp CK3510: 31.8 hp; CK3510 HST: 30.8 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry element Not Published Fuel System Not Published Common rail direct injection Alternator Not Published 45 A, 12 V ▶ HydraulicsPump Type Gear Gear Implement Flow CK3520, CK3520H: 7.14 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 6.86 gpm Not Published Steering Flow CK3520, CK3520H: 4.59 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 4.46 gpm Not Published Total Hydraulic Flow CK3520, CK3520H: 11.73 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 11.33 gpm 11.7 gpm Overall Hydraulic Pump Flow CK3520, CK3520H: 11.73 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 11.33 gpm 11.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves CK3520, CK3520H: 0; CK3520SE, CK3520SEH, CK3520SEH CAB: 2 0 (2 optional) No. of Optional Remote Valves CK3520, CK3520H: 2 2 (4 ports) ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 9.0 gal Coolant Capacity 0.89 gal Not Published Crankcase Capacity 1.6 gal Not Published Transmission / Hydraulic System Capacity 5.8 gal Not Published Front Axle Fluid Capacity 1.6 gal Not Published ▶ PTO & HitchPTO Type CK3520, CK3520H: Live; CK3520SE, CK3520SEH, CK3520SEH CAB: Independent Live PTO Rear 540 rpm (1-3/8 in, 6 splines) 540 rpm Mid-PTO Availability Optional, 2,000 rpm Optional, 2,000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,270 lb 1,631 lb at 24 in Hitch Lift Capacity (at 24”) 1,631 lb 1,631 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type CK3520: Manual; CK3520H, CK3520SEH, CK3520SEH CAB: Hydrostatic; CK3520SE: Synchro shuttle CK3510: Manual; CK3510 HST: Hydrostatic No. of Speeds CK3520: 9F/3R; CK3520H, CK3520SEH, CK3520SEH CAB: Infinite, 3 range; CK3520SE: 12F/12R CK3510: 9F/3R; CK3510 HST: Infinite, 3 range Max Travel Speed (Forward) CK3520: 14.64 mph; CK3520H, CK3520SEH, CK3520SEH CAB: 14.88 mph; CK3520SE: 15.53 mph CK3510: 14.62 mph; CK3510 HST: 14.85 mph Max Travel Speed (Reverse) CK3520: 9.56 mph; CK3520H, CK3520SEH, CK3520SEH CAB: 10.41 mph; CK3520SE: 15.14 mph CK3510: 9.55 mph; CK3510 HST: 13.37 mph Clutch CK3520: Dry dual stage; CK3520H, CK3520SE: Dry single stage; CK3520SEH, CK3520SEH CAB: None (hydrostatic) CK3510: Dry dual stage; CK3510 HST: Dry single stage Differential Lock & Limited Slip Options Rear differential lock (standard) Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet multi-disc Wet multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type 4WD, manual engagement 4WD, mechanical engagement (standard) Front Axle Rating Not Published Not Published Drawbar Capacity 1,433 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 120.9 in 120.9 in Overall Width 54.5 in 55.1 in Wheelbase 65.7 in 65.7 in Ground Clearance 13.4 in 13.4 in Min. Turn Radius without Brakes 107.5 in 8.0 ft (with brake applied) Height to Top of ROPS 92.9 in 99.2 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.5 in 91.7 in ▶ WeightTractor Weight (Base) CK3520: 2,679 lb; CK3520H: 2,734 lb; CK3520SE: 2,906 lb; CK3520SEH: 2,921 lb; CK3520SEH CAB: 3,397 lb CK3510: 2,679 lb; CK3510 HST: 2,734 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front AG 7-16 (Turf 28x8.5-15/6, Industrial 27x8.5-15); Rear AG 11.2-24 (Turf 41x14-20/4, Industrial 15-19.5) Front AG 7-16 (Turf 28x8.5-15/6, Industrial 27x8.5-15); Rear AG 11.2-24 (Turf 41x14-20/4, Industrial 15-19.5) R1 Agricultural - Front 7-16 7-16 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 28x8.5-15/6 28x8.5-15/6 R3 Turf - Rear 41x14-20/4 41x14-20/4 R4 Industrial - Front 27x8.5-15 27x8.5-15 R4 Industrial - Rear 15-19.5 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick attach (QA) bucket, 60 in or 66 in Loader Model KL4030; KL4030C KL4010; KL4030 Loader Lift Height 98.4 in (KL4030 and KL4030C loaders) 98.4 in (KL4010 and KL4030 loaders) Loader Lift Capacity (Full Height) KL4030: 1,835 lb; KL4030C: 1,969 lb 1,835 lb (KL4010 and KL4030 loaders) Loader Breakout Force KL4030: 3,464 lb; KL4030C: 2,989 lb 3,464 lb (KL4010 and KL4030 loaders) ▶ WarrantyWarranty Length & Coverage 24 months unlimited hours, parts and labor (non-commercial); powertrain 72 months unlimited hours, parts and labor Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor ▶ ITC Company AccessoriesAccessories that fit
