▶ EngineEngine Manufacturer KIOTI (Daedong) KIOTI Engine Model CK4010: 3H-TM4A; CK4010 HST: 3H-TH4A CK3520: 3H-TM4-U; CK3520H: 3H-TH4-U; CK3520SE, CK3520SEH, CK3520SEH CAB: 3H-TM4-U2 / 3H-TH4-U2 Engine Type 3 cylinder, in-line vertical, water-cooled 4-cycle diesel, CRDI 3-cylinder, in-line, liquid-cooled diesel No. of Cylinders 3 3 Displacement 111.4 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 39.6 hp 34.9 hp PTO Power CK4010: 34.8 hp; CK4010 HST: 33.3 hp CK3520, CK3520SE: 30.9 hp; CK3520H, CK3520SEH, CK3520SEH CAB: 28.9 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water-cooled Liquid-cooled Air Cleaner Not Published Dry element Fuel System Common rail direct injection Not Published Alternator 75 A, 12 V Not Published ▶ HydraulicsPump Type Gear Gear Implement Flow Not Published CK3520, CK3520H: 7.14 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 6.86 gpm Steering Flow Not Published CK3520, CK3520H: 4.59 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 4.46 gpm Total Hydraulic Flow 11.7 gpm CK3520, CK3520H: 11.73 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 11.33 gpm Overall Hydraulic Pump Flow 11.7 gpm CK3520, CK3520H: 11.73 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 11.33 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 (2 optional) CK3520, CK3520H: 0; CK3520SE, CK3520SEH, CK3520SEH CAB: 2 No. of Optional Remote Valves 2 (4 ports) CK3520, CK3520H: 2 ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 9.0 gal Coolant Capacity Not Published 0.89 gal Crankcase Capacity Not Published 1.6 gal Transmission / Hydraulic System Capacity Not Published 5.8 gal Front Axle Fluid Capacity Not Published 1.6 gal ▶ PTO & HitchPTO Type Live CK3520, CK3520H: Live; CK3520SE, CK3520SEH, CK3520SEH CAB: Independent PTO Rear 540 rpm 540 rpm (1-3/8 in, 6 splines) Mid-PTO Availability Optional, 2,000 rpm Optional, 2,000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,631 lb at 24 in 2,270 lb Hitch Lift Capacity (at 24”) 1,631 lb 1,631 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type CK4010: Manual; CK4010 HST: Hydrostatic CK3520: Manual; CK3520H, CK3520SEH, CK3520SEH CAB: Hydrostatic; CK3520SE: Synchro shuttle No. of Speeds CK4010: 9F/3R; CK4010 HST: Infinite, 3 range CK3520: 9F/3R; CK3520H, CK3520SEH, CK3520SEH CAB: Infinite, 3 range; CK3520SE: 12F/12R Max Travel Speed (Forward) CK4010: 14.62 mph; CK4010 HST: 14.85 mph CK3520: 14.64 mph; CK3520H, CK3520SEH, CK3520SEH CAB: 14.88 mph; CK3520SE: 15.53 mph Max Travel Speed (Reverse) CK4010: 9.55 mph; CK4010 HST: 13.37 mph CK3520: 9.56 mph; CK3520H, CK3520SEH, CK3520SEH CAB: 10.41 mph; CK3520SE: 15.14 mph Clutch CK4010: Dry dual stage; CK4010 HST: Dry single stage CK3520: Dry dual stage; CK3520H, CK3520SE: Dry single stage; CK3520SEH, CK3520SEH CAB: None (hydrostatic) Differential Lock & Limited Slip Options Rear differential lock (standard) Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet multi-disc Wet multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type 4WD, mechanical engagement (standard) 4WD, manual engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,433 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 120.9 in 120.9 in Overall Width 55.1 in 54.5 in Wheelbase 65.7 in 65.7 in Ground Clearance 13.4 in 13.4 in Min. Turn Radius without Brakes 8.0 ft (with brake applied) 107.5 in Height to Top of ROPS 99.2 in 92.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 91.7 in 92.5 in ▶ WeightTractor Weight (Base) CK4010: 2,679 lb; CK4010 HST: 2,734 lb CK3520: 2,679 lb; CK3520H: 2,734 lb; CK3520SE: 2,906 lb; CK3520SEH: 2,921 lb; CK3520SEH CAB: 3,397 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front AG 7-16 (Turf 28x8.5-15/6, Industrial 27x8.5-15); Rear AG 11.2-24 (Turf 41x14-20/4, Industrial 15-19.5) Front AG 7-16 (Turf 28x8.5-15/6, Industrial 27x8.5-15); Rear AG 11.2-24 (Turf 41x14-20/4, Industrial 15-19.5) R1 Agricultural - Front 7-16 7-16 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 28x8.5-15/6 28x8.5-15/6 R3 Turf - Rear 41x14-20/4 41x14-20/4 R4 Industrial - Front 27x8.5-15 27x8.5-15 R4 Industrial - Rear 15-19.5 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Quick attach (QA) bucket, 60 in or 66 in Not Published Loader Model KL4010; KL4030 KL4030; KL4030C Loader Lift Height 98.4 in (KL4010 and KL4030 loaders) 98.4 in (KL4030 and KL4030C loaders) Loader Lift Capacity (Full Height) 1,835 lb (KL4010 and KL4030 loaders) KL4030: 1,835 lb; KL4030C: 1,969 lb Loader Breakout Force 3,464 lb (KL4010 and KL4030 loaders) KL4030: 3,464 lb; KL4030C: 2,989 lb ▶ WarrantyWarranty Length & Coverage Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor 24 months unlimited hours, parts and labor (non-commercial); powertrain 72 months unlimited hours, parts and labor ▶ ITC Company AccessoriesAccessories that fit
