▶ EngineEngine Manufacturer KIOTI Daedong Engine Model CS2530H: 3L123-TH4C; CS2530CH: 3L123-TH4A 3C100LFH-U1 Engine Type 3-cylinder, water-cooled diesel Diesel No. of Cylinders 3 3 Displacement 75.2 in³ 61.5 in³ Rated Engine Speed 3000 rpm 3200 rpm Engine Power (Gross) 24.5 hp 24.5 hp PTO Power 19.3 hp 18.8 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Not Published Air Cleaner Not Published Not Published Fuel System Indirect injection Not Published Alternator Not Published Not Published ▶ HydraulicsPump Type Not Published Not Published Implement Flow 4.9 gpm Not Published Steering Flow 2.03 gpm Not Published Total Hydraulic Flow 6.97 gpm 7.2 gpm Overall Hydraulic Pump Flow 6.97 gpm 7.2 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None (rear hydraulics optional) No. of Optional Remote Valves Not Published 1 pair ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.7 gal Coolant Capacity 0.53 gal Not Published Crankcase Capacity 0.98 gal Not Published Transmission / Hydraulic System Capacity 2.75 gal Not Published Front Axle Fluid Capacity 0.53 gal Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Available (2,200 rpm) Standard: 2200 rpm Category, 3-Point Hitch Category I Category I Limited Hitch Lift Capacity 1,580 lb Not Published Hitch Lift Capacity (at 24”) 700 lb 700 lb Lift Control Type Position Hydraulic Position Control System ▶ Transmission & DrivetrainTransmission Type Hydrostatic (HST) 2-Range HST No. of Speeds Infinite, 2 range (High/Low) Infinite forward and reverse (2-range) Max Travel Speed (Forward) 8.99 mph 11.1 mph Max Travel Speed (Reverse) 6.15 mph 7.6 mph Clutch None (hydrostatic transmission) Not Published Differential Lock & Limited Slip Options Rear differential lock (standard) Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet disc Wet multi-disc Seat Suspension & Adjustability Not Published Adjustable seat (standard) Front Axle Type Mechanical 4WD Four-wheel drive (standard) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width CS2530H: 48.8 in; CS2530CH: 50.0 in 45.7 in (with industrial tires) Wheelbase 55.1 in 55.1 in Ground Clearance 6.4 in 6.3 in Min. Turn Radius without Brakes 100.0 in (with brake applied) 8.4 ft Height to Top of ROPS 87.6 in 87.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 82.6 in Not Published Overall Length CS2530H: 102.9 in; CS2530HC: 107.1 in (without front weight, with 3-point hitch) 99.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) CS2530H: 1,735 lb; CS2530CH: 2,403 lb 1,521 lb (operating weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R4 Industrial: 18x8.5-10 front, 26x12.00-12 rear; R3 Turf: 18x8.5-10 front, 26x12.00-12 rear Turf, Industrial, Agricultural R1 Agricultural - Front 18x8.5-10 18x8.5-10 R1 Agricultural - Rear Not Published 26x12.00-12 R3 Turf - Front 18x8.5-10 Not Published R3 Turf - Rear 26x12.00-12 Not Published R4 Industrial - Front 18x8.5-10 Not Published R4 Industrial - Rear 26x12.00-12 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Quick attach bucket, 48 in Standard quick attach mounting system Loader Model SL2530 FL6 Loader Lift Height SL2530: 70.9 in (at pivot pin) 71.9 in (to pivot pin) Loader Lift Capacity (Full Height) SL2530: 871 lb 608 lb Loader Breakout Force SL2530: 1,299 lb (at pivot pin) 1,554 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Non-commercial: basic 24 months, unlimited hours, parts and labor, 0% deductible; powertrain 6 years, unlimited hours Basic 24 months or 1,500 hours, on all components; powertrain 48 months, unlimited hours, for consumer purchasers, or 36 months or 2,000 hours for commercial purchasers
