▶ EngineEngine Manufacturer KIOTI KIOTI Engine Model CS2530H: 3L123-TH4C; CS2530CH: 3L123-TH4A 3C100LFH-U2 Engine Type 3-cylinder, water-cooled diesel In-Line Vertical, Water-Cooled Diesel (3-cylinder) No. of Cylinders 3 3 Displacement 75.2 in³ 61.5 in³ Rated Engine Speed 3000 rpm 3200 rpm Engine Power (Gross) 24.5 hp 24.5 hp PTO Power 19.3 hp 18.5 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Water-cooled Water-cooled Air Cleaner Not Published Dry type Fuel System Indirect injection Not Published Alternator Not Published Not Published ▶ HydraulicsPump Type Not Published Gear Implement Flow 4.9 gpm Not Published Steering Flow 2.03 gpm Not Published Total Hydraulic Flow 6.97 gpm 6.5 gpm Overall Hydraulic Pump Flow 6.97 gpm 6.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.7 gal Coolant Capacity 0.53 gal 1.0 gal Crankcase Capacity 0.98 gal 0.8 gal Transmission / Hydraulic System Capacity 2.75 gal 3.4 gal Front Axle Fluid Capacity 0.53 gal 0.5 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Available (2,200 rpm) Available (2,200 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,580 lb 1,580 lb Hitch Lift Capacity (at 24”) 700 lb 700 lb Lift Control Type Position Position ▶ Transmission & DrivetrainTransmission Type Hydrostatic (HST) HST (hydrostatic) No. of Speeds Infinite, 2 range (High/Low) Infinite, 2 range (High/Low) Max Travel Speed (Forward) 8.99 mph 10.3 mph Max Travel Speed (Reverse) 6.15 mph 7.0 mph Clutch None (hydrostatic transmission) None (hydrostatic transmission) Differential Lock & Limited Slip Options Rear differential lock (standard) Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet disc Wet Multi Disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Mechanical 4WD Mechanical 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width CS2530H: 48.8 in; CS2530CH: 50.0 in 46.7 in Wheelbase 55.1 in 55.1 in Ground Clearance 6.4 in 6.4 in Min. Turn Radius without Brakes 100.0 in (with brake applied) 8.2 ft (with brake applied) Height to Top of ROPS 87.6 in 87.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 82.6 in Not Published Overall Length CS2530H: 102.9 in; CS2530HC: 107.1 in (without front weight, with 3-point hitch) 99.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) CS2530H: 1,735 lb; CS2530CH: 2,403 lb 1,485 lb (with AG. tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R4 Industrial: 18x8.5-10 front, 26x12.00-12 rear; R3 Turf: 18x8.5-10 front, 26x12.00-12 rear Agricultural, Turf and Industrial: 18x8.5-10 front, 26x12.00-12 rear R1 Agricultural - Front 18x8.5-10 18x8.5-10 R1 Agricultural - Rear Not Published 26x12.00-12 R3 Turf - Front 18x8.5-10 18x8.5-10 R3 Turf - Rear 26x12.00-12 26x12.00-12 R4 Industrial - Front 18x8.5-10 18x8.5-10 R4 Industrial - Rear 26x12.00-12 26x12.00-12 ▶ Loader & AttachmentsQuick Attach Loader System Quick attach bucket, 48 in Quick attach (QA) bucket, 48 in Loader Model SL2530 SL2410 Loader Lift Height SL2530: 70.9 in (at pivot pin) SL2410: 71.3 in (at pivot pin) Loader Lift Capacity (Full Height) SL2530: 871 lb SL2410: 675 lb Loader Breakout Force SL2530: 1,299 lb (at pivot pin) SL2410: 1,332 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Non-commercial: basic 24 months, unlimited hours, parts and labor, 0% deductible; powertrain 6 years, unlimited hours Non-commercial: basic 24 months, powertrain 72 months on qualifying tractors, unlimited hours, parts and labor ▶ ITC Company AccessoriesAccessories that fit None tagged yet
