▶ EngineEngine Manufacturer KIOTI (Daedong) KIOTI Engine Model 3A165LXE CK3520, CK3520H: 3H-TM4A; CK3520SE, CK3520SEH, CK3520SEH CAB: 3H-TM4B Engine Type Not Published 3-cylinder, in-line, liquid-cooled diesel No. of Cylinders 3 3 Displacement 100.5 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 34 hp 34.9 hp PTO Power 28.3 hp CK3520, CK3520SE: 30.9 hp; CK3520H, CK3520SEH, CK3520SEH CAB: 28.9 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Not Published Liquid-cooled Air Cleaner Dual stage air filter cartridge Dry element Fuel System Not Published Not Published Alternator Not Published Not Published ▶ HydraulicsPump Type Not Published Gear Implement Flow 7.8 gpm CK3520, CK3520H: 7.14 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 6.86 gpm Steering Flow 4.7 gpm CK3520, CK3520H: 4.59 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 4.46 gpm Total Hydraulic Flow 12.5 gpm CK3520, CK3520H: 11.73 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 11.33 gpm Overall Hydraulic Pump Flow 12.5 gpm CK3520, CK3520H: 11.73 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 11.33 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 CK3520, CK3520H: None; CK3520SE, CK3520SEH, CK3520SEH CAB: 2 No. of Optional Remote Valves 1 CK3520, CK3520H: 2 ▶ Fluid CapacityFuel Tank Capacity 11.5 gal 9.0 gal Coolant Capacity Not Published 0.89 gal Crankcase Capacity Not Published 1.6 gal Transmission / Hydraulic System Capacity Not Published 5.8 gal Front Axle Fluid Capacity Not Published 1.6 gal ▶ PTO & HitchPTO Type Hydraulic independent CK3520, CK3520H: Live; CK3520SE, CK3520SEH, CK3520SEH CAB: Independent PTO Rear 540 rpm 540 rpm (1-3/8 in, 6 splines) Mid-PTO Availability Optional (2,000 rpm) Optional, 2,000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,270 lb 2,270 lb Hitch Lift Capacity (at 24”) Not Published 1,631 lb Lift Control Type Position, Draft and Mixed control Position control ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle CK3520: Manual; CK3520H, CK3520SEH, CK3520SEH CAB: Hydrostatic; CK3520SE: Synchro shuttle No. of Speeds 8F/8R (16F/16R with optional creeper gear) CK3520: 9F/3R; CK3520H, CK3520SEH, CK3520SEH CAB: Infinite, 3 range; CK3520SE: 12F/12R Max Travel Speed (Forward) 13.93 mph CK3520: 14.64 mph; CK3520H, CK3520SEH, CK3520SEH CAB: 14.88 mph; CK3520SE: 15.53 mph Max Travel Speed (Reverse) Not Published CK3520: 9.56 mph; CK3520H, CK3520SEH, CK3520SEH CAB: 10.41 mph; CK3520SE: 15.14 mph Clutch Dry single plate CK3520: dry, dual-stage; CK3520H, CK3520SE: dry, single-stage; CK3520SEH, CK3520SEH CAB: n/a (hydrostatic) Differential Lock & Limited Slip Options Rear differential lock (mechanical) Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydraulic power steering Hydrostatic power steering Brakes Wet disc Wet multi-disc Seat Suspension & Adjustability Adjustable seat Not Published Front Axle Type 4WD (MFWD) 4WD, manual engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,433 lb ▶ Dimensions & ManeuverabilityOverall Width 57.1 in 54.5 in Wheelbase 65.7 in 65.7 in Ground Clearance 11.4 in 13.4 in Min. Turn Radius without Brakes 125.9 in 107.5 in Height to Top of ROPS 92.5 in 92.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published n/a (ROPS model) Overall Length 126.3 in (with 3-point hitch) 120.87 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,475 lb (with ag tires) CK3520: 2,679 lb; CK3520H: 2,734 lb; CK3520SE: 2,906 lb; CK3520SEH: 2,921 lb; CK3520SEH CAB: 3,397 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Front AG 7-16 (Turf 28x8.5-15/6, Industrial 27x8.5-15); Rear AG 11.2-24 (Turf 41x14-20/4, Industrial 15-19.5) R1 Agricultural - Front 7-16 7-16 R1 Agricultural - Rear 12.4-24 11.2-24 R3 Turf - Front 27x8.5-15 28x8.5-15/6 R3 Turf - Rear 41x14-20 41x14-20/4 R4 Industrial - Front 27x10.5-15 27x8.5-15 R4 Industrial - Rear 43x16-20 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model KL1450 KL4030; KL4030C Loader Lift Height KL1450: 103.5 in 98.4 in (KL4030 and KL4030C loaders) Loader Lift Capacity (Full Height) KL1450: 1,350 lb (at pivot pin) KL4030: 1,835 lb; KL4030C: 1,969 lb Loader Breakout Force KL1450: 2,100 lb (at pivot pin) KL4030: 3,464 lb; KL4030C: 2,989 lb ▶ WarrantyWarranty Length & Coverage Not Published Non-commercial: basic 24 months, powertrain 72 months, unlimited hours, parts and labor ▶ ITC Company AccessoriesAccessories that fit
