▶ EngineEngine Manufacturer KIOTI (Daedong) LS Mtron Engine Model 3H-TH4D L3C19-T4 Engine Type 3-cylinder, liquid-cooled diesel 3-cylinder, turbocharged diesel, Tier 4 B/Final No. of Cylinders 3 3 Displacement 111.4 in³ 116 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 39.6 hp 40 hp PTO Power 29.1 hp 32 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Pressurized liquid cooling with recirculating bypass Air Cleaner Dry element Not Published Fuel System Not Published High pressure common rail Alternator Not Published 70 A, 12 V ▶ HydraulicsPump Type Gear Gear Implement Flow 9.62 gpm 8.2 gpm Steering Flow 6.87 gpm 5.3 gpm Total Hydraulic Flow 16.5 gpm 13.5 gpm (8.2 + 5.3, computed) Overall Hydraulic Pump Flow 16.5 gpm Not Published Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 0 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 12.7 gal 7.4 gal Coolant Capacity 2.1 gal 7.5 qt Crankcase Capacity 1.95 gal 5.8 qt Transmission / Hydraulic System Capacity 11.4 gal 8.5 gal Front Axle Fluid Capacity 1.48 gal 6.9 qt ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional (2,000 rpm) Optional, 2,000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,998 lb 1,808 lb Hitch Lift Capacity (at 24”) 2,716 lb 1,433 lb Lift Control Type Position Mechanical Draft Control (MDC) ▶ Transmission & DrivetrainTransmission Type Hydrostatic (HST) 3-range hydrostatic (optional) No. of Speeds 3 ranges (hydrostatic, infinite speeds) infinite, 3 ranges Max Travel Speed (Forward) 18.45 mph 14.8 mph Max Travel Speed (Reverse) 12.92 mph 14.96 mph Clutch None (hydrostatic transmission) Dry clutch Differential Lock & Limited Slip Options Rear differential lock (standard) Mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Wet multi-disc Wet disc, mechanical actuation Seat Suspension & Adjustability Deluxe suspension seat Adjustable suspension seat Front Axle Type Mechanical 4WD Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity 1,655 lb (max. drawbar vertical load) Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 125.5 in 145.2 in Overall Width 62.8 in 66.5 in Wheelbase 71.3 in 67.2 in Ground Clearance 14.5 in Not Published Min. Turn Radius without Brakes 102.8 in (with brake applied) 123 in Height to Top of ROPS 96.8 in 87.6 in Height to Top of ROPS (folded) Not Published 68.2 in Height to Top of Cab Model 93.0 in Not Published ▶ WeightTractor Weight (Base) 3,523 lb (DK4220SEH); 4,043 lb (DK4220SEH CAB) 3,067 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial, R14 R1 agricultural, R3 turf, or R4 industrial (R4 standard) R1 Agricultural - Front 8-16 7x14 R1 Agricultural - Rear 13.6-24 11.2x24 R3 Turf - Front 29-12.5-15 25x8.50-14 R3 Turf - Rear 21.5L-16.1 41x14.00-20 R4 Industrial - Front 10-16.5 25x8.50-14 R4 Industrial - Rear 14.9-24 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System Quick attach (QA) bucket, 66 in or 72 in Not Published Loader Model KL5520; KL5521 (Cab models) L340A Loader Lift Height KL5520: 107.7 in; KL5521: 107.7 in 98.4 in Loader Lift Capacity (Full Height) KL5520: 2,474 lb; KL5521: 2,474 lb 1,250 lb Loader Breakout Force KL5520: 3,895 lb; KL5521: 3,895 lb 1913 lb ▶ WarrantyWarranty Length & Coverage Non-commercial: 24 months, unlimited hours, parts and labor, 0% deductible; non-commercial powertrain (engine and driveline): 72 months, unlimited hours 6-year extended warranty: 2 years bumper-to-bumper plus 4 additional years of powertrain protection ▶ ITC Company AccessoriesAccessories that fit None tagged yet
