▶ EngineEngine Manufacturer KIOTI (Daedong) LS Mtron Engine Model 3H-TH4D L3C19-T4 Engine Type 3-cylinder, liquid-cooled diesel Diesel, 3-cylinder, turbocharged No. of Cylinders 3 3 Displacement 111.4 in³ 116 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 39.6 hp 40 hp PTO Power 29.1 hp 32 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Not Published Air Cleaner Dry element Replaceable dry element Fuel System Not Published Common rail direct injection Alternator Not Published 70 A ▶ HydraulicsPump Type Gear Not Published Implement Flow 9.62 gpm 8.2 gpm Steering Flow 6.87 gpm 5.3 gpm Total Hydraulic Flow 16.5 gpm 13.5 gpm (8.2 + 5.3, computed) Overall Hydraulic Pump Flow 16.5 gpm Not Published Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 12.7 gal 12.4 gal Coolant Capacity 2.1 gal Not Published Crankcase Capacity 1.95 gal Not Published Transmission / Hydraulic System Capacity 11.4 gal Not Published Front Axle Fluid Capacity 1.48 gal Not Published ▶ PTO & HitchPTO Type Independent Independent rear PTO, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional (2,000 rpm) Optional, 2000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,998 lb 1,808 lb Hitch Lift Capacity (at 24”) 2,716 lb 1,433 lb Lift Control Type Position Mechanical draft control (MDC) ▶ Transmission & DrivetrainTransmission Type Hydrostatic (HST) 3-range hydrostatic (HST) No. of Speeds 3 ranges (hydrostatic, infinite speeds) infinitely variable, 3 ranges Max Travel Speed (Forward) 18.45 mph 14.8 mph Max Travel Speed (Reverse) 12.92 mph Not Published Clutch None (hydrostatic transmission) Not Applicable Differential Lock & Limited Slip Options Rear differential lock (standard) Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Wet multi-disc Wet multi-disc Seat Suspension & Adjustability Deluxe suspension seat Deluxe cloth seat with adjustable suspension Front Axle Type Mechanical 4WD Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity 1,655 lb (max. drawbar vertical load) Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 125.5 in 128.1 in Overall Width 62.8 in 66.4 in Wheelbase 71.3 in 66 in Ground Clearance 14.5 in Not Published Min. Turn Radius without Brakes 102.8 in (with brake applied) Not Published Height to Top of ROPS 96.8 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 93.0 in 93.3 in ▶ WeightTractor Weight (Base) 3,523 lb (DK4220SEH); 4,043 lb (DK4220SEH CAB) 3,803 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial, R14 R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 8-16 Not Published R1 Agricultural - Rear 13.6-24 Not Published R3 Turf - Front 29-12.5-15 Not Published R3 Turf - Rear 21.5L-16.1 Not Published R4 Industrial - Front 10-16.5 Not Published R4 Industrial - Rear 14.9-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Quick attach (QA) bucket, 66 in or 72 in Quick-Attach faceplate; quick-connect loader mounting (L350A) Loader Model KL5520; KL5521 (Cab models) L350A Loader Lift Height KL5520: 107.7 in; KL5521: 107.7 in 105 in Loader Lift Capacity (Full Height) KL5520: 2,474 lb; KL5521: 2,474 lb 2,000 lb Loader Breakout Force KL5520: 3,895 lb; KL5521: 3,895 lb 2,640 lbf ▶ WarrantyWarranty Length & Coverage Non-commercial: 24 months, unlimited hours, parts and labor, 0% deductible; non-commercial powertrain (engine and driveline): 72 months, unlimited hours 6-year (72-month) extended warranty: 2-year bumper-to-bumper plus 4 additional years powertrain ▶ ITC Company AccessoriesAccessories that fit None tagged yet
