▶ EnginePTO Power 45.6 hp (34.0 kW) 40.8 hp (30.5 kW) (manufacturer’s estimated) Alternator Not Published 12 V, 75 A Air Cleaner Not Published Dual element (dry type with safety element) Engine Type In-Line Vertical, Water-Cooled Turbo Diesel Engine, CRDI Diesel Fuel System Common Rail Direct Injection (CRDI) High-pressure common rail direct injection Displacement 111.4 in³ (1,826 cc) 127.6 in³ (2091 cc) No. of Cylinders 3 4 Rated Engine Speed 2,600 rpm 2600 rpm Cooling System Type Water-cooled Liquid (water pump) Engine Manufacturer KIOTI (Daedong) Yanmar Engine Emissions Constraints Tier 4 Final Tier 4 Engine Power (Gross vs. Net HP) Gross: 50 hp (37.3 kW) Gross: 50.8 hp (37.9 kW) @ 2600 rpm (SAE J1995); Net: Not Published ▶ WeightTractor Weight with Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published Weight with ROPS and Loader Not Published Not Published ▶ HydraulicsPump Type Gear Single gear Steering Flow Not Published 23.5 L/min (6.2 gpm) Implement Flow Not Published 42.3 L/min (11.2 gpm) Total Hydraulic Flow 55.1 L/min (14.5 gpm) 65.8 L/min (17.4 gpm) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 55.1 L/min (14.5 gpm) 65.8 L/min (17.4 gpm) No. of Optional Remote Valves 2 Up to 6 rear remotes No. of Standard Remote Valves 0 Not Published ▶ Tire OptionsR3 Turf - Rear 21.5L-16.1 44X18.00-20 (4PR) R3 Turf - Front 29X12.5-15 27X10.50-15 Tire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Bar, R3 Turf, R4 Industrial R4 Industrial - Rear 14.9-24 420/85D24 R4 Industrial - Front 10-16.5 260/70D16.5 R1 Agricultural - Rear 13.6-24 13.6-28 (6PR) or 380/70R28 or 360/80R28 R1 Agricultural - Front 8.0-16 8.00-16 (10PR) or 280/70R16 or 250/75R16 ▶ Pto & HitchPTO Rear 540 rpm 540 rpm PTO Type Independent Independent (electrohydraulic) Lift Control Type Position Position control Hitch Lift Capacity 2,716 lbs (1,232 kg) (24 in aft. of hitch) 3,130 lb (1,420 kg) Mid-PTO Availability Not Published Available Category, 3-Point Hitch Category I Category 1 (limited) Hitch Lift Capacity (at 24”) 2,716 lbs (1,232 kg) 2,500 lb (1,134 kg) Rear 3-Point Hitch Lift Capacity 2,716 lbs (1,232 kg) (24 in aft. of hitch) 3,130 lb (1,420 kg) ▶ Fluid CapacityCoolant Capacity Not Published Open station: 6.8 qt (6.4 L); Cab: 8.0 qt (7.6 L) (if equipped) Crankcase Capacity Not Published 5.6 qt (5.3 L) (with filter) Fuel Tank Capacity 11.9 gal (45 L) Open station: 15.0 gal (56.9 L); Cab: 14.7 gal (55.6 L) (if equipped) Front Axle Fluid Capacity Not Published 5.3 qt (5.0 L) Transmission / Hydraulic System Capacity Not Published 12.5 gal (47.3 L) ▶ Loader & AttachmentsLoader Lift Height 109 in (2,768 mm) (to pivot pin) 112.1 in (2,850 mm) Loader Breakout Force 3,900 lb (1,769 kg) (at pivot pin) At pivot: 3,853 lbf (1,743.7 kgf); @ 500 mm ahead of pivot: 2,902 lbf (1,315.4 kgf) Price for Backhoe Option Not Published Not Published Price for Mid-Mount Mower Not Published Not Published Quick Attach Loader System Built-in parking stand (quick attach/detach); single-lever joystick w/ float; bucket level indicator Rigid mounted with parking kit available; Parking stand kit BW16127 (parkable) Loader Lift Capacity (Full Height) 2,660 lb (1,207 kg) (at pivot pins) At pivot: 2,396 lb (1,087 kg); @ 500 mm ahead of pivot: 1,764 lb (800 kg) ▶ Transmission & DrivetrainClutch Dry type, single stage Wet; wet clutch disk diameter 5.08 in (129 mm) No. of Speeds 8F/8R eHydro: Infinitely-variable, 3 range; PowrReverser: 12F/12R Transmission Type Synchronized H-Shuttle Standard: eHydro (eHST), 3-range hydrostatic; Optional: 12/12 PowrReverser (PRT) Max Travel Speed (Forward) 17.3 mph (27.9 km/h) 18.6 mph (30 km/h) Max Travel Speed (Reverse) 16.9 mph (27.2 km/h) 18.6 mph (30 km/h) Differential Lock & Limited Slip Options Rear differential lock (standard) Differential lock: Yes ▶ Chassis Steering & ControlsBrakes Wet multi disc Multi-plate wet disc Steering Hydrostatic power steering; tilt steering wheel Hydrostatic power steering Frame Type Not Published ROPS - Foldable Front Axle Type Mechanical 4WD Mechanical front wheel drive (MFWD) - Standard; engagement On-the-Go Drawbar Capacity Not Published Max vertical load 500 kg (1103 lb) Front Axle Rating Not Published (Continuous) 1500 kg (3307 lb) Seat Suspension & Adjustability Adjustable suspension seat Air suspension seat with swivel ▶ Dimensions & ManeuverabilityWheelbase 71.3 in (1,810 mm) 73.0 in (1,855 mm) Overall Width 62.8 in (1,596 mm) 78.2 in (1,986 mm) Ground Clearance 15.2 in (387 mm) Front axle: 15.6 in (395.1 mm); Drawbar support: 14.8 in (377 mm) Height to Top of ROPS 92.0 in (2,338 mm) 93.7 in (2,380 mm) Height to Top of Cab Model Not Published 96.3 in (2,445 mm) Height to Top of ROPS (folded) Not Published 69.5 in (1,766 mm) Min. Turn Radius without Brakes Not Published 17.1 ft (5.2 m) Overall Length with 3-Point Hitch 124.3 in (3,157 mm) 130.6 in (3,317 mm) ▶ Pricing Financing & WarrantyFinancing Options Available through KIOTI dealers 0% APR fixed rate for 36 months; 0% APR fixed rate for 48 months Base Price with Loader Not Published Not Published Warranty Length & Coverage Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) Base Price with Loader + Cab Not Published Not Published ▶ SourcesSpec sheet sources [1] tractordata.com [2] tractorgearbox.com [3] payeur.com [4] payeur.com [5] agro-specs.com [1] deere.com [2] explore.deere.com [3] deere.com
