▶ EngineEngine Manufacturer KIOTI KIOTI (Daedong) Engine Model 3HT-TM4B 3HT-TM4B Engine Type 3-cylinder, liquid-cooled diesel 3-cylinder, turbocharged, common-rail, liquid-cooled diesel No. of Cylinders 3 3 Displacement 111.4 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 50.3 hp 50.3 hp PTO Power 41.5 hp 45.6 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Not Published Not Published Fuel System Not Published Common Rail Direct Injection (CRDI) Alternator Not Published Not Published ▶ HydraulicsPump Type Gear Gear Implement Flow 9.62 gpm Not Published Steering Flow 4.94 gpm Not Published Total Hydraulic Flow 14.56 gpm 14.5 gpm Overall Hydraulic Pump Flow 14.56 gpm 14.5 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None (2 optional) None No. of Optional Remote Valves 2 2 ▶ Fluid CapacityFuel Tank Capacity 11.9 gal 11.9 gal Coolant Capacity 0.89 gal Not Published Crankcase Capacity 1.95 gal Not Published Transmission / Hydraulic System Capacity 11.4 gal Not Published Front Axle Fluid Capacity 1.48 gal Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional (2,000 rpm) Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,998 lb (at lower link ball) Not Published Hitch Lift Capacity (at 24”) 2,716 lb 2,716 lb Lift Control Type Position Position ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle Synchronized shuttle No. of Speeds 8F/8R 8F/8R Max Travel Speed (Forward) 16.71 mph 17.3 mph Max Travel Speed (Reverse) 16.28 mph 16.9 mph Clutch Dry single stage Dry type, single stage Differential Lock & Limited Slip Options Rear differential lock (standard) Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet multi-disc Wet multi disc Seat Suspension & Adjustability Deluxe suspension seat Adjustable suspension seat Front Axle Type Mechanical 4WD Mechanical 4WD Front Axle Rating Not Published Not Published Drawbar Capacity 1,655 lb (max. drawbar vertical load) Not Published ▶ Dimensions & ManeuverabilityOverall Width 62.8 in 62.8 in Wheelbase 71.3 in 71.3 in Ground Clearance 14.5 in 14.5 in Min. Turn Radius without Brakes 102.7 in (with brake applied) 8.6 ft (with brake applied) Height to Top of ROPS 96.8 in 92 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 124.3 in (with 3-point hitch) 124.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,373 lb 3,373 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Industrial, Turf, R14 Not Published R1 Agricultural - Front 8-16 8-16 R1 Agricultural - Rear 13.6-24 13.6-24 R3 Turf - Front 29-12.5-15 29-12.5-15 R3 Turf - Rear 21.5L-16.1 21.5L-16.1 R4 Industrial - Front 10-16.5 10-16.5 R4 Industrial - Rear 14.9-24 14.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Quick attach (QA) bucket, 66 in Quick attach (QA) bucket, 66 in / 72 in Loader Model KL5520 KL5520 Loader Lift Height KL5520: 107.7 in (to pivot point) KL5520: 105.7 in (at pivot pin) Loader Lift Capacity (Full Height) KL5520: 2,474 lb (at pivot pins) KL5520: 2,474 lb (at pivot pin) Loader Breakout Force KL5520: 3,895 lb (at pivot pins) KL5520: 3,895 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Non-commercial: basic 24 months, unlimited hours, parts and labor, 0% deductible; powertrain 72 months, unlimited hours Not Published ▶ ITC Company AccessoriesAccessories that fit
