▶ EngineEngine Manufacturer KIOTI (Daedong) KIOTI (Daedong) Engine Model 4A220T 3HT-TH4C Engine Type Indirect injection, vertical, water-cooled, turbocharged 4-cycle diesel 3-cylinder, liquid-cooled diesel No. of Cylinders 4 3 Displacement 134.1 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 54 hp 50.3 hp PTO Power 45.2 hp 39.3 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner High efficiency air filter with cyclone pre-cleaner canister Dry element Fuel System Indirect injection Not Published Alternator 50 A, 12 V Not Published ▶ HydraulicsPump Type Tandem gear Gear Implement Flow 9.88 gpm 9.62 gpm Steering Flow 4.33 gpm 6.87 gpm Total Hydraulic Flow 14.2 gpm 16.5 gpm Overall Hydraulic Pump Flow 14.2 gpm 16.5 gpm Hydraulic System Type Not Published Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 18.0 gal 12.7 gal Coolant Capacity 2.51 gal 2.1 gal Crankcase Capacity 2.25 gal 1.95 gal Transmission / Hydraulic System Capacity 10.0 gal 11.4 gal Front Axle Fluid Capacity 2.17 gal 1.48 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540/1000 rpm 540 rpm Mid-PTO Availability Not Published Optional (2,000 rpm) Category, 3-Point Hitch Category II (Category I ends optional) Category I Hitch Lift Capacity Not Published 2,998 lb Hitch Lift Capacity (at 24”) 2,654 lb 2,716 lb Lift Control Type Position, Draft and Mixed control Position ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle Hydrostatic (HST) No. of Speeds 12F/12R 3 ranges (hydrostatic, infinite speeds) Max Travel Speed (Forward) 16.42 mph 18.45 mph Max Travel Speed (Reverse) 13.59 mph 12.92 mph Clutch Dry type single plate, single stage None (hydrostatic transmission) Differential Lock & Limited Slip Options Mechanical rear differential lock Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc type Wet multi-disc Seat Suspension & Adjustability Adjustable seat Deluxe suspension seat Front Axle Type 4WD (bevel gear front wheel drive, push-button engagement) Mechanical 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,655 lb (max. drawbar vertical load) ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 128.6 in 125.5 in Overall Width 69.3 in 62.8 in Wheelbase 75.6 in 71.3 in Ground Clearance 17.5 in 14.5 in Min. Turn Radius without Brakes 145 in 102.8 in (with brake applied) Height to Top of ROPS 106.5 in 96.8 in Height to Top of ROPS (folded) 85.5 in Not Published Height to Top of Cab Model 97.2 in 93.0 in ▶ WeightTractor Weight (Base) 4,795 lb 3,523 lb (DK5320SEH); 4,043 lb (DK5320SEH CAB) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial, R14 R1 Agricultural - Front 9.5-20 8-16 R1 Agricultural - Rear 14.9-28 13.6-24 R3 Turf - Front 29x12.5-15 29-12.5-15 R3 Turf - Rear 44x18-20 21.5L-16.1 R4 Industrial - Front 14x17.5 10-16.5 R4 Industrial - Rear 18.4x24 14.9-24 ▶ Loader & AttachmentsQuick Attach Loader System KL551: universal quick-attach bucket mount, 78 in QA bucket Quick attach (QA) bucket, 66 in or 72 in Loader Model KL551; KL1595 KL5520; KL5521 (Cab models) Loader Lift Height KL551: 113.58 in; KL1595: 127.52 in KL5520: 107.7 in; KL5521: 107.7 in Loader Lift Capacity (Full Height) KL551: 2,850 lb; KL1595: 2,685 lb KL5520: 2,474 lb; KL5521: 2,474 lb Loader Breakout Force KL551: 4,675 lb; KL1595: 4,500 lb KL5520: 3,895 lb; KL5521: 3,895 lb ▶ WarrantyWarranty Length & Coverage Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor Non-commercial: 24 months, unlimited hours, parts and labor, 0% deductible; non-commercial powertrain (engine and driveline): 72 months, unlimited hours ▶ ITC Company AccessoriesAccessories that fit
