Kioti HX1151 vs John Deere 5115M | Side-by-side comparison | ITC Resource Center
Compare Tractors
See horsepower, lift capacity, hydraulic flow, and the numbers that matter to your work. Up to 4 machines, side by side, in graphs built to show which tractor is better at what.
Mechanical rear differential lock (standard); front limited-slip differential
Electro-hydraulic rear differential lock, engage on the go
Frame Type
Not Published
Cast iron mid-frame
Steering
Hydrostatic Power Steering
Not Published
Brakes
Wet Multi Disc
Not Published
Seat Suspension & Adjustability
Heated air suspension seat, 20 degree swivel both directions, adjustable fore/aft
OOS: isolated mechanical seat standard (fore/aft, weight, lumbar adjust) or air suspension seat optional; Cab: mechanical seat standard or air suspension seat optional; adjustable weight range 88-330 lb
Front Axle Type
4WD with outboard planetary final drives and limited-slip differential
Cab, with fender extension: 85.6 in; Cab, without fender extension: 74.0 in; OOS, with fender extension: 69.1 in; OOS, without fender extension: 51.7 in
Wheelbase
94.9 in
92.5 in
Ground Clearance
18.9 in
Not Published
Min. Turn Radius without Brakes
12.7 ft (with brake applied)
Not Published
Height to Top of ROPS
Not Published
102.1 in
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
111.9 in
102.9 in
Tractor Weight (Base)
10,230 lb
MFWD, OOS: 8,765 lb; MFWD, Cab: 9,185 lb (2WD not offered on 5115M)
