▶ EngineEngine Manufacturer KIOTI John Deere Engine Model 4J243TA-TP5B John Deere PowerTech 4.5L diesel Engine Type 4-cylinder, in-line vertical, water-cooled, turbocharged and intercooled CRDI diesel (4J243TA-TP5B) 4-cylinder, turbocharged and intercooled diesel, 4-valve high pressure common rail No. of Cylinders 4 4 Displacement 233.9 in³ 276 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 90 hp 90 hp PTO Power 70 hp 75 hp @ 100 rpm Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry element with evacuator valve Dry type with safety element Fuel System CRDI High pressure common rail, 4 valve, electronic fuel control Alternator Not Published 200 A ▶ HydraulicsPump Type Gear Tandem gear pump (open center); variable axial-piston implement pump (PFC, optional) Implement Flow 19.8 gpm 19.3 gpm (open center); 30.9 gpm (PFC) Steering Flow 12.2 gpm 6.3 gpm (open center) Total Hydraulic Flow 32 gpm 25.6 gpm (open center) Overall Hydraulic Pump Flow 32 gpm 25.6 gpm (open center); 30.9 gpm (PFC) Hydraulic System Type Open Center Open center (standard); closed center PFC (optional) Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 3 2 rear and 2 mid (stackable) No. of Optional Remote Valves 4th remote valve Rear: 3 (mechanical or proportional EH, optional; 4th rear by conversion kit); Mid: 3 Deluxe (mechanical or EH, optional) ▶ Fluid CapacityFuel Tank Capacity 47.6 gal 38 gal Coolant Capacity 4.6 gal 4.25 gal Crankcase Capacity 3.9 gal 3.1 gal Transmission / Hydraulic System Capacity 20.34 gal 11.75 gal (open center); 12.5 gal (closed center PFC) Front Axle Fluid Capacity 2.6 gal 1.3 gal (MFWD differential housing); 0.2 gal (each wheel hub) ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulic engagement, wet PTO clutch, reversible 540/1000 shaft PTO Rear 540 / 540E / 1000 rpm 540/540E/1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II (telescoping draft links with Category II balls) Hitch Lift Capacity 8,079 lb 7,158 lb; 8,157 lb throughout lift range at hitch ball; 11,122 lb / 12,515 lb maximum Hitch Lift Capacity (at 24”) 8,002 lb 6,975 lb; 7,868 lb throughout lift range Lift Control Type Electronic control Electro-hydraulic hitch with fender controls, lower-link draft sensing ▶ Transmission & DrivetrainTransmission Type Power Shuttle w/ Hi-Lo Shift CommandQuad 16F/16R manual with electronic range and gear shifting, AutoClutch and wet traction clutch (standard); CommandQuad 16F/16R Auto, CommandQuad 16F/16R manual with creeper, or Command8 32F/16R (optional) No. of Speeds 24 forward / 24 reverse 16F/16R (CommandQuad, standard); 32F/16R (Command8, optional) Max Travel Speed (Forward) 23.83 mph 22.0 mph (D4, 16/16 transmission, 480/70R28 rear tires) Max Travel Speed (Reverse) 23.67 mph 18.6 mph Clutch Wet Multi Disc Wet traction clutch with AutoClutch Differential Lock & Limited Slip Options Mechanical rear differential lock (standard); front limited-slip differential Electro-hydraulic differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Cab standard with air conditioning; mechanical front-wheel drive (MFWD) Steering Hydrostatic Power Steering Hydrostatic power steering Brakes Wet Disc Hydraulic wet disc, self-equalizing and self-adjusting, lockable turning brakes; electronic park brake Seat Suspension & Adjustability Heated air suspension seat, 20 degree swivel both directions, adjustable fore/aft Not Published Front Axle Type 4WD, outboard planetary drives, limited-slip differential MFWD, electro-hydraulic engagement, planetary final drives Front Axle Rating Not Published 7,937 lb (MFWD closed center); 7,055 lb (MFWD open center) Drawbar Capacity Max. Drawbar vertical load: 3,307 lb; Max. Trailer loading weight: 9,921 lb 2,756 lb (standard drawbar, 9.8 in extended); 2,205 lb (standard, 13.8 in extended); 3,197 lb (heavy duty, 9.8 in extended); 2,646 lb (heavy duty, 13.8 in extended) ▶ Dimensions & ManeuverabilityOverall Width 88.6 in 87 in (with fender extension); 74 in (without fender extension); 66.9 in (narrow cab, without fender extension) Wheelbase 94.9 in 88.6 in Ground Clearance 18.9 in Not Published Min. Turn Radius without Brakes 12.7 ft (with brake applied) Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 111.9 in 106.1 in Overall Length 170.8 in (with 3-point hitch) 147.8 in ▶ WeightTractor Weight (Base) 10,230 lb (with AG tires) 9,811 lb (base machine weight, with all fluids) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural (bias 13.6-24 / 18.4-34, radial 13.6R-24 / 18.4R-34); R14 radial (340/85R24 / 460/85R34) 320/85R24 (12.4R24) R1-W radial front and 460/85R30 (18.4R30) R1-W radial rear standard; optional 11.2R28/13.6R38, 380/70R20/480/70R28, 13.6R24/16.9R34, 380/70R24/480/70R34 R1; R3 44x18-20/23.1-26; R4 12.5/80-18/19.5L-24 R1 Agricultural - Front 13.6-24 320/85R24 (12.4R24) R1-W radial R1 Agricultural - Rear 18.4-34 460/85R30 (18.4R30) R1-W radial R3 Turf - Front Not Published 44x18-20 R3 Turf - Rear Not Published 23.1-26 R4 Industrial - Front Not Published 12.5/80-18 R4 Industrial - Rear Not Published 19.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System KL1155: quick-attach system with built-in parking stand; single-lever joystick control with float; bucket level indicator Global carrier in base; John Deere 500-style carrier optional (540R) Loader Model KL1155 540R (non self-leveling and mechanical self-leveling) Loader Lift Height KL1155: 150.6 in (to pivot pin) 540R: 141.5 in Loader Lift Capacity (Full Height) KL1155: 4,216 lb (at pivot pins) 540R NSL: 4,246 lb (measured at pivot) Loader Breakout Force KL1155: 8,554 lb (at pivot pins) 540R NSL: 4,945 lbf (measured at pivot) ▶ WarrantyWarranty Length & Coverage Non-commercial: basic 24 months, unlimited hours, parts and labor, 0% deductible; powertrain 48 months, unlimited hours, HX series Not Published
