▶ EngineEngine Manufacturer KIOTI KIOTI (Daedong) Engine Model 3F183T 4A220 Engine Type 3-cylinder, turbocharged, common-rail, liquid-cooled diesel Not Published No. of Cylinders 3 4 Displacement 111.4 in³ 134.1 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 45 hp 45 hp PTO Power 33.9 hp 38 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water-cooled Not Published Air Cleaner Dry type element Dual stage air filter cartridge Fuel System Common Rail Diesel (CRDI) Not Published Alternator Not Published Not Published ▶ HydraulicsPump Type Gear Not Published Implement Flow Not Published 9.9 gpm Steering Flow Not Published 4.3 gpm Total Hydraulic Flow 17.9 gpm 14.2 gpm Overall Hydraulic Pump Flow 17.9 gpm 14.2 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 1 Not Published ▶ Fluid CapacityFuel Tank Capacity 14.8 gal 11.5 gal Coolant Capacity 2.0 gal Not Published Crankcase Capacity 1.58 gal Not Published Transmission / Hydraulic System Capacity 11.89 gal Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Hydraulic independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional (2,000 rpm) Not Published Category, 3-Point Hitch Category I Category I (Category II ends optional) Hitch Lift Capacity 3,538 lb 3,968 lb Hitch Lift Capacity (at 24”) 3,177 lb 2,987 lb Lift Control Type Position with Draft Control Position, Draft and Mixed control ▶ Transmission & DrivetrainTransmission Type Hydrostatic Synchronized shuttle No. of Speeds 3 Range 12F/12R Max Travel Speed (Forward) 16.52 mph 15.84 mph Max Travel Speed (Reverse) 16.52 mph Not Published Clutch Not Published Dry single plate Differential Lock & Limited Slip Options Differential Lock: Rear (Standard) Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Hydraulic power steering Brakes Wet Multi Disc Wet disc Seat Suspension & Adjustability Adjustable Seat Adjustable seat Front Axle Type Not Published 4WD (MFWD) Front Axle Rating Not Published Not Published Drawbar Capacity 1,655 lb (max. drawbar vertical load) Not Published ▶ Dimensions & ManeuverabilityOverall Width 65.6 in 61.0 in Wheelbase 75.6 in 71.6 in Ground Clearance 13.8 in 14.5 in Min. Turn Radius without Brakes 9.8 ft 123.2 in Height to Top of ROPS 103.1 in 87.5 in Height to Top of ROPS (folded) Not Published 64.5 in Height to Top of Cab Model Not Published 91 in Overall Length 139.6 in (with 3-point hitch) 130.7 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 4,000 lb 3,895 lb (ag tires, ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf, Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 8-16 9.5-16 R1 Agricultural - Rear 13.6-24 14.9-24 R3 Turf - Front 29-12.5-15 29x12.5-15 R3 Turf - Rear 21.5L-16.1 21.5L-16.1 R4 Industrial - Front 10-16.5 12x16.5 R4 Industrial - Rear 14.9-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Not Published Loader Model KL6010 KL249; KL1470; KL1590 Loader Lift Height KL6010: 108.3 in (to pivot pin) KL249: 107.5 in; KL1470: 111.44 in; KL1590: 121.06 in Loader Lift Capacity (Full Height) KL6010: 2,761 lb (at pivot pin, max height) KL249: 2,050 lb; KL1470: 2,100 lb; KL1590: 2,500 lb Loader Breakout Force KL6010: 3,727 lb (at pivot pin) KL249: 3,695 lb; KL1470: 3,400 lb; KL1590: 4,000 lb ▶ WarrantyWarranty Length & Coverage Non-commercial: basic 2 years, powertrain 72 months, unlimited hours, parts and labor Not Published ▶ ITC Company AccessoriesAccessories that fit
