▶ EnginePTO Power 46.0 hp (34.3 kW) 45.2 hp (33.7 kW) Alternator Not Published 12 V, 50 A Air Cleaner Not Published Not Published Engine Type In-Line Vertical, Water-cooled 4-Cycle Turbo Diesel, CRDI Turbocharged diesel, liquid-cooled Fuel System Common Rail Direct Injection (CRDI) In-line pump system; mechanical control; indirect injection Displacement 111.40 in³ (1,826 cc) 134.1 in³ (2,198 cc) No. of Cylinders 3 4 Rated Engine Speed 2,600 rpm 2,600 rpm Cooling System Type Water-cooled Liquid-cooled Engine Manufacturer KIOTI (Daedong) KIOTI (Daedong) Engine Emissions Constraints Tier 4 Tier IV Interim Engine Power (Gross vs. Net HP) Gross: 55 hp (41.0 kW) Gross: 55 hp (41.0 kW) ▶ WeightTractor Weight with Loader Not Published Not Published Weight with Cab and Loader 4,562 lb (2,069.5 kg) Not Published Weight with ROPS and Loader Not Applicable Not Published ▶ HydraulicsPump Type Gear Tandem gear Steering Flow 31.2 L/min (8.2 gpm) 15.9 L/min (4.2 gpm) Implement Flow 31.2 L/min (8.2 gpm) 37.5 L/min (9.9 gpm) Total Hydraulic Flow 62.40 L/min (16.50 gpm) 53.7 L/min (14.2 gpm) Hydraulic System Type Open Center Not Published Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 62.40 L/min (16.50 gpm) 53.7 L/min (14.2 gpm) No. of Optional Remote Valves 1 Not Published No. of Standard Remote Valves 1 2 ▶ Tire OptionsR3 Turf - Rear 21.5lx16.1 21.5LX16.1/4 R3 Turf - Front 29x12.5-15 29X12.5X15/6 Tire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R4 Industrial - Rear 17.5-24 17.5X24/8 R4 Industrial - Front 10-16.5 12X16.5/6 R1 Agricultural - Rear 13.6-28 14.9-28 R1 Agricultural - Front 9.5-18 9.5-20/6 ▶ Pto & HitchPTO Rear 540 rpm 540/1000 RPM PTO Type Independent Independent Lift Control Type Position with Draft Control Top link draft sensing Hitch Lift Capacity Not Published 2,643 lbs (1,198 kg) at 24 in Mid-PTO Availability Optional (2,000 rpm) Not Published Category, 3-Point Hitch Category I Category II/I Hitch Lift Capacity (at 24”) 3,177 lbs (1,441 kg) 2,643 lbs (1,198 kg) Rear 3-Point Hitch Lift Capacity 3,177 lbs (1,441 kg) (at 24 in) 2,643 lbs (1,198 kg) at 24 in ▶ Fluid CapacityCoolant Capacity 2.0 gal (7.7 L) Not Published Crankcase Capacity 1.58 gal (6.0 L) Not Published Fuel Tank Capacity 14.8 gal (56 L) 18 gal (68.1 L) Front Axle Fluid Capacity 1.8 gal (7.0 L) Not Published Transmission / Hydraulic System Capacity 14.53 gal (55 L) Not Published ▶ Loader & AttachmentsLoader Lift Height 108.3 in (2,750 mm) Not Published Loader Breakout Force 3,727 lb (1,691 kg) Not Published Price for Backhoe Option KB2485: $9,504 MSRP (KIOTI notes subframe & bucket sold separately) Not Published Price for Mid-Mount Mower Not Applicable Not Published Quick Attach Loader System Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Not Published Loader Lift Capacity (Full Height) 2,761 lb (1,252 kg) Not Published ▶ Transmission & DrivetrainClutch Dry Type Single Stage Dry disc No. of Speeds 24X24 12F/12R Transmission Type Synchro Shuttle Synchronized shuttle Max Travel Speed (Forward) 17.35 mph (27.93 km/h) 16.4 mph (26.4 km/h) Max Travel Speed (Reverse) 15.42 mph (24.82 km/h) Not Published Differential Lock & Limited Slip Options Differential Lock: Rear (Standard) Mechanical rear differential lock ▶ Chassis Steering & ControlsBrakes Wet Multi Disc Wet disc brakes Steering Hydrostatic Power Steering Power steering Frame Type Not Published Not Published Front Axle Type Not Published Not Published Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Adjustable Seat Not Published ▶ Dimensions & ManeuverabilityWheelbase 75.6 in (1,920 mm) 76.8 in (1,950 mm) Overall Width 65.6 in (1,665 mm) 69.3 in (1,760 mm) Ground Clearance 15.7 in (400 mm) 17.5 in (440 mm) Height to Top of ROPS Not Applicable 106.5 in (2,705 mm) Height to Top of Cab Model 94.1 in (2,390 mm) 104 in (2,640 mm) Height to Top of ROPS (folded) Not Applicable 85.5 in (2,170 mm) Min. Turn Radius without Brakes 9.97 ft (3.04 m) Not Published Overall Length with 3-Point Hitch 139.6 in (3,547 mm) 130.5 in (3,316 mm) ▶ Pricing Financing & WarrantyFinancing Options NX Series offers listed: up to $4,000 cash offer OR 0% APR up to 36 months OR 6.99% interest rate Available through KIOTI dealers Base Price with Loader Tractor Starting MSRP $44,378 + LOADER $7,535 = $51,913 MSRP Not Published Warranty Length & Coverage Tractors (Non-Commercial Application): 24 months parts & labor; Tractors (Non-Commercial Application and driveline): 48 months parts & labor; eligible purchases may receive total 6 years (72 months) extended powertrain warranty coverage (limited time) Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor Base Price with Loader + Cab Tractor Starting MSRP $44,378 + LOADER $7,535 = $51,913 MSRP Not Published ▶ SourcesSpec sheet sources [1] kioti.com [2] kioti-api.files.svdcdn.com [3] daedong-kioti.com [1] tractordata.com [2] tractorgearbox.com
