▶ EngineEngine Manufacturer KIOTI (Daedong) FPT Engine Model 3F183T R753 Engine Type KIOTI 3 Cylinder, In-Line Vertical, Water-Cooled 4-Cycle Turbo Diesel, CRDI Turbocharged, intercooled 3-cylinder diesel No. of Cylinders 3 3 Displacement 111.4 in³ 136 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 60 hp 60 hp PTO Power 48.3 hp 51 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Pressurized liquid with recirculating bypass Air Cleaner Dry type element 2-stage Fuel System Common Rail Direct Injection (CRDI) Common rail direct injection (CRDI) Alternator Not Published 75 A ▶ HydraulicsPump Type Gear Dual engine-driven gear pumps, open center, fixed displacement Implement Flow 9.6 gpm 12 gpm Steering Flow 8.2 gpm 5.5 gpm Total Hydraulic Flow 17.9 gpm 17.5 gpm Overall Hydraulic Pump Flow 17.9 gpm 17.5 gpm Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 1 2 ▶ Fluid CapacityFuel Tank Capacity 14.8 gal 17.2 gal Coolant Capacity 2.0 gal 10.6 qt Crankcase Capacity 1.58 gal 6.7 qt Transmission / Hydraulic System Capacity 11.89 gal ROPS 2WD: 6.1 gal; ROPS 4WD: 6.6 gal Front Axle Fluid Capacity 1.8 gal 4WD: 8.0 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm (540/540E optional) Mid-PTO Availability Optional (2,000 rpm) Not Published Category, 3-Point Hitch Category I & II Category II/I Hitch Lift Capacity 3,538 lb 3,307 lb Hitch Lift Capacity (at 24”) 3,177 lb 2,701 lb Lift Control Type Position with Draft Control Position control with mechanical draft control ▶ Transmission & DrivetrainTransmission Type Hydrostatic 8x8 synchronized shuttle No. of Speeds 3 Range 8F/8R Max Travel Speed (Forward) 18.26 mph 19.1 mph (13.6x28 rear tires); 19.8 mph (14.9x28 rear tires) Max Travel Speed (Reverse) 18.26 mph 20.2 mph (13.6x28 rear tires); 20.9 mph (14.9x28 rear tires) Clutch Not Published Dry, 11 in organic plate (LUK) Differential Lock & Limited Slip Options Differential Lock: Rear (Standard) Mechanical rear differential lock (foot pedal); 4WD front axle with limited slip and front differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Power steering Brakes Wet Multi Disc Individual mechanically actuated wet disc Seat Suspension & Adjustability Adjustable Seat Deluxe contoured suspension seat, adjusts to operator height Front Axle Type Not Published 4WD: limited-slip front axle with front differential lock, mechanical FWD engagement Front Axle Rating Not Published Not Published Drawbar Capacity 1,655 lb (max. drawbar vertical load) Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 139.6 in ROPS 2WD: 129.5 in; ROPS 4WD: 134.0 in Overall Width 65.7 in ROPS 2WD: 66.5 in; ROPS 4WD: 67.5 in Wheelbase 75.6 in ROPS 2WD: 77.6 in; ROPS 4WD: 77.2 in Ground Clearance 15.7 in ROPS 2WD: 19.5 in; ROPS 4WD: 15.9 in Min. Turn Radius without Brakes 10.0 ft ROPS 2WD: 122.0 in; ROPS 4WD: 190.9 in Height to Top of ROPS 103.1 in ROPS 2WD: 96.5 in; ROPS 4WD: 97.6 in Height to Top of ROPS (folded) Not Published ROPS 2WD: 75.9 in; ROPS 4WD: 77.0 in Height to Top of Cab Model 94.1 in Not Published ▶ WeightTractor Weight (Base) NX6010H: 4,198 lb; NX6010HC: 4,529 lb ROPS 2WD: 4,442 lb; ROPS 4WD: 5,059 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 agricultural, R3 turf, R4 industrial R1 Agricultural - Front 9.5-16 8.3X24, 6 ply R1 Agricultural - Rear 16.9-24 14.9x28 R1, 6 ply R3 Turf - Front 29-12.5-15 Not Published R3 Turf - Rear 21.5L-16.1 Not Published R4 Industrial - Front 10-16.5 12.5x18 R4 Industrial - Rear 17.5-24 18.4x24 R4 ▶ Loader & AttachmentsQuick Attach Loader System Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator 600TL Series quick-attach loader (611TL, 621TL, 616TL, 626TL) Loader Model KL6010 611TL, 616TL, 621TL, 626TL (611TL and 621TL non self-leveling; 616TL and 626TL mechanical self-leveling) Loader Lift Height KL6010: 108.3 in (to pivot pin) 611TL: 112 in; 616TL: 115 in; 621TL: 119 in; 626TL: 122 in Loader Lift Capacity (Full Height) KL6010: 2,761 lb (at pivot pin, max height) Not Published Loader Breakout Force KL6010: 3,727 lb (at pivot pin) 611TL: 2,998 lb; 616TL: 3,130 lb; 621TL: 3,086 lb; 626TL: 3,527 lb (at 31.5 in ahead of pivot pin) ▶ WarrantyWarranty Length & Coverage Non-commercial tractor: 24 months, unlimited hours, parts & labor; non-commercial powertrain (engine and driveline): 72 months, unlimited hours, parts & labor Not Published
