▶ EngineEngine Manufacturer Daedong Kubota Engine Model 4F243DTP-A V3307-CR-TE4 Engine Type 4-cylinder, liquid-cooled turbocharged diesel Liquid-cooled, diesel, 4-cylinder, Turbocharged No. of Cylinders 4 4 Displacement 148.6 in³ 203 in³ Rated Engine Speed 2500 rpm 2400 rpm Engine Power (Gross) 66 hp 66.4 hp PTO Power Not Published 56 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Dry paper, dual element, 8 in diameter, with pre-cleaner Fuel System Not Published Common Rail System (CRS) Alternator Not Published 45 A, 12 V ▶ HydraulicsPump Type Not Published Gear Implement Flow 11 gpm 11.0 gpm Steering Flow 6.9 gpm 6.1 gpm Total Hydraulic Flow 17.9 gpm 17.1 gpm Overall Hydraulic Pump Flow 17.9 gpm 17.1 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published 11.0 gpm No. of Standard Remote Valves Not Published 1 (SCD) No. of Optional Remote Valves Not Published 2nd, 3rd (optional) ▶ Fluid CapacityFuel Tank Capacity Not Published 18.5 gal Coolant Capacity Not Published 8.5 qt Crankcase Capacity Not Published 12.7 qt Transmission / Hydraulic System Capacity Not Published 14.8 gal Front Axle Fluid Capacity Not Published 5.8 qt (differential) plus 3.7 qt (each bevel gear case) ▶ PTO & HitchPTO Type Independent Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540 / 540E rpm 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II I / II Hitch Lift Capacity Not Published 4189 lb Hitch Lift Capacity (at 24”) 4,575 lb 3307 lb Lift Control Type Position and draft control Position, Draft (Top Link Sensing) & Mixed Control ▶ Transmission & DrivetrainTransmission Type Power shuttle Hydraulic-shuttle transmission (fully synchronized) No. of Speeds 24F/24R F8/R8 Max Travel Speed (Forward) Not Published 18.0 mph Max Travel Speed (Reverse) Not Published 17.7 mph Clutch Hydraulic wet disc Multiple wet disc Differential Lock & Limited Slip Options Rear differential lock (mechanical) Rear differential lock standard (mechanical) ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS Steering Power steering Hydrostatic power steering Brakes Wet disc Mechanical wet disc Seat Suspension & Adjustability Not Published Fully adjustable suspension seat (travel, suspension tension, backrest tilt, arm rests); optional air ride seat on cab models Front Axle Type 4WD Bevel gear type with 55 degree turning angle (4WD) Front Axle Rating Not Published 5290 lb (6615 lb with loader) Drawbar Capacity Not Published 2200 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 145.8 in 138.0 in Overall Width Not Published 73.0 in Wheelbase Not Published 83.1 in Ground Clearance 16.5 in 18.1 in Min. Turn Radius without Brakes Not Published 11.8 ft Height to Top of ROPS 106.3 in 96.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 103.5 in 100.6 in ▶ WeightTractor Weight (Base) Not Published 5005 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural (standard): 11.2-20 front, 14.9-30 rear Standard: 9.5-24 front, 16.9-28 rear R1 Agricultural - Front 11.2-20 9.5-24 R1 Agricultural - Rear 14.9-30 16.9-28/14.9-28 R3 Turf - Front Not Published LSW305-521 R3 Turf - Rear Not Published LSW570-648 R4 Industrial - Front Not Published 12.5/80-18 R4 Industrial - Rear Not Published 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published LA1154A: 2-Lever Quick Coupler Loader Model KL601; KL701 LA1154A Loader Lift Height KL601: 114.2 in; KL701: 133.9 in Height position: 132.7 in; Power position: 117.2 in Loader Lift Capacity (Full Height) KL601: 2,864 lb; KL701: 3,384 lb Height position: 2469 lb; Power position: 2928 lb Loader Breakout Force KL601: 4,577 lb; KL701: 5,359 lb Height position: 4230 lbf; Power position: 5354 lbf ▶ WarrantyWarranty Length & Coverage Not Published 24 months or 2000 hours; Limited Powertrain: 36 months or 3000 hours. ▶ ITC Company AccessoriesAccessories that fit None tagged yet
