▶ EngineEngine Manufacturer Kubota Yanmar Engine Model D1703-M-DI-E4 3TNV80F Engine Type Direct injection, vertical, water-cooled, 4-cycle diesel 3-cylinder, naturally aspirated, liquid-cooled diesel No. of Cylinders 3 3 Displacement 100.47 in³ 77.3 in³ Rated Engine Speed 2200 rpm 3000 rpm Engine Power (Gross) 24.8 hp 24.7 hp PTO Power 19 hp 17.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Pressurized liquid with recirculating bypass Air Cleaner Dry paper single element (dual optional) Single-element Fuel System Direct injection In-line injection pump, indirect injection (swirl chamber) Alternator 40 A, 12 V 50 A ▶ HydraulicsPump Type Open center tandem pump, gear type Gear Implement Flow 5.15 gpm 4.6 gpm Steering Flow 3.11 gpm 2.1 gpm Total Hydraulic Flow 8.26 gpm 6.7 gpm Overall Hydraulic Pump Flow 8.26 gpm 6.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 3: self-canceling detent valve or float detent valve 1 ▶ Fluid CapacityFuel Tank Capacity 10.0 gal 6.6 gal Coolant Capacity 6.3 qt 3.49 qt Crankcase Capacity 6.0 qt 3 qt Transmission / Hydraulic System Capacity HST (4WD): 6.2 gal; DT (2WD): 7.1 gal; DT (4WD): 7.3 gal 3.3 gal Front Axle Fluid Capacity 6.9 qt 0.5 gal ▶ PTO & HitchPTO Type F (2WD), DT (4WD): Transmission driven with overrunning clutch; HST (4WD): Live-continuous running Independent, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid-PTO offered Standard (2,500 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,918 lb 992 lb Hitch Lift Capacity (at 24”) 1,389 lb 728 lb Lift Control Type Position control Lift-hold-lower ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (3-range) 2-range hydrostatic, dual pedal No. of Speeds 3-range Infinite (2 ranges) Max Travel Speed (Forward) 11.5 mph 9.1 mph Max Travel Speed (Reverse) 10.3 mph 5.5 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Rear differential lock standard Mechanical, foot-operated rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Integral type power steering Hydrostatic power steering Brakes Wet disc type Wet, multi-disc Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Deluxe high-back seat with armrests and adjustable backrest Front Axle Type Bevel gear front axle, non-adjustable tread spacing 4WD Front Axle Rating 2,865 lb (4WD, at 43.1 in tread) Not Published Drawbar Capacity 730 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 46.7 in Wheelbase 63.3 in 56.1 in Ground Clearance 13.4 in 12 in Min. Turn Radius without Brakes 8.2 ft (with brake applied) 94 in Height to Top of ROPS 91.7 in 87.4 in Height to Top of ROPS (folded) Not Published 64 in Height to Top of Cab Model Not Published 87.4 in Overall Length 106.3 in (without 3-point hitch) 97.4 in ▶ WeightTractor Weight (Base) 2,623 lb ROPS: 1,444 lb; Cab: 1,805 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R4 Industrial R3 Turf, R4 Industrial R1 Agricultural - Front 7.2-16 Not Published R1 Agricultural - Rear 11.2-24 Not Published R3 Turf - Front Not Published 18x8.50-10 R3 Turf - Rear Not Published 26x12.0-12 R4 Industrial - Front 27X8.50-15 18x8.50-10 R4 Industrial - Rear 15-19.5 26x12.0-12 ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA525 - 2 Lever Quick Coupler) 100LC: Quick Mount system, no tools needed Loader Model LA525 100LC Loader Lift Height 94.3 in (at pivot pin) 100LC: 72 in (at pivot pin) Loader Lift Capacity (Full Height) 1,082 lb (at pivot pin) 100LC: 1,005 lb (at bucket pivot pin, max height) Loader Breakout Force 2,373 lbf (at pivot pin) 100LC: 2,078 lb (at bucket pivot pin) ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Basic 2 years or 750 hours; powertrain to 6 years or 1,500 hours total ▶ ITC Company AccessoriesAccessories that fit None tagged yet
