▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1703-M-DI-E4 / D1703-M-DI-E4K D902 Engine Type Direct injection, vertical, water-cooled 4-cycle, diesel Liquid-cooled, 3-cylinder diesel No. of Cylinders 3 3 Displacement 100.5 in³ 54.8 in³ Rated Engine Speed 2200 rpm 3200 rpm Engine Power (Gross) 23.3 hp 23 hp PTO Power 18.4 hp 17.7 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry type, single element Not Published Fuel System Direct injection Indirect injection Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 5.2 gpm Not Published Steering Flow 3.1 gpm Not Published Total Hydraulic Flow 8.28 gpm (5.15 + 3.13, computed) 6.2 gpm Overall Hydraulic Pump Flow 8.28 gpm (5.15 + 3.13, computed) 6.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 6.6 gal Coolant Capacity 6.3 qt 2.8 qt Crankcase Capacity 6.0 qt 3.3 qt Transmission / Hydraulic System Capacity 6.9 gal 3.06 gal Front Axle Fluid Capacity 4.8 qt Not Published ▶ PTO & HitchPTO Type Live-independent hydraulic PTO with PTO brake, wet Live independent, wet hydraulic clutch PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Standard mid-PTO, 2500 rpm Category, 3-Point Hitch SAE Category I Category I Hitch Lift Capacity 1,874 lb 1,210 lb Hitch Lift Capacity (at 24”) 1,389 lb 680 lb Lift Control Type Position control Directional control with auto-return lever ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (3-range) Hydrostatic transmission with High-Low gear shift, 2-range No. of Speeds 3-range 2-range Max Travel Speed (Forward) 11.5 mph 8.1 mph Max Travel Speed (Reverse) 10.3 mph 6.2 mph Clutch n/a Not Published Differential Lock & Limited Slip Options Rear differential lock, pedal operated Differential lock (pedal operated) ▶ Chassis, Steering & ControlsFrame Type Not Published Roll Over Protective Structure (ROPS) Steering Integral type power steering Hydrostatic power steering Brakes Mechanical, wet disc type Wet disc Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Not Published Front Axle Type Cast-iron front axle Selectable 2WD and 4WD Front Axle Rating Not Published Not Published Drawbar Capacity 730 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 44.5 in (with turf tires) Wheelbase 63.4 in 55.1 in Ground Clearance 13.4 in 8.7 in (front axle) Min. Turn Radius without Brakes 8.2 ft (with brake applied) 7.5 ft Height to Top of ROPS 91.7 in 70.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 108.5 in (without 3-point hitch) 95.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,833 lb 1,290 lb (with ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural; Turf; Industrial Turf, bar (ag) or industrial: 18x8.5-10 front, 26x12-12 rear R1 Agricultural - Front 7.2-16 18x8.5-10 R1 Agricultural - Rear 11.2-24 26x12-12 R3 Turf - Front 25X8.50-14 18x8.5-10 R3 Turf - Rear 13.6-16 26x12-12 R4 Industrial - Front 27X8.50-15 18x8.5-10 R4 Industrial - Rear 15-19.5 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) Not Published Loader Model LA526 LA243 Loader Lift Height LA526: 94.8 in LA243: 71.3 in (at pivot pin) Loader Lift Capacity (Full Height) LA526: 1,096 lb LA243: 750 lb (pivot pin, max. height) Loader Breakout Force Not Published LA243: 992 lbf ▶ WarrantyWarranty Length & Coverage Not Published Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
