▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1703-M-DI-E4 / D1703-M-DI-E4K D1703-M-DI-E4 / D1703-M-DI-E4K Engine Type Direct injection, vertical, water-cooled 4-cycle, diesel Direct injection, vertical, water-cooled 4-cycle, diesel No. of Cylinders 3 3 Displacement 100.5 in³ 100.5 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 23.3 hp 23.3 hp PTO Power 18.4 hp 18.4 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Water-cooled Water-cooled Air Cleaner Dry type, single element Dry type, single element Fuel System Direct injection Direct injection Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 5.2 gpm 5.2 gpm Steering Flow 3.1 gpm 3.1 gpm Total Hydraulic Flow 8.28 gpm (5.15 + 3.13, computed) 8.28 gpm (5.15 + 3.13, computed) Overall Hydraulic Pump Flow 8.28 gpm (5.15 + 3.13, computed) 8.28 gpm (5.15 + 3.13, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 11.1 gal Coolant Capacity 6.3 qt 6.3 qt Crankcase Capacity 6.0 qt 6.0 qt Transmission / Hydraulic System Capacity 7.4 gal HST (4WD): 6.9 gal; DT (2WD): 7.4 gal; DT (4WD): 7.5 gal Front Axle Fluid Capacity Not Published 4.8 qt ▶ PTO & HitchPTO Type Transmission driven with overrunning clutch DT (2WD), DT (4WD): Transmission driven with overrunning clutch; HST (4WD): Live-independent hydraulic PTO with PTO brake, wet PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch SAE Category I SAE Category I Hitch Lift Capacity 1874 lb 1874 lb Hitch Lift Capacity (at 24”) 1389 lb 1389 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Constant mesh with synchronized shuttle DT (2WD), DT (4WD): Constant mesh with synchronized shuttle; HST (4WD): Hydrostatic transmission (3-range) No. of Speeds 8 forward, 8 reverse DT (2WD), DT (4WD): 8 forward, 8 reverse; HST (4WD): 3-range Max Travel Speed (Forward) 10.7 mph DT (2WD), DT (4WD): 10.7 mph; HST (4WD): 11.5 mph Max Travel Speed (Reverse) 10.7 mph DT (2WD), DT (4WD): 10.7 mph; HST (4WD): 10.3 mph Clutch Dry type single stage DT (2WD), DT (4WD): Dry type single stage; HST (4WD): Not Applicable Differential Lock & Limited Slip Options Rear differential lock, pedal operated Rear differential lock, pedal operated ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Integral type power steering Integral type power steering Brakes Mechanical, wet disc type Mechanical, wet disc type Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Suspension seat with fore/aft travel adjustment and suspension tension adjustment Front Axle Type Cast-iron front axle Cast-iron front axle Front Axle Rating Not Published Not Published Drawbar Capacity 730 lb 730 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 110.6 in (without 3-point hitch) DT (2WD): 110.6 in; DT (4WD), HST (4WD): 108.5 in (without 3-point hitch) Overall Width 55.1 in 55.1 in Wheelbase 63.8 in DT (2WD): 63.8 in; DT (4WD), HST (4WD): 63.4 in Ground Clearance 13.6 in DT (2WD): 13.6 in; DT (4WD), HST (4WD): 13.4 in Min. Turn Radius without Brakes 7.9 ft (with brake applied) DT (2WD): 7.9 ft; DT (4WD), HST (4WD): 8.2 ft (with brake applied) Height to Top of ROPS 91.7 in 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2601 lb DT (2WD): 2601 lb; DT (4WD): 2811 lb; HST (4WD): 2833 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 5.0-15 DT (2WD): 5.0-15; DT (4WD), HST (4WD): 7.2-16 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 23X8.50-12 DT (2WD): 23X8.50-12; DT (4WD), HST (4WD): 25X8.50-14 R3 Turf - Rear 13.6-16 13.6-16 R4 Industrial - Front Not Published DT (2WD): Not Applicable; DT (4WD), HST (4WD): 27X8.50-15 R4 Industrial - Rear Not Published DT (2WD): Not Applicable; DT (4WD), HST (4WD): 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) Loader Model LA526 LA526 Loader Lift Height 94.8 in LA526: 94.8 in Loader Lift Capacity (Full Height) 1096 lb LA526: 1,096 lb Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published ▶ ITC Company AccessoriesAccessories that fit
