▶ EngineEngine Manufacturer Kubota Kubota Engine Model Not Published V1505-E3-D24H Engine Type Not Published Indirect injection, vertical, water-cooled, 4-cycle diesel No. of Cylinders 3 4 Displacement 91.5 in³ 91.5 in³ Rated Engine Speed 2800 rpm 2700 rpm Engine Power (Gross) 30 hp 33 hp PTO Power F (2WD gear), DT (4WD gear): 25 hp; HST (4WD): 23.5 hp 25 hp Engine Emissions Constraints Tier 2 Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Not Published Dual paper element Fuel System Indirect injection (E-TVCS) Indirect injection Alternator 40 A, 12 V 14.5 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 6.5 gpm 6.7 gpm Steering Flow 4.0 gpm 3.2 gpm Total Hydraulic Flow 10.5 gpm (6.5 + 4.0, computed) 9.9 gpm Overall Hydraulic Pump Flow Not Published 9.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 3 1 (optional rear valve) ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 8.1 gal Coolant Capacity Not Published 4.7 qt Crankcase Capacity Not Published 5.7 qt Transmission / Hydraulic System Capacity 7.3 gal 3.83 gal Front Axle Fluid Capacity 4.8 qt Not Published ▶ PTO & HitchPTO Type F (2WD gear), DT (4WD gear): transmission-driven, live-continuous running; HST (4WD): live-continuous with overrunning clutch Live PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published None (no mid-PTO) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1998 lb 1786 lb Hitch Lift Capacity (at 24”) 1435 lb 1400 lb Lift Control Type Position control Quarter inching valve ▶ Transmission & DrivetrainTransmission Type Not Published Hydrostatic transmission, 3-range No. of Speeds F (2WD gear), DT (4WD gear): 8F/4R; HST (4WD): 3-range 3-range Max Travel Speed (Forward) F (2WD gear), DT (4WD gear): 13.7 mph; HST (4WD): 14.7 mph 11.9 mph Max Travel Speed (Reverse) F (2WD gear), DT (4WD gear): 4.9 mph; HST (4WD): 13.2 mph 9.5 mph Clutch F (2WD gear), DT (4WD gear): dry-type single stage; HST (4WD): dry-type single stage Dry single plate Differential Lock & Limited Slip Options Rear differential lock standard Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS (foldable ROPS optional) Two-post ROPS (sunshade optional) Steering Integral type power steering Integral type power steering Brakes Wet disc type Wet disc type Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1100 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch F (2WD gear): 110.6 in; DT (4WD gear), HST (4WD): 106.5 in (w/o 3P) (without 3-point hitch) 99.2 in (w/o 3P) (without 3-point hitch) Overall Width 51.4 in 53.7 in Wheelbase F (2WD): 63.4 in; DT (4WD), HST (4WD): 63.3 in 66.8 in Ground Clearance F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.4 in 14.6 in Min. Turn Radius without Brakes F (2WD gear): 7.9 ft; DT (4WD gear), HST (4WD): 8.2 ft (w/brake) (with brake applied) 7.9 ft (w/brake) (with brake applied) Height to Top of ROPS 85.0 in 88.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) F (2WD gear): 2359 lb; DT (4WD gear): 2536 lb; HST (4WD): 2600 lb 1764 lb (farm tires); 1786 lb (industrial tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options F (2WD gear): 5-15 front, 11.2-24 rear; DT (4WD gear), HST (4WD): 7-16 front, 11.2-24 rear Not Published R1 Agricultural - Front F (2WD gear): 5-15; DT (4WD gear), HST (4WD): 7-16 7-12 R1 Agricultural - Rear 11.2-24 12.4-16 R3 Turf - Front 2WD: 23x8.50-12; 4WD: 25x8.50-14 Not Published R3 Turf - Rear 13.6-16 13.6-16 R4 Industrial - Front 27x8.50-15 (4WD) Not Published R4 Industrial - Rear 15-19.5 R4 (4WD) Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model LA463 LA504 Loader Lift Height LA463: 95.3 in LA504: 82.6 in Loader Lift Capacity (Full Height) LA463: 1142 lb LA504: 1065 lb Loader Breakout Force LA463: 1858 lbf (at 19.7 in) (19.7 in forward of pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
