▶ EngineEngine Manufacturer Kubota Kubota Engine Model Not Published V1505-E3-D24H Engine Type Not Published Indirect injection, vertical, water-cooled, 4-cycle diesel No. of Cylinders 3 4 Displacement 91.5 in³ 91.5 in³ Rated Engine Speed Not Published 2700 rpm Engine Power (Gross) 32.1 hp 33 hp PTO Power 25.8 hp 25 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Not Published Water-cooled Air Cleaner Not Published Dual paper element Fuel System Indirect injection Indirect injection Alternator Not Published 14.5 A, 12 V ▶ HydraulicsPump Type Single pump (position-control) Not Published Implement Flow 8.3 gpm 6.7 gpm Steering Flow 4.9 gpm 3.2 gpm Total Hydraulic Flow 13.2 gpm 9.9 gpm Overall Hydraulic Pump Flow 8.3 gpm 9.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 3 1 (optional rear valve) ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 8.1 gal Coolant Capacity 6.3 qt 4.7 qt Crankcase Capacity 6.0 qt 5.7 qt Transmission / Hydraulic System Capacity 11.1 gal 3.83 gal Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent, hydraulic clutch Live PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional mid-PTO, independent, 2000 rpm None (no mid-PTO) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3750 lb (at lift points) 1786 lb Hitch Lift Capacity (at 24”) 2650 lb 1400 lb Lift Control Type Position control (with optional draft control) Quarter inching valve ▶ Transmission & DrivetrainTransmission Type F (2WD), DT (4WD): 8-speed fully synchronized main and shuttle (16-speed with creep option) Hydrostatic transmission, 3-range No. of Speeds 8F/8R (16F/16R with creep option) 3-range Max Travel Speed (Forward) Not Published 11.9 mph Max Travel Speed (Reverse) Not Published 9.5 mph Clutch Dry type single stage Dry single plate Differential Lock & Limited Slip Options Not Published Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post ROPS (sunshade optional) Steering Hydrostatic power steering Integral type power steering Brakes Wet disk type Wet disc type Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1100 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 119.1 in (without 3P) (without 3-point hitch) 99.2 in (w/o 3P) (without 3-point hitch) Overall Width 56.3 in (minimum tread) 53.7 in Wheelbase 71.1 in 66.8 in Ground Clearance 14.6 in 14.6 in Min. Turn Radius without Brakes 8.9 ft (w/brake) (with brake applied) 7.9 ft (w/brake) (with brake applied) Height to Top of ROPS 88.8 in (with ROPS) 88.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3265 lb (with ROPS) 1764 lb (farm tires); 1786 lb (industrial tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard Front: 7-16; Rear: 12.4-24 Not Published R1 Agricultural - Front 7-16 7-12 R1 Agricultural - Rear 12.4-24 12.4-16 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published 13.6-16 R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System LA513 and LA723 loaders offered Not Published Loader Model LA513; LA723 LA504 Loader Lift Height LA513: 96.5 in; LA723: 102.4 in LA504: 82.6 in Loader Lift Capacity (Full Height) LA513: 1345 lb; LA723: 1870 lb LA504: 1065 lb Loader Breakout Force LA513: 2160 lbf (at 19.7 in); LA723: 2605 lbf (at 19.7 in) (19.7 in forward of pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
