▶ EngineEngine Manufacturer Kubota Kubota Engine Model F (2WD gear), DT (4WD gear): D1803-CR-E4-LB1; HST (4WD): D1803-CR-E4-LB2 Not Published Engine Type 3-cylinder, multi-valve, naturally aspirated, common-rail, liquid-cooled diesel Not Published No. of Cylinders 3 3 Displacement 111.4 in³ 91.5 in³ Rated Engine Speed 2700 rpm Not Published Engine Power (Gross) 33 hp 32.1 hp PTO Power F (2WD gear), DT (4WD gear): 27.7 hp; HST (4WD): 26.2 hp 25.8 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled, water with pressurized radiator Not Published Air Cleaner Dry paper single element Not Published Fuel System Common-rail, direct injection, electronic control Indirect injection Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Open center tandem pump, gear type Single pump (position-control) Implement Flow 6.3 gpm 8.3 gpm Steering Flow 3.8 gpm 4.9 gpm Total Hydraulic Flow 10.1 gpm 13.2 gpm Overall Hydraulic Pump Flow 10.1 gpm 13.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 3: self-canceling detent valve or float detent valve 3 ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 10.6 gal Coolant Capacity 6.3 qt 6.3 qt Crankcase Capacity 7.1 qt 6.0 qt Transmission / Hydraulic System Capacity F (2WD gear): 7.4 gal; DT (4WD gear): 7.5 gal; HST (4WD): 6.2 gal 11.1 gal Front Axle Fluid Capacity 4.8 qt Not Published ▶ PTO & HitchPTO Type F (2WD gear), DT (4WD gear): Transmission driven with overrunning clutch; HST (4WD): Live-continuous running Independent, hydraulic clutch PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid-PTO offered Optional mid-PTO, independent, 2000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,874 lb (at lift points) 3,750 lb (at lift points) Hitch Lift Capacity (at 24”) 1,433 lb 2,650 lb Lift Control Type Position control Position control (with optional draft control) ▶ Transmission & DrivetrainTransmission Type F (2WD gear), DT (4WD gear): manual transmission with synchronized shuttle; HST (4WD): hydrostatic transmission F (2WD), DT (4WD): 8-speed fully synchronized main and shuttle (16-speed with creep option) No. of Speeds F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range 8F/8R (16F/16R with creep option) Max Travel Speed (Forward) F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph Not Published Max Travel Speed (Reverse) F (2WD gear), DT (4WD gear): 13.1 mph; HST (4WD): 12.7 mph Not Published Clutch Dry type single stage Dry type single stage Differential Lock & Limited Slip Options Rear differential lock standard Not Published ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (factory certified) with retractable seat belt Not Published Steering Integral power steering Hydrostatic power steering Brakes Mechanical wet disc type, pedals can be locked together Wet disk type Seat Suspension & Adjustability Not Published Not Published Front Axle Type F (2WD gear): tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): bevel-gear front axle, non-adjustable tread spacing Not Published Front Axle Rating 2,865 lb (at 41.3 in tread, 2WD and 4WD models) Not Published Drawbar Capacity 730 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 56.3 in (minimum tread) Wheelbase 63.3 in 71.1 in Ground Clearance F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.5 in 14.6 in Min. Turn Radius without Brakes F (2WD gear): 8.9 ft; DT (4WD gear), HST (4WD): 10.5 ft 8.9 ft (with brake applied) Height to Top of ROPS 97.1 in 88.8 in (with ROPS) Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length F (2WD gear): 119.1 in; DT (4WD gear), HST (4WD): 116.3 in (with 3-point hitch) 119.1 in (without 3-point hitch) ▶ WeightTractor Weight (Base) F (2WD gear): 2,557 lb; DT (4WD gear): 2,734 lb; HST (4WD): 2,778 lb 3,265 lb (with ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) Standard Front: 7-16; Rear: 12.4-24 R1 Agricultural - Front F (2WD gear): 5-15 (7.5L-15 optional); DT (4WD gear), HST (4WD): 7.2-16 7-16 R1 Agricultural - Rear 11.2-24 12.4-24 R3 Turf - Front F (2WD gear): 23x8.5-12; DT (4WD gear), HST (4WD): 25x8.5-14 Not Published R3 Turf - Rear 13.6-16 Not Published R4 Industrial - Front 27x8.5-15 (4WD) Not Published R4 Industrial - Rear 15-19.5 (4WD) Not Published ▶ Loader & AttachmentsQuick Attach Loader System LA525: 2-lever quick coupler, tool-free attach and detach LA513 and LA723 loaders offered Loader Model LA525 LA513; LA723 Loader Lift Height LA525: 94.3 in (at pivot pin) LA513: 96.5 in; LA723: 102.4 in Loader Lift Capacity (Full Height) LA525: 1,131 lb (at pivot pin, maximum height) LA513: 1,345 lb; LA723: 1,870 lb Loader Breakout Force LA525: 2,462 lbf (at bucket pivot pin) LA513: 2,160 lbf (at 19.7 in); LA723: 2,605 lbf (at 19.7 in) (19.7 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage 24 months or 1500 hours (general) Not Published
