▶ EngineEngine Manufacturer Kubota Yanmar Engine Model D1803-CR-E5 3TNV88C-MJT Engine Type Direct injection, vertical, water-cooled 4-cycle, diesel Diesel, turbocharged No. of Cylinders 3 3 Displacement 111.4 in³ 97.6 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 33 hp 31.8 hp PTO Power 26.1 hp 24.3 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Water pump Air Cleaner Dry type, single element Dry type with safety element Fuel System Direct injection High pressure common rail direct injection (HPCR) Alternator 45 A, 12 V 75 A, 12 V ▶ HydraulicsPump Type Not Published Implement/steering pump: Dual gear; hydrostatic pump: PV axial piston Implement Flow 6.3 gpm 8.6 gpm Steering Flow 3.8 gpm 5.9 gpm Total Hydraulic Flow 10.1 gpm (6.3 + 3.8, computed) 14.4 gpm Overall Hydraulic Pump Flow 10.1 gpm (6.3 + 3.8, computed) 14.4 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Up to 6 rear remotes ▶ Fluid CapacityFuel Tank Capacity 11.1 gal Open station: 13.5 gal; Cab: 11.8 gal Coolant Capacity 6.3 qt 1.4 gal Crankcase Capacity 7.1 qt 1.1 gal Transmission / Hydraulic System Capacity 7.5 gal 6.8 gal Front Axle Fluid Capacity 4.8 qt 1.3 gal ▶ PTO & HitchPTO Type Transmission driven with overrunning clutch Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Optional (2100 rpm) Category, 3-Point Hitch SAE Category I Limited Category 1 Hitch Lift Capacity 1998 lb 2530 lb at hitch ball Hitch Lift Capacity (at 24”) 1435 lb 2,194 lb at 24 in behind link arms Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Gear shift with synchronized shuttle three-range, infinitely variable No. of Speeds 8 forward, 8 reverse infinite in 3 ranges Max Travel Speed (Forward) 13.2 mph 18.50 mph Max Travel Speed (Reverse) 13.2 mph 18.50 mph Clutch Dry type single stage Not Applicable Differential Lock & Limited Slip Options Rear differential lock, pedal operated Differential lock: Yes ▶ Chassis, Steering & ControlsFrame Type Not Published Foldable ROPS; cab or open station configurations available Steering Integral type power steering Hydrostatic power steering Brakes Mechanical, wet disc type Multi-plate wet disk Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Standard seat: height/level/fore-aft adjustments; Deluxe seat: weight (air pressure) & fore-aft adjustments Front Axle Type Cast-iron front axle Mechanical front wheel drive (MFWD) Front Axle Rating Not Published 3196 lb Drawbar Capacity 730 lb 899 lbf ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 108.5 in (without 3-point hitch) 120.2 in Overall Width 55.1 in 69.1 in Wheelbase 63.4 in 68.0 in Ground Clearance 13.4 in 12.2 in Min. Turn Radius without Brakes 8.2 ft (with brake applied) 8.8 ft (2.68 m, MFWD off) Height to Top of ROPS 91.7 in 93.3 in Height to Top of ROPS (folded) Not Published 72.0 in Height to Top of Cab Model Not Published 85.0 in ▶ WeightTractor Weight (Base) 2734 lb 2900 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 7.2-16 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 25X8.50-14 27X8.50-15 R3 Turf - Rear 13.6-16 41X14-20 R4 Industrial - Front 27X8.50-15 25X8.5-14 or 27X8.5-15 R4 Industrial - Rear 15-19.5 15-19.5 or 43X16-20 ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) Quik-Park mounting system Loader Model LA526 H160 Loader Lift Height 94.8 in 90 in Loader Lift Capacity (Full Height) 1144.4 lb 1,360 lb at pivot; 999 lb @ 19.7 in ahead of pivot Loader Breakout Force Not Published 2,855 lb at pivot; 2,032 lb @ 19.7 in ▶ WarrantyWarranty Length & Coverage Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) ▶ ITC Company AccessoriesAccessories that fit None tagged yet
