▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403-CR-E4-GL2 F (2WD gear), DT (4WD gear): D1803-CR-E4-LB3; HST (4WD): D1803-CR-E4-LB4 Engine Type Naturally aspirated, multi-valve, liquid-cooled diesel 3-cylinder, multi-valve, naturally aspirated, common-rail, liquid-cooled diesel No. of Cylinders 4 3 Displacement 148.5 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2700 rpm Engine Power (Gross) 42 hp 37.5 hp PTO Power 32.5 hp F (2WD gear), DT (4WD gear): 32.1 hp; HST (4WD): 30.6 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled, water with pressurized radiator Air Cleaner Dry paper, dual element Dry paper single element Fuel System Electronic CRS (Common Rail System) Common-rail, direct injection, electronic control Alternator 40 A, 12 V 40 A ▶ HydraulicsPump Type Tandem pump - gear type Open center tandem pump, gear type Implement Flow 9.4 gpm 6.3 gpm Steering Flow 4.7 gpm 3.8 gpm Total Hydraulic Flow 14.1 gpm 10.1 gpm Overall Hydraulic Pump Flow 14.1 gpm 10.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None standard (up to 3 optional) Not Published No. of Optional Remote Valves Optional, up to 3: double-acting valve or float detent valve, any position Up to 3: self-canceling detent valve or float detent valve ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 11.1 gal Coolant Capacity 7.9 qt 6.3 qt Crankcase Capacity 8.7 qt 7.1 qt Transmission / Hydraulic System Capacity 11.4 gal F (2WD gear): 7.4 gal; DT (4WD gear): 7.5 gal; HST (4WD): 6.2 gal Front Axle Fluid Capacity 6.9 qt 4.8 qt ▶ PTO & HitchPTO Type Live independent (hydraulic clutch) Live-continuous running PTO Rear 540 rpm @ 2476 engine rpm 540 rpm Mid-PTO Availability Optional No mid-PTO offered Category, 3-Point Hitch SAE Category I Category I Hitch Lift Capacity 3,858 lb 1,874 lb (at lift points) Hitch Lift Capacity (at 24”) 2,760 lb 1,433 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic F (2WD gear), DT (4WD gear): synchronized shuttle, 8F/8R; HST (4WD): hydrostatic, 3-range No. of Speeds 3-Range, 6 speeds (H-DS), infinitely variable in each F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range Max Travel Speed (Forward) 16.8 mph F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph Max Travel Speed (Reverse) 15.1 mph F (2WD gear), DT (4WD gear): 13.1 mph; HST (4WD): 12.7 mph Clutch Not Published F (2WD gear), DT (4WD gear), HST (4WD): dry type single stage Differential Lock & Limited Slip Options Rear differential lock, standard Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS (factory certified) with retractable seat belt Steering Hydrostatic power steering Integral power steering Brakes Wet disc type, mechanically activated Mechanical wet disc type, pedals can be locked together Seat Suspension & Adjustability Deluxe suspension seat with swivel (standard); Air-Ride seat (optional) Not Published Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing F (2WD gear): tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): bevel-gear front axle, non-adjustable tread spacing Front Axle Rating Not Published 2,865 lb (at 41.3 in tread, 2WD and 4WD models) Drawbar Capacity 1,433 lb 730 lb ▶ Dimensions & ManeuverabilityOverall Width 66.5 in 55.1 in Wheelbase 74.6 in 63.3 in Ground Clearance 14.2 in F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.5 in Min. Turn Radius without Brakes 8.9 ft (with brake applied) F (2WD gear): 8.9 ft; DT (4WD gear), HST (4WD): 10.5 ft Height to Top of ROPS 97.6 in 97.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model n/a (ROPS model) Not Published Overall Length 129.5 in (with 3-point hitch) F (2WD gear): 119.1 in; DT (4WD gear), HST (4WD): 116.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,759 lb F (2WD gear): 2,557 lb; DT (4WD gear): 2,734 lb; HST (4WD): 2,778 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) R1 Agricultural - Front 8.3-16 F (2WD gear): 5-15 (7.5L-15 optional); DT (4WD gear), HST (4WD): 7.2-16 R1 Agricultural - Rear 14.9-24 11.2-24 R3 Turf - Front 27-10.50LL15 F (2WD gear): 23x8.5-12; DT (4WD gear), HST (4WD): 25x8.5-14 R3 Turf - Rear 41-18LLx16.1 13.6-16 R4 Industrial - Front 10-16.5 27x8.5-15 (4WD) R4 Industrial - Rear 17.5L-24 15-19.5 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) LA525: 2-lever quick coupler, tool-free attach and detach Loader Model LA805 LA525 Loader Lift Height 104.7 in (at pivot pin) LA525: 94.3 in (at pivot pin) Loader Lift Capacity (Full Height) 1,715 lb (at pivot pin) LA525: 1,131 lb (at pivot pin) Loader Breakout Force 2,549 lb LA525: 2,462 lbf (bucket pivot pin) ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours 24 months or 1500 hours (general) ▶ ITC Company AccessoriesAccessories that fit None tagged yet
