▶ EngineEngine Manufacturer Kubota KIOTI Engine Model V2403-CR-E4-GL5 3F183T Engine Type Naturally aspirated, multi-valve, liquid-cooled diesel 3-cylinder, in-line vertical, water-cooled, 4-cycle, turbocharged, common rail diesel No. of Cylinders 4 3 Displacement 148.5 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 49 hp 50 hp PTO Power 39.5 hp 41.8 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry paper, dual element Dry type element Fuel System Electronic CRS (Common Rail System) Common Rail Diesel (CRDI) Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Tandem pump - gear type Gear Implement Flow 9.4 gpm Not Published Steering Flow 4.7 gpm Not Published Total Hydraulic Flow 14.1 gpm 16.5 gpm Overall Hydraulic Pump Flow 14.1 gpm 16.5 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None standard (up to 3 optional) 1 No. of Optional Remote Valves Optional, up to 3: double-acting valve or float detent valve, any position 1 ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 14.8 gal Coolant Capacity 8.7 qt 2.0 gal Crankcase Capacity 8.7 qt 1.58 gal Transmission / Hydraulic System Capacity 11.4 gal 14.53 gal Front Axle Fluid Capacity 8.9 qt 1.8 gal ▶ PTO & HitchPTO Type Live independent (hydraulic clutch) Independent PTO Rear 540 rpm @ 2475 engine rpm 540 rpm Mid-PTO Availability Optional Optional (2,000 rpm) Category, 3-Point Hitch SAE Category I Category I Hitch Lift Capacity 3,858 lb 3,538 lb Hitch Lift Capacity (at 24”) 2,756 lb 3,177 lb Lift Control Type Position control Position with Draft Control ▶ Transmission & DrivetrainTransmission Type Hydrostatic Synchro Shuttle No. of Speeds 3-range, 6 speeds (H-DS), infinitely variable in each 24x24 Max Travel Speed (Forward) 16.8 mph 15.71 mph Max Travel Speed (Reverse) 15.1 mph 13.96 mph Clutch Not Published Dry Type Single Stage Differential Lock & Limited Slip Options Rear differential lock, standard Differential Lock: Rear (Standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Power Steering Brakes Wet disc type, mechanically activated Wet Multi Disc Seat Suspension & Adjustability Deluxe suspension seat with swivel; Air-Ride seat (optional) Adjustable Seat Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,433 lb 1,655 lb (max. drawbar vertical load) ▶ Dimensions & ManeuverabilityOverall Width 66.5 in 65.6 in Wheelbase 74.6 in 75.6 in Ground Clearance 14.4 in 13.8 in Min. Turn Radius without Brakes 8.9 ft (with brake applied) 9.8 ft Height to Top of ROPS 97.6 in 103.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Applicable Not Published Overall Length 129.5 in (with 3-point hitch) 139.6 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,847 lb 3,978 lb (with AG tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf (Option 1) or R3 LSW Turf (Option 2); R4 Industrial Agricultural, Turf, Industrial R1 Agricultural - Front 8.3-16 8-16 R1 Agricultural - Rear 14.9-24 13.6-24 R3 Turf - Front 29x12.50-15 29-12.5-15 R3 Turf - Rear 44x18-20 21.5L-16.1 R4 Industrial - Front 10-16.5 10-16.5 R4 Industrial - Rear 17.5L-24 14.9-24 ▶ Loader & AttachmentsQuick Attach Loader System 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Loader Model LA1105 KL6010 Loader Lift Height Not Published KL6010: 108.3 in (to pivot pin) Loader Lift Capacity (Full Height) Not Published KL6010: 2,761 lb (at pivot pin, max height) Loader Breakout Force LA555: 2,030 lb; LA805: 2,549 lb; LA1055: 3,171 lb KL6010: 3,727 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Non-commercial: basic 2 years, powertrain 72 months, unlimited hours, parts and labor ▶ ITC Company AccessoriesAccessories that fit
