▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403-CR-E4-GL4 V2403-CR-E4-LB1 Engine Type Naturally aspirated, multi-valve, liquid-cooled diesel 4-cylinder, multi-valve, naturally aspirated, common-rail, liquid-cooled diesel No. of Cylinders 4 4 Displacement 148.5 in³ 148.5 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 49 hp 47.3 hp PTO Power 41 hp F (2WD gear), DT (4WD gear): 39.3 hp; HST (4WD): 37.8 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled, water with pressurized radiator Air Cleaner Dry paper, dual element Dry paper dual element Fuel System Electronic CRS (Common Rail System) Common-rail, direct injection, electronic control Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Tandem pump - gear type Open center tandem pump, gear type Implement Flow 9.8 gpm 7.8 gpm Steering Flow 4.9 gpm 4.7 gpm Total Hydraulic Flow 14.7 gpm 12.5 gpm Overall Hydraulic Pump Flow 14.7 gpm 12.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None standard (up to 3 optional) Not Published No. of Optional Remote Valves Optional, up to 3: double-acting valve or float detent valve, any position Up to 3: self-canceling detent valve or float detent valve ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 13.5 gal Coolant Capacity 8.7 qt 6.9 qt Crankcase Capacity 8.7 qt 8.7 qt Transmission / Hydraulic System Capacity 11.4 gal 10.6 gal Front Axle Fluid Capacity 8.9 qt 6.9 qt ▶ PTO & HitchPTO Type Live independent (hydraulic clutch) Live independent PTO with hydraulic clutch PTO Rear 540 rpm @ 2550 engine rpm 540 rpm Mid-PTO Availability Optional No mid-PTO offered Category, 3-Point Hitch SAE Category I Category I Hitch Lift Capacity 3,858 lb 2,870 lb Hitch Lift Capacity (at 24”) 2,756 lb 2,310 lb Lift Control Type Position control Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type Glide Shift F (2WD gear), DT (4WD gear): synchronized shuttle, 8F/8R; HST (4WD): hydrostatic, 3-range No. of Speeds 12Fx8R F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range Max Travel Speed (Forward) 16.0 mph F (2WD gear), DT (4WD gear): 14.9 mph; HST (4WD): 15.8 mph Max Travel Speed (Reverse) 15.2 mph F (2WD gear), DT (4WD gear): 14.3 mph; HST (4WD): 14.2 mph Clutch Not Published F (2WD gear), DT (4WD gear): dry type, single plate; HST (4WD): no transmission clutch Differential Lock & Limited Slip Options Rear differential lock, standard Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS (factory certified) with retractable seat belt Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc type, mechanically activated Mechanical wet disc type, pedals can be locked together Seat Suspension & Adjustability Deluxe suspension seat with swivel; Air-Ride seat (optional) Not Published Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing F (2WD gear): tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): bevel-gear front axle, non-adjustable tread spacing Front Axle Rating Not Published F (2WD gear): 3,300 lb (at 50.4 in tread); DT (4WD gear), HST (4WD): 3,300 lb (at 45.5 in tread) Drawbar Capacity 1,433 lb 1,430 lb ▶ Dimensions & ManeuverabilityOverall Width 66.5 in 62.4 in Wheelbase 74.6 in F (2WD gear): 72.8 in; DT (4WD gear), HST (4WD): 72.6 in Ground Clearance Not Published 15.2 in Min. Turn Radius without Brakes 8.9 ft (with brake applied) F (2WD gear): 10.2 ft; DT (4WD gear), HST (4WD): 11.5 ft Height to Top of ROPS 97.6 in 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Applicable Not Published Overall Length 129.5 in (with 3-point hitch) F (2WD gear): 130.3 in; DT (4WD gear), HST (4WD): 127.4 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,836 lb F (2WD gear): 3,219 lb; DT (4WD gear): 3,296 lb; HST (4WD): 3,307 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf (Option 1) or R3 LSW Turf (Option 2); R4 Industrial R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) R1 Agricultural - Front 8.3-16 F (2WD gear): 7.5L-15, 6-16; DT (4WD gear), HST (4WD): 8.3-16 R1 Agricultural - Rear 14.9-24 14.9-24 R3 Turf - Front 29x12.50-15 27x8.5-15 (2WD and 4WD); 27x10.5-15 (4WD) R3 Turf - Rear 44x18-20 44x18-20 R4 Industrial - Front 10-16.5 10-16.5 (4WD) R4 Industrial - Rear 17.5L-24 17.5L-24 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) 2-lever quick coupler, tool-free attach and detach Loader Model Not Published LA765 Loader Lift Height Not Published LA765: 105.2 in Loader Lift Capacity (Full Height) Not Published LA765: 1,684 lb Loader Breakout Force Not Published LA765: 3,153 lbf ▶ WarrantyWarranty Length & Coverage Not Published Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
