▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403-CR-E5 V2403-CR-E4-LB1 Engine Type Direct injection, vertical, water-cooled 4-cycle, diesel 4-cylinder, multi-valve, naturally aspirated, common-rail, liquid-cooled diesel No. of Cylinders 4 4 Displacement 148.5 in³ 148.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 48.4 hp 47.3 hp PTO Power 40.5 hp F (2WD gear), DT (4WD gear): 39.3 hp; HST (4WD): 37.8 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid-cooled, water with pressurized radiator Air Cleaner Dry type, primary and secondary element Dry paper dual element Fuel System Direct injection Common-rail, direct injection, electronic control Alternator 45 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Not Published Open center tandem pump, gear type Implement Flow 7.8 gpm 7.8 gpm Steering Flow 4.7 gpm 4.7 gpm Total Hydraulic Flow 12.5 gpm (7.8 + 4.7, computed) 12.5 gpm Overall Hydraulic Pump Flow 12.5 gpm (7.8 + 4.7, computed) 12.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Optional: double-acting valve, or double-acting valve with float position (float valve as second segment only) Up to 3: self-canceling detent valve or float detent valve ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 13.5 gal Coolant Capacity 6.9 qt 6.9 qt Crankcase Capacity 8.7 qt 8.7 qt Transmission / Hydraulic System Capacity 10.6 gal 10.6 gal Front Axle Fluid Capacity 6.9 qt 6.9 qt ▶ PTO & HitchPTO Type Live independent PTO with hydraulic clutch Live independent PTO with hydraulic clutch PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published No mid-PTO offered Category, 3-Point Hitch SAE Category I Category I Hitch Lift Capacity 2,870 lb 2,870 lb Hitch Lift Capacity (at 24”) 2,320 lb 2,310 lb Lift Control Type Position control Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type Constant mesh with synchronized shuttle F (2WD gear), DT (4WD gear): synchronized shuttle, 8F/8R; HST (4WD): hydrostatic, 3-range No. of Speeds 8 forward, 8 reverse F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range Max Travel Speed (Forward) 12.9 mph F (2WD gear), DT (4WD gear): 14.9 mph; HST (4WD): 15.8 mph Max Travel Speed (Reverse) 12.4 mph F (2WD gear), DT (4WD gear): 14.3 mph; HST (4WD): 14.2 mph Clutch Dry type single stage F (2WD gear), DT (4WD gear): dry type, single plate; HST (4WD): no transmission clutch Differential Lock & Limited Slip Options Rear differential lock, pedal operated Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS (factory certified) with retractable seat belt Steering Hydrostatic power steering Hydrostatic power steering Brakes Mechanical, wet disc type Mechanical wet disc type, pedals can be locked together Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Not Published Front Axle Type Cast-iron front axle F (2WD gear): tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): bevel-gear front axle, non-adjustable tread spacing Front Axle Rating Not Published F (2WD gear): 3,300 lb (at 50.4 in tread); DT (4WD gear), HST (4WD): 3,300 lb (at 45.5 in tread) Drawbar Capacity 1,430 lb 1,430 lb ▶ Dimensions & ManeuverabilityOverall Width 52.7 in 62.4 in Wheelbase 72.6 in F (2WD gear): 72.8 in; DT (4WD gear), HST (4WD): 72.6 in Ground Clearance 11.5 in 15.2 in Min. Turn Radius without Brakes 8.9 ft (with brake applied) F (2WD gear): 10.2 ft; DT (4WD gear), HST (4WD): 11.5 ft Height to Top of ROPS 94.9 in (61.2 in with ROPS folded) 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 117.7 in (without 3-point hitch) F (2WD gear): 130.3 in; DT (4WD gear), HST (4WD): 127.4 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,362 lb F (2WD gear): 3,219 lb; DT (4WD gear): 3,296 lb; HST (4WD): 3,307 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) R1 Agricultural - Front 7.2-16 F (2WD gear): 7.5L-15, 6-16; DT (4WD gear), HST (4WD): 8.3-16 R1 Agricultural - Rear 11.2-24 14.9-24 R3 Turf - Front Not Published 27x8.5-15 (2WD and 4WD); 27x10.5-15 (4WD) R3 Turf - Rear Not Published 44x18-20 R4 Industrial - Front Not Published 10-16.5 (4WD) R4 Industrial - Rear Not Published 17.5L-24 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System Not Published 2-lever quick coupler, tool-free attach and detach Loader Model Not Published LA765 Loader Lift Height Not Published LA765: 105.2 in Loader Lift Capacity (Full Height) Not Published LA765: 1,684 lb Loader Breakout Force Not Published LA765: 3,153 lbf ▶ WarrantyWarranty Length & Coverage Basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: powertrain 36 months or 2,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
