▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403-CR-E5 V2403-CR-E5 Engine Type Direct injection, vertical, water-cooled 4-cycle, diesel Direct injection, vertical, water-cooled 4-cycle, diesel No. of Cylinders 4 4 Displacement 148.5 in³ 148.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 48.4 hp 48.4 hp PTO Power 40.5 hp 39 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Water-cooled Water-cooled Air Cleaner Dry type, primary and secondary element Dry type, primary and secondary element Fuel System Direct injection Direct injection Alternator 45 A, 12 V 45 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 7.8 gpm 7.8 gpm Steering Flow 4.7 gpm 4.7 gpm Total Hydraulic Flow 12.5 gpm (7.8 + 4.7, computed) 12.5 gpm (7.8 + 4.7, computed) Overall Hydraulic Pump Flow 12.5 gpm (7.8 + 4.7, computed) 12.5 gpm (7.8 + 4.7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Optional: double-acting valve, or double-acting valve with float position (float valve as second segment only) Optional: double-acting valve, or double-acting valve with float position (float valve as second segment only) ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 13.5 gal Coolant Capacity 6.9 qt 6.9 qt Crankcase Capacity 8.7 qt 8.7 qt Transmission / Hydraulic System Capacity 10.6 gal 10.6 gal Front Axle Fluid Capacity Not Published 6.9 qt ▶ PTO & HitchPTO Type Live independent PTO with hydraulic clutch Live independent PTO with hydraulic clutch PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch SAE Category I SAE Category I Hitch Lift Capacity 2,870 lb 2,870 lb Hitch Lift Capacity (at 24”) 2,320 lb 2,320 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Constant mesh with synchronized shuttle Hydrostatic transmission (3-range) No. of Speeds 8 forward, 8 reverse 3-range Max Travel Speed (Forward) 14.9 mph 15.8 mph Max Travel Speed (Reverse) 14.3 mph 14.2 mph Clutch Dry type single stage Not Applicable Differential Lock & Limited Slip Options Rear differential lock, pedal operated Rear differential lock, pedal operated ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Mechanical, wet disc type Mechanical, wet disc type Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Suspension seat with fore/aft travel adjustment and suspension tension adjustment Front Axle Type Cast-iron front axle Cast-iron front axle Front Axle Rating Not Published Not Published Drawbar Capacity 1,430 lb 1,430 lb ▶ Dimensions & ManeuverabilityOverall Width 62.2 in 62.2 in Wheelbase 72.6 in 72.6 in Ground Clearance 15.2 in 15.2 in Min. Turn Radius without Brakes 8.9 ft (with brake applied) 8.5 ft (with brake applied) Height to Top of ROPS 91.7 in 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 122.8 in (without 3-point hitch) 120.3 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 3,296 lb 3,549 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural; Turf Agricultural; Turf; Industrial (R4) R1 Agricultural - Front 7.5L-15 8.3-16 R1 Agricultural - Rear 14.9-24 14.9-24 R3 Turf - Front 27X8.50-15 27X10.5-15 R3 Turf - Rear 44X18-20 44X18-20 R4 Industrial - Front Not Published 10.0-16.5 R4 Industrial - Rear Not Published 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System LA766 2-Lever Quick Coupler LA766 2-Lever Quick Coupler Loader Model LA766 LA766 Loader Lift Height 105.2 in (at pivot pin) 105.2 in (at pivot pin) Loader Lift Capacity (Full Height) 1,676 lb (at pivot pin, max. height) 1,676 lb (at pivot pin, max. height) Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: powertrain 36 months or 2,000 hours Basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: powertrain 36 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit
