▶ EngineEngine Manufacturer Kubota FPT Engine Model V2403-CR-TE4-GL1 R 753 IE4 Engine Type Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged 3-cylinder, FPT turbocharged & aftercooled No. of Cylinders 4 3 Displacement 148.5 in³ 135.9 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 52 hp 53 hp PTO Power 44 hp 45 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry paper, dual element Dry Fuel System Electronic Common Rail System (CRS) Electronic high pressure common rail Alternator 45 A, 12 V 75 A ▶ HydraulicsPump Type Tandem pump - gear type Engine-driven dual gear-type Implement Flow 9.8 gpm 11.9 gpm Steering Flow 4.9 gpm 5.5 gpm Total Hydraulic Flow 14.7 gpm 17.4 gpm (11.9 + 5.5, computed) Overall Hydraulic Pump Flow 14.7 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Optional, up to 3: double-acting valve or float detent valve, any position 2 ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 17.2 gal Coolant Capacity 8.7 qt Not Published Crankcase Capacity 9.9 qt Not Published Transmission / Hydraulic System Capacity 11.9 gal Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Live independent (hydraulic clutch) Independent PTO Rear 540 rpm @ 2550 engine rpm 540 / 540E Mid-PTO Availability Optional Not Published Category, 3-Point Hitch SAE Category I & II Category I/II Hitch Lift Capacity 3,858 lb Not Published Hitch Lift Capacity (at 24”) 2,976 lb 2,701 lb Lift Control Type Position control Mechanical Draft Control (MDC), top link sensing ▶ Transmission & DrivetrainTransmission Type Glide Shift 8x8 mechanical shuttle (dry clutch) No. of Speeds 12Fx8R 8 forward / 8 reverse Max Travel Speed (Forward) 16.5 mph Not Published Max Travel Speed (Reverse) 15.8 mph Not Published Clutch Dry type single stage Dry clutch Differential Lock & Limited Slip Options Rear differential lock, standard Mechanical rear differential lock; limited-slip MFD front axle ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic steering Brakes Wet disc type, mechanically activated Wet disc Seat Suspension & Adjustability Suspension seat with swivel function Not Published Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing 2WD or MFD with limited slip Front Axle Rating Not Published Not Published Drawbar Capacity 1,433 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 67.3 in 67.5 in Wheelbase 75.4 in MFD: 77.7 in; 2WD: 77.5 in Ground Clearance 15.4 in Not Published Min. Turn Radius without Brakes 9.2 ft (with brake applied) MFD: 190.9 in; 2WD: 135.8 in Height to Top of ROPS 98.0 in MFD: 97.4 in; 2WD: 92.7 in Height to Top of ROPS (folded) Not Published 75.9 in Height to Top of Cab Model Not Published Not Published Overall Length 135.0 in (with 3-point hitch) MFD: 134.0 in; 2WD: 129.5 in ▶ WeightTractor Weight (Base) 3,979 lb MFD: 5,060 lb; 2WD: 4,442 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard R1 (9.5-16 / 14.9-26); options: R1 (9.5-16 / 13.6-28), R4 (10-16.5 / 17.5L-24), R3 (29x12.50-15 / 44x18-20), LSW R3 (LSW305R343 / LSW610R470) R1 agricultural (bar tread) or R4 industrial tread R1 Agricultural - Front 9.5-16 MFD: 8.3x24; 2WD: 7.5x16 R1 Agricultural - Rear 14.9-26; 13.6-28 MFD: 13.6x28; 2WD: 13.6x28 R3 Turf - Front 29X12.50-15 Not Published R3 Turf - Rear 44X18-20 Not Published R4 Industrial - Front 10-16.5 MFD: 12.5x18 R4 Industrial - Rear 17.5L-24 MFD: 18.4x24 ▶ Loader & AttachmentsQuick Attach Loader System 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) Compatible loaders: L545, L555 Loader Model LA1055 L545; L555 Loader Lift Height 112.7 in (at pivot pin) L545: 106 in; L555: 105 in Loader Lift Capacity (Full Height) 2,361 lb (at pivot pin) L545 NSL: 1,565 lb; L545 MSL: 2,205 lb; L555 NSL: 1,940 lb; L555 MSL: 2,734 lb Loader Breakout Force 3,171 lbf L545: 3,131 lb; L555: 3,527 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
